Scheppach AB2000 Instruction Manual page 11

A careless action can cause severe injury within a
fraction of a second.
Power tool use and care
• Do not overload the device. Use the correct
power tool for your application. The correct pow-
er tool will do the job better and safer at the rate for
which it was designed.
• Do not use the power tool if the switch does not
turn it on and off. Any power tool that cannot be
controlled with the switch is dangerous and must
be repaired.
• Remove the plug from the socket and/or remove
the battery before setting the device, changing
accessories or putting the device away. Such
preventive safety measures reduce the risk of start-
ing the power tool accidentally.
• Store idle power tools out of the reach of chil-
dren and Do not let people use the device if they
are not familiar with it or if they have not read
these instructions. Power tools are dangerous in
the hands of untrained users.
• Maintain the electric tool with care. Check
whether moving parts function properly and
do not get stuck and whether parts are broken
or are damaged and thus adversely affect the
electric tool function. Have damaged parts re-
paired before using the device. Many accidents
are caused by poorly maintained power tools.
• Always keep your cutting tools sharp and clean.
Properly maintained cutting tools with sharp cut-
ting edges are less likely to bind and are easier
to control.
• Use the power tool, accessories and tool bits
etc. in accordance with these instructions, tak-
ing into account the working conditions and the
work to be performed. Use of the power tool for
operations different from those intended could re-
sult in a hazardous situation.
• Keep handles and grasping surfaces dry, clean
and free from oil and grease. Slippery handles
and grasping surfaces do not allow for safe handling
and control of the tool in unexpected situations.
Service
• Have your power tool serviced by a qualified
repair person using only identical replacement
parts. This will ensure that the safety of the power
tool is maintained.
20 | GB www.scheppach.com
Safety instructions for hammers
• Wear hearing protection. Excessive noise can re-
sult in a loss of hearing.
• Use the additional handles provided with the
device. Loss of control can lead to injuries.
• When performing work during which the tool at-
tachment can meet with concealed power lines
or its own mains cable, hold the device by the
insulated gripping surfaces. Contact with a live
power line can also electrify metal device parts and
lead to an electric shock.
Keep these safety instructions in a safe place.
Residual risks
Even when this power tool is operated properly,
residual risks still remain. The following hazards
may arise in connection with the design and con-
struction of this power tool:
• Lung damage if suitable dust protection mask is not
worn.
• Hearing damage if suitable hearing protection is not
worn.
• Damage to health resulting from hand/arm vibration
if the device is used over an extended period of time
or if it is not properly operated and maintained.
6. Technical data
Blow rate 2000 bpm
Dimensions L x W x H 630 x 125 x 275 mm
Blowing force 60 Joule
Weight 11.5 kg
Motor 220 - 240 V~ 50 Hz
Power consumption P1 1700 W
Protection class
Type of Protection IPX0
Tool fitting SDS-MAX
Danger!
Noise and vibration
The noise and vibration levels have been determined
in accordance with EN 60745.
Sound pressure level L 98.6 dB
pA
Uncertainty K 3 dB
pA
Sound power level L
WA
Uncertainty K
WA
Wear hearing protection.
Excessive noise can result in a loss of hearing.
Total vibration emission values (vector sum of three
directions) determined according to EN 60745.
Main handle
a = 13.99 m/s , K = 1.5 m/s
2
h(NL)
a = 18.42 m/s , K = 1.5 m/s
2
h(CH)
a = 17.62 m/s 2 , K = 1.5 m/s
h(Cheq)
Additional grip
a = 14.41 m/s , K = 1.5 m/s
2 2
h(NL)
a = 14.08 m/s , K = 1.5 m/s
2
h(CH)
a = 14.15 m/s , K = 1.5 m/s
2
h(Cheq)
The specified vibration emission value has been meas-
ured according to a standardised testing procedure
and can be used for comparison of one power tool with
another; and may change depending on the way in
which the power tool is used and in exceptional cases
may be higher than the specified value.
The specified vibration emission value can be used to
compare one power tool with another.
The specified vibration emission value can also be
used for an initial estimation of the impair.
Keep the noise level and vibration to a minimum!
• Only use devices which are free of defects.
• Maintain and clean the device at regular intervals.
• Adapt your working methods to the device.
• Do not overload the device.
• Have the device checked if necessary.
• Switch the device off if it is not in use.
• Wear gloves.
II
7. Unpacking
• Open the packaging and carefully remove the de-
vice.
• Remove the packaging material, as well as the pack-
aging and transport safety devices (if present).
• Check whether the scope of delivery is complete.
• Check the device and accessory parts for transport
damage. In the event of complaints the carrier must
be informed immediately. Later claims will not be
recognised.
104.06 dB
• If possible, keep the packaging until the expiry of the
warranty period.
3 dB
• Familiarise yourself with the product by means of the
operating instructions before using for the first time.
• With accessories as well as wearing parts and re-
placement parts use only original parts. Replace-
ment parts can be obtained from your dealer.
• When ordering please provide our article number as
well as type and year of manufacture for your equip-
ment.
2
m WARNING!
2
The device and the packaging material are not
2
children's toys! Do not let children play with plas-
tic bags, films or small parts! There is a danger of
choking or suffocating!
2
8. Before commissioning
2
Before connecting the machine, make certain that the
data on the type plate matches with the mains power
data.
Warning!
Always pull out the mains plug before carrying out
adjustments on the device.
Check the deployment location for hidden electrical
lines, gas pipes and water pipes using a cable detector.
Additional handle (fig.1)
For safety reasons, use the demolition hammer
only with the additional handle!
1. The additional handle (9) provides you safe grip
while using the demolition hammer.
2. The additional handle (9) can be rotated to any po-
sition.
3. Loosen the screw.
4. Turn the additional handle (9) to a convenient and
safe working position and tighten the screw again.
Inserting the tool (Fig. 2)
• Clean tool before use and lightly grease tool shaft
with drill grease.
• Pull back the locking sleeve (2) and hold in place.
• Push the dust-free tool into the tool receiver up to
the stop while rotating it. The tool will lock itself in
place.
• Check the locking mechanism by pulling on the tool.
www.scheppach.com GB | 21
