- Page 1 S Y S T E M B A U G R U P P E D 1 2 0 5 S Y S T E M B O A R D D 1 2 0 5 TECHNISCHES HANDBUCH TECHNICAL MANUAL...
- Page 2 Sie haben ..technische Fragen oder Probleme? Wenden Sie sich bitte an: · unsere Hotline: Mo-Fr: 9 - 18 Uhr 9 - 14 Uhr Tel.: ++49 (0) 180 3777 000 · Ihren zuständigen Vertriebspartner · Ihr Verkaufsstelle Weitere Informationen finden Sie im Handbuch "Sicherheit, Ergonomie und Garantie". Aktuelle Informationen zu unseren Produkten, Tipps, Updates usw.
- Page 4 Este manual ha sido impreso sobre papel reciclado. Questo manuale è stato stampato su carta da riciclaggio. Denna handbok är tryckt på recyclingpapper. Dit handboek werd op recycling-papier gedrukt. A26361-D1205-Z120-1-7419 Bestell-Nr./Order No.: Printed in the Federal Republic of Germany AG 0800...
- Page 5 Deutsch English Systembaugruppe D1205 System board D1205 Technisches Handbuch Technical Manual Ausgabe August 2000 August 2000 edition...
- Page 6 Copyright ã Fujitsu Siemens Computers GmbH 2000 Intel ist ein eingetragenes Warenzeichen der Intel Corporation, USA. PS/2 ist ein eingetragenes Warenzeichen von International Business Machines, Inc. Alle weiteren genannten Warenzeichen sind Warenzeichen oder eingetragene Warenzeichen der jeweiligen Inhaber und werden als geschützt anerkannt.
-
Page 7: Table Of Contents
Skipping the password query - switch 7 ..................9 Recovering System BIOS - switch 8 ..................9 Add-on modules ..........................10 Slot sequence.......................... 11 Upgrading main memory......................11 Upgrading the IPSEC accelerator chip ..................12 Replacing the lithium battery....................13 Glossary ............................14 A26361-D1205-Z120-1-7419... -
Page 9: Introduction
Introduction This Technical Manual describes the system board D1205, which can be equipped with up to four Intel Xeon processors. You may find further information in the description "BIOS Setup". Further information to drivers is provided in the readme files on hard disk or on the supplied drivers diskettes or on the "Drivers &... -
Page 10: Information On Boards
The equipment and tools you use must be free of static charges. • Pull out the power plug before inserting or pulling out boards containing ESDs. • Always hold boards with ESDs by their edges. • Never touch pins or conductors on boards fitted with ESDs. 2 - English A26361-D1205-Z120-1-7419... -
Page 11: Features
(COM1 and COM2) • two external and one internal USB port (USB = Universal Serial Bus) • external CAN bus port • two external PS/2 interfaces for keyboard and mouse • system monitoring English - 3 A26361-D1205-Z120-1-7419... -
Page 12: Interfaces And Connectors
11 = Fan connectors 1 and 2 (optional) 5 = IDE drives (primary) 12 = Switch block 6 = Power supply II 13 = External ports 7 = IDE drives (primary) 14 = CAN port 15 = Internal USB port 4 - English A26361-D1205-Z120-1-7419... - Page 13 5 = Parallel port 10 = PS/2 keyboard port If a chipcard reader is installed, no device may be connected to serial interface 2 (COM2). Please use the current driver from the mailbox for the chipcard reader. English - 5 A26361-D1205-Z120-1-7419...
-
Page 14: Pci Bus Resources
64 bit 64 bit PCI bus slot 33 MHz / 5 V 64 bit 64 bit PCI bus slot 33 MHz / 5 V 32 bit 32 bit PCI bus slot 33 MHz / 5 V 6 - English A26361-D1205-Z120-1-7419... -
Page 15: Pci Irq Line X - Assignment Of The Pci Interrupts
ISA interrupt that is used by a component on the system board (e.g. controller) or an ISA board. With the Auto setting, you can use the ICU (ISA Configuration Utility ) utility to check how the interrupts are assigned. English - 7 A26361-D1205-Z120-1-7419... -
Page 16: Possible Screen Resolution
16.7 mio. 1600x1200 65 535 1600x1200 65 535 1600x1200 65 535 1600x1200 65 535 The horizontal rate values may have a tolerance range of ±0.3 kHz. Shaded screen resolutions are not supported by LCD monitors (TFT). 8 - English A26361-D1205-Z120-1-7419... -
Page 17: Settings With Switches
The system boots from the "Flash BIOS floppy disk" from Drive A and reprograms the system BIOS on the board. The system is started with the system BIOS from the system board. The system BIOS cannot be reprogrammed (default setting). English - 9 A26361-D1205-Z120-1-7419... -
Page 18: Add-On Modules
4 = Location bank 1A for main memory 10 = PCI slot 7 5 = Location bank 2 for main memory 6 = Location bank 2A for main memory PCI slots support 3.3 V main and auxiliary voltages. 10 - English A26361-D1205-Z120-1-7419... -
Page 19: Slot Sequence
PC133 specification). Installing memory modules Ê Flip the holders on each side of the relevant location outwards. Ê Insert the memory module in the slot while folding the side holders up until the memory module engages (2). English - 11 A26361-D1205-Z120-1-7419... -
Page 20: Upgrading The Ipsec Accelerator Chip
Pull the memory module out of its location (2). Upgrading the IPSEC accelerator chip If the system board is prepared for upgrading with an IPSEC accelerator chip (Intel IPSEC), the upgrade is carried out as shown in the figure. 12 - English A26361-D1205-Z120-1-7419... -
Page 21: Replacing The Lithium Battery
Brukte batterier kasseres i henhold til fabrikantens instruksjoner. Ê Lift the contact (1) a few millimeters and remove the battery from its socket (2). Ê Insert a new lithium battery of the same type in the socket (3). English - 13 A26361-D1205-Z120-1-7419... -
Page 22: Glossary
Firmware Hub Universal Serial Bus GMCH Graphics and Memory Controller Video Graphic Adapter Inter Integrated Circuit Wake On LAN IAPC Instantly Available Power Managed Desktop PC Design I/O Controller Hub Intelligent Drive Electronics IPSEC Internet Protocol Security 14 - English A26361-D1205-Z120-1-7419...
