- Page 1 COMPONENTS Technisches Handbuch / Technical manual Mainboard D1527 / D1526...
- Page 2 Please contact: · your sales partner · your sales outlet You will find further information in the manuals "Safety" and "Warranty". The latest information and updates (e. g. BIOS update) on our mainboards can be found on the Internet under: http://www.fujitsu-siemens.com/mainboards...
- Page 4 Questo manuale è stato stampato su carta da riciclaggio. Denna handbok är tryckt på recyclingpapper. Dit handboek werd op recycling-papier gedrukt. Herausgegeben von/Published by Fujitsu Siemens Computers GmbH A26361-D1527-Z120-1-6319 Bestell-Nr./Order No.: Printed in the Federal Republic of Germany AG 0902...
- Page 5 German English Mainboard D1527 / D1526 Technisches Handbuch Technical manual Ausgabe September 2002 September 2002 edition...
- Page 6 All other trademarks referenced are trademarks or registered trademarks of their respective owners, whose protected rights are acknowledged. Copyright ã Fujitsu Siemens Computers GmbH 2002 All rights, including rights of translation, reproduction by printing, copying or similar methods, in part or in whole, are reserved.
- Page 7 Übersicht /Overview Mainboard D1526/D1527 Stromversorgung / Power Supply Interne Anschlüsse und Steckplätze / internal Diskettenlaufwerk / Floppy disk drive connectors and slots IDE-Laufwerke 3/4 / IDE-drives 3/4 Systemüberwachung / System monitoring Bedienfeld / Frontpanel Schalter / Switch IDE-Laufwerke 1/2 / IDE-drives 1/2...
-
Page 9: Table Of Contents
Contents Übersicht /Overview Mainboard D1526/D1527................1 Mainboard D1527 / D1526........................1 Notational conventions ......................1 Important notes..........................1 Information about boards ......................2 List of features...........................3 Special technical features – special features ................4 Brief instructions on installing mainboard ..................6 Prior to installation ........................6 Interfaces and connectors ......................8 External ports ............................8... -
Page 11: Übersicht /Overview Mainboard D1526/D1527
Mainboard D1527 / D1526 Your mainboard is available in different configuration levels. Depending on the configuration chosen, some of the hardware components described may not be available on your mainboard. Further information Informationen zum BIOS-Setup und zusätzliche Beschreibungen zu den Treibern finden Sie: ·... -
Page 12: Information About Boards
· Remove the power plug from the mains supply before inserting or removing boards containing ESDs. · Always hold boards with ESDs by their edges. · Never touch pins or conductors on boards fitted with ESDs. 2 - English A26361-D1527-Z120-1-6319... -
Page 13: List Of Features
Temperature monitoring ü System Monitoring ü ü Fujitsu Siemens Computers Keyboard Power Button Support Internal ports DIMM Sockets (DDR SDRAM, PC2100/2700) AGP Slot (2/4x, 32 bit, 66 MHz, 1.5 V) PCI slot (32-bit, 33 MHz, 5 V and 3.3 V) CNR Slot (Type A, AC‘97 only) -
Page 14: Special Technical Features - Special Features
Thermal Management and System Monitoring A microcontroller developed by Fujitsu Siemens Computers reliably protects your PC against damage caused by overheating. Overheating can lead to the data loss or processor damage. - Page 15 If an error occurs during a BIOS update (e.g. due to a power failure), the system BIOS will be destroyed. All Fujitsu Siemens Computers mainboards are equipped with a recovery BIOS. With it a destroyed BIOS can easily be restored. Exact instructions are provided in the chapter "BIOS Recovery –...
