1897681
Thames Cheval Mirror
Parts and Hardware List
A.
Mirror Assembly
B.
Feet Assemblies
C.
Wood Stretcher
D.
Back Stretcher
E.
Brass Stretchers
F.
Cast Dutch Bolts
G.
Small Rubber Washers
H.
Big Rubber Washers
I.
Wood Caps
J.
Allen Head Bolts
K.
Lock Washers
L.
Flat Washers
M.
Pan Head Wood Screws
N.
Phillips Head Screwdriver
O.
Allen Head Wrench
∗
Please make sure that you have all the parts and hardware indicated above before you begin assembly of this item.
∗
Use the hardware illustrations to determine correct piece and size.
∗
This item should be assembled on a soft surface to prevent scratching the finish during assembly.
∗
This item may require periodic tightening.
Page 1 of 4
1 pc
2 pcs
1 pc
1 pc
2 pcs
2 pcs
2 pcs
2 pcs
8 pcs
8 pcs
8 pcs
8 pcs
2 pcs
1 pc
1 pc
R1-8-27-04
