Summary of Contents for Fujitsu Siemens Computers D1242
- Page 1 COMPONENT .com Technisches Handbuch / Technical Manual Systembaugruppe / System board D1242...
- Page 2 Sie haben ..technische Fragen oder Probleme? Wenden Sie sich bitte an: · Ihren zuständigen Vertriebspartner · Ihre Verkaufsstelle Weitere Informationen finden Sie in den Handbüchern "Sicherheit" und "Garantie". Aktuelle Informationen zu unseren Produkten, Tipps, Updates usw. finden Sie im Internet: http://www.fujitsu-siemens.com Are there ...
- Page 4 Este manual ha sido impreso sobre papel reciclado. Questo manuale è stato stampato su carta da riciclaggio. Denna handbok är tryckt på recyclingpapper. Dit handboek werd op recycling-papier gedrukt. A26361-D1242-Z120-1-7419 Bestell-Nr./Order No.: Printed in the Federal Republic of Germany AG 0402...
- Page 5 Deutsch English Systembaugruppe D1242 System board D1242 Technisches Handbuch Technical Manual Ausgabe April 2002 April 2002 edition...
- Page 6 Copyright ã Fujitsu Siemens Computers GmbH 2002 Intel ist ein eingetragenes Warenzeichen der Intel Corporation, USA. PS/2 ist ein eingetragenes Warenzeichen von International Business Machines, Inc. Alle weiteren genannten Warenzeichen sind Warenzeichen oder eingetragene Warenzeichen der jeweiligen Inhaber und werden als geschützt anerkannt.
-
Page 7: Table Of Contents
Write protection for floppy disks - switch 6 .................9 Skipping the password query - switch 7 ..................9 Recovering System BIOS - switch 8 ..................9 Add-on modules ..........................10 Slot sequence..........................11 Upgrading main memory......................11 Replacing the lithium battery....................13 Glossary ............................14 A26361-D1242-Z120-1-7419 - Preliminary... -
Page 9: Introduction
Introduction This Technical Manual describes the system board D1242, which can be equipped with up to two Intel Xeon processors. You will find further information in the "BIOS Setup" description. Further information about drivers is provided in the readme files on the hard disk, on the supplied drivers diskettes, on the "Drivers &... -
Page 10: Information About Boards
Remove the power plug from the mains supply before inserting or removing boards containing ESDs. · Always hold boards with ESDs by their edges. · Never touch pins or conductors on boards fitted with ESDs. 2 - English A26361-D1242-Z120-1-7419 - Preliminary... -
Page 11: Features
PS/2 ports for keyboard and mouse · 1 RJ45 LAN port for System Management · 1 serial port for System Management · 1 power supply connector for System Management · 1 port for an accumulator card for System Management English - 3 A26361-D1242-Z120-1-7419 - Preliminary... -
Page 12: Interfaces And Connectors
6 = Fan connector for CPU 2 15 = Power supply connector for System 7 = IDE drives (secondary) Management 8 = IDE drives (primary) 16 = Wake On LAN 9 = Port for powerbackplane support 17 = Switch block 4 - English A26361-D1242-Z120-1-7419 - Preliminary... -
Page 13: Isa Bus Resources
"IRQ" = interrupt assigned as shipped "Address" = this address can be used for your particular device "Address" = this DMA can be used for your particular device Default settings are shown in bold print. English - 5 A26361-D1242-Z120-1-7419 - Preliminary... -
Page 14: Pci Bus Resources
PCI IRQ Line for INTC# PCI IRQ Line for INTD# PCI devices on the system board use the following PCI IRQ Line: PCI Device Ethernet Copernicus SCSI A SCSI B PCI IRQ Line 1, 2, 3, 4 6 - English A26361-D1242-Z120-1-7419 - Preliminary... -
Page 15: Screen Resolution
32 bit True Color 800x600 32 bit True Color 800x600 32 bit True Color 1024x768 32 bit True Color 1024x768 32 bit True Color 1024x768 32 bit True Color 1024x768 32 bit True Color English - 7 A26361-D1242-Z120-1-7419 - Preliminary... -
Page 16: Settings With Switches
Switch 2 is used to define whether the memory configuration saved in CMOS is ignored and the physical memory size is redetermined. The memory configuration saved in CMOS is ignored and the physical memory size is redetermined. The memory configuration from CMOS is used. 8 - English A26361-D1242-Z120-1-7419 - Preliminary... -
Page 17: Server Management Controller - Switch 5
The system boots from the "Flash BIOS floppy disk" from Drive A and reprograms the system BIOS on the board. The System BIOS is started with the system BIOS from the system board (default setting). English - 9 A26361-D1242-Z120-1-7419 - Preliminary... -
Page 18: Add-On Modules
Voltage regulator module (VRM) for bank 3) CPU 2 6 = Locations for main memory (memory bank 2) PCI slots 3 to 6 have 3.3 V signal voltage, PCI slots 1 and 2 have 5 V signal voltage. 10 - English A26361-D1242-Z120-1-7419 - Preliminary... -
Page 19: Slot Sequence
Installing a memory module Ê Push the holders on each side of the memory compartment outwards. Ê Insert the memory module in the slot while folding the side holders up until the memory module engages (2). English - 11 A26361-D1242-Z120-1-7419 - Preliminary... - Page 20 Add-on modules Removing a memory module Ê Push the clips on the right and left of the compartment outward (1). Ê Carefully remove the memory module from the compartment (2). 12 - English A26361-D1242-Z120-1-7419 - Preliminary...
-
Page 21: Replacing The Lithium Battery
Ê Lift the contact (1) a few millimetres and remove the lithium battery from its socket (2). Ê Insert a new lithium battery of the same type into the socket (3). English - 13 A26361-D1242-Z120-1-7419 - Preliminary... -
Page 22: Glossary
Universal Serial Bus GMCH Graphics and Memory Controller Video Graphic Adapter Inter Integrated Circuit Wake On LAN IAPC Instantly Available Power Managed Desktop PC Design I/O Controller Hub Intelligent Drive Electronics IPSEC Internet Protocol Security 14 - English A26361-D1242-Z120-1-7419 - Preliminary...