-
Page 16: Brief Instructions On Installing Mainboard
(power supply unit, case connections such as ATX on/off switch, hard disk or floppy disk drive). You should not install additional cards and devices until this minimum configuration successfully boots (see chapter entitled "Add-on modules / Upgrading". 6 - English A26361-D1527-Z120-1-6319... -
Page 17: Driver Installation
Connect the plugs for the power supply, control panel and drives to the corresponding connections on the mainboard. Driver installation Ê Install the drivers for the chipset. The drivers are contained on the included "Drivers & Utilities" CD. Please refer to chapter "Drivers" for a description of installing drivers. English - 7 A26361-D1527-Z120-1-6319... -
Page 18: Interfaces And Connectors
VGA port, blue (monitor) LAN connector This mainboard is equipped with the 82562ET (D1526) or the 82562EM (D1527) LAN controller. The LAN controller is equipped with a 3 KB transmission and receiving buffer (FIFO) and supports WOL function through Magic Packetä. -
Page 19: Internal Ports And Connectors
An ultra ATA/66 or ultra ATA/100 hard disk must be connected with a cable especially designed for the ultra ATA/66 or ultra ATA/100 mode. Ê Connect the end of the cable marked with blue to the mainboard. English - 9 A26361-D1527-Z120-1-6319... -
Page 20: Pin Assignment Of Internal Ports
"APM and ACPI system status, energy-saving modes"). Speaker 0,5 W at 8 Ohm Sleep Indicates the system state APM or ACPI together with the Power-On LED (see chapter entitled "APM and ACPI system status, energy-saving modes"). 10 - English A26361-D1527-Z120-1-6319... - Page 21 PS FAN Control (PS FAN C max. 3 mA) Reserved PS FAN Sense SMB CLK SMB DATA VCC EEPROM (+3.3 V) Power On LED II Signal Power On LED (Anode) Power On LED (Anode) Power On LED (Cathode) English - 11 A26361-D1527-Z120-1-6319...
- Page 22 Fan sense Lüfter 2 / Fan 2 (system fan - supervised) Signal Controlled Fan voltage (0 V, +6 V ... +12 V, max. 1 A) or fix Fan voltage (+12 V, max. 1 A) Fan sense 12 - English A26361-D1527-Z120-1-6319...
- Page 23 P3V3P DUAL USB C/D / E/F - dual channel (internal or external via special wire) Signal Signal Chiprcardreader on VCC C VCC D Data negative C Data negative D Data positive C Data positive D not connected English - 13 A26361-D1527-Z120-1-6319...
- Page 24 Intrusion switch present (low asserted) Audio S/PDIF Signal SPDIF out Audio Bedienfeld / Audio front panel Signal Signal Micro input Analog GND Micro bias Analog VCC Right line output Right line return Left line output Left line return 14 - English A26361-D1527-Z120-1-6319...
- Page 25 Pin assignment of internal ports CD-ROM audio Signal Left CD audio input CD GND CD GND Right CD audio input Prozessor-Stromversorgung / Processor power Supply Signal Signal +12 V +12 V English - 15 A26361-D1527-Z120-1-6319...
-
Page 26: Settings With Switches And Jumpers
The System BIOS executes from floppy drive A: and the inserted "Flash-BIOS- Diskette" restores the System BIOS on the mainboard. Normal operation (default setting). Reserved - switch 3 and switch 4 Switch 3 and 4 are reserved. 16 - English A26361-D1527-Z120-1-6319... -
Page 27: Add-On Modules / Upgrading
(A) with regard to the position (4). Die abgeschrägte Ecke des Prozessors kann auch an einer anderen Stelle sein als wie in der Abbildung dargestellt. Ê Push the lever back down until it clicks into place (5). English - 17 A26361-D1527-Z120-1-6319... -
Page 28: Mounting Heat Sink
Depending on the processor variant, clips may also be supplied for mounting the heat sink that fix it in place. Ê When you have mounted the optional fan, connect the fan plug to the corresponding connection on the mainboard. 18 - English A26361-D1527-Z120-1-6319... -
Page 29: Upgrading Main Memory
32, 64, 128, 256, 512 or 1024 Mbyte for one socket A current list of the memory modules recommended for this mainboard is available on the Internet at: www.fujitsu-siemens.de/mainboards. At least one memory module must be installed. Memory modules with different memory capacities can be combined. -
Page 30: Upgrading Agp Screen Controllers
PCI IRQ Lines connect AGP slots, PCI slots and onboard components to the interrupt controller. PCI IRQ Lines are permanently wired on the mainboard. Which ISA IRQs are assigned to the PCI IRQ Lines is normally automatically specified by the BIOS (see description in "BIOS Setup"). 20 - English A26361-D1527-Z120-1-6319... -
Page 31: Replacing Lithium Battery
Do not throw lithium batteries into the household waste. They must be disposed of in accordance with local regulations concerning special waste. Ensure that you insert the battery the right way round. The plus pole must be on the top! English - 21 A26361-D1527-Z120-1-6319... - Page 32 Press the locking lug in the direction of the arrow; the battery jumps somewhat out of the holder (1). Ê Remove the battery (2). Ê Insert a new lithium battery of the same type into the socket (3). 22 - English A26361-D1527-Z120-1-6319...
-
Page 33: Bios Update
BIOS update BIOS update When should a BIOS update be carried out? Fujitsu Siemens Computers makes new BIOS versions available to ensure compatibility to new operating systems, new software or new hardware. In addition, new BIOS functions can also be integrated. -
Page 34: Microcode Update
Safety for processor on Fujitsu Siemens Computers mainboards If the processor uses an old or incorrect microcode, error-free operation cannot be ensured. Fujitsu Siemens Computers has therefore implemented a function on its mainboards that interrupts the booting process if no suitable microcode is available for the installed processor. -
Page 35: Drivers
Insert the CD Drivers & Utilities Collection into the CD ROM drive. Ê If the CD does not start automatically, run the START.EXE programme in the main directory of the CD. Ê Select DeskUpdate - Fully automatic installation. Ê Follow the instructions on screen. English - 25 A26361-D1527-Z120-1-6319... -
Page 36: Annex
Mainboard current requirement You require a Pentium4 power supply nit as per the ATX12V specification for this mainboard. If you do not have a PC from Fujitsu Siemens Computer, make sure that the power supply unit provides the required amperages. -
Page 37: Apm And Acpi System Status, Energy-Saving Modes
* G = Global status; S = System status The power supply unit must provide sufficiently loadable 5 V standby voltage. To use the WOL functionality the power supply must provide a 5 V auxiliary voltage (5VSB) of at least 1 A. English - 27 A26361-D1527-Z120-1-6319... -
Page 38: Mainboard Revision And Bios Version
The BIOS version can be displayed in the BIOS Setup. Ê Press [F2] during booting to open the BIOS Setup. Ê Press [F1]. The BIOS version is specified on the displayed information page under the entry BIOS Release. 28 - English A26361-D1527-Z120-1-6319... -
Page 39: Error Messages
Available CPUs do not support the same bus frequency – System halted! Memory type mixing detected Non Fujitsu Siemens Memory Module detected – Warranty void There are more than 32 32 RDRAM devices in the system Check whether the system configuration has changed. If necessary, correct the settings. - Page 40 Keyboard error Check that the keyboard is connected properly. Keyboard error nn nn Stuck Key Release the key on the keyboard (nn is the hexadecimal code for the key). 30 - English A26361-D1527-Z120-1-6319...
- Page 41 = Group number x = Number of SEs found on the communication bus y = Number of SEs entered in Number of connected SE k1, k2 ... = Device ID of the storage extensions found English - 31 A26361-D1527-Z120-1-6319...
-
Page 42: Dos Error Messages
Critical error logged to server management processor - system halted If the NMI button of the control panel is pressed, then the following error text is output on the screen: Frontpanel NMI activated - system halted 32 - English A26361-D1527-Z120-1-6319... -
Page 43: Smartcard Reader - Error Messages
You have exceeded the maximum number of failed attempts to enter the PIN. The Sicrypt SmartCard is blocked. Enter the administrator PIN to re-activate the Sicrypt SmartCard. You must then enter a new User PIN to restart the system. English - 33 A26361-D1527-Z120-1-6319... -
Page 44: Glossary
