- Page 1 Technisches Handbuch / Technical Manual Mainboard D1562/D1561 Deutsch / English / Français...
- Page 2 ...des questions techniques ou des problèmes ? Veuillez contacter : Votre partenaire Commercial Votre point de Vente Les dernières informations ainsi que les updates (p.ex. BIOS-Update) par rapport à nos cartes mères sont à votre disposition sur Internet : http://www.fujitsu-siemens.com/mainboards...
- Page 4 Questo manuale è stato stampato su carta da riciclaggio. Denna handbok är tryckt på recyclingpapper. Dit handboek werd op recycling-papier gedrukt. Herausgegeben von/Published by Fujitsu Siemens Computers GmbH Bestell-Nr./Order No.: A26361-D1562-Z121-1-6319 Printed in the Federal Republic of Germany AG 1103...
- Page 5 Deutsch English Mainboard D1562/D1561 Français Technisches Handbuch Technical Manual Ausgabe November 2003 November 2003 edition...
- Page 6 Alle weiteren genannten Warenzeichen sind Warenzeichen oder eingetragene Warenzeichen der jeweiligen Inhaber und werden als geschützt anerkannt. Copyright ã Fujitsu Siemens Computers GmbH 2003 Alle Rechte vorbehalten, insbesondere (auch auszugsweise) die der Übersetzung, des Nachdrucks, der Wiedergabe durch Kopieren oder ähnliche Verfahren.
- Page 7 Übersicht/Overview Mainboard D1562/61 Diskettenlaufwerk / Floppy disk drive Interne Anschlüsse und Steckplätze / Power On LED II Internal connectors and slots Bedienfeld / Front panel 22 23 Stromversorgungsüberwachung / Power supply control IDE-Laufwerke 3/4 / IDE-drives 3/4 Stromversorgung / Power supply...
-
Page 9: Table Of Contents
Contents Übersicht/Overview Mainboard D1562/61 ..................1 Mainboard D1562/D1561........................1 Notational conventions.......................1 Important notes ..........................2 Information about boards ......................2 List of features...........................3 Special features.........................7 Brief instructions on installing mainboard...................9 Prior to installation ........................9 Interfaces and connectors ......................11 External ports ..........................11 LAN connector.........................11 Graphics port - Supported screen resolutions ................12 Internal ports and connectors ......................12... -
Page 11: Übersicht/Overview Mainboard D1562/61
Mainboard D1562/D1561 Your mainboard is available in different configuration levels. Depending on the configuration chosen, some of the hardware components described may not be available on your mainboard. Additional information Information on the BIOS Setup and additional descriptions of the drivers are contained:... -
Page 12: Important Notes
The equipment and tools you use must be free of static charges. Remove the power plug from the mains supply before inserting or removing boards containing ESDs. Always hold boards with ESDs by their edges. Never touch pins or conductors on boards fitted with ESDs. 2 - English A26361-D1562-Z121-1-6319... -
Page 13: List Of Features
- / - / - / - ü / - SmartCard Reader Support (USB / serial) - / - ü ü Fujitsu Siemens Computers Keyboard Power Button Support Special Onboard features ü / - Silent Fan / Silent Fan LT - / - System Guard / Silent Drives ü... - Page 14 List of features Internal ports (continued) D1562-A D1561-A FireWire™ * (9-Pin, Intel standard header) USB Ports* (2.0, ~480 MB/s) Serial Ports* (FIFO, 16550 compatible) Fan Connectors PSU** / CPU / AUX1 / AUX2 1 / 1 / 1 / -...
- Page 15 Temperature monitoring CPU/ONB1/ONB2/OFFB SmartCard Reader Support (USB / serial) ü / - - / - ü ü Fujitsu Siemens Computers Keyboard Power Button Support Supports new Intel Pentium processors with 1 Mbyte Second-level-cache Special Onboard features ü / - - / ü...
- Page 16 List of features Internal ports (continued) D1562-C D1561-C FireWire™ * (9-Pin, Intel standard header) USB Ports* (2.0, ~480 MB/s) Serial Ports* (FIFO, 16550 compatible) Fan Connectors PSU** / CPU / AUX1 / AUX2 1 / 1 / 1 / -...
-
Page 17: Special Features
Silent Fan A micro controller developed by Fujitsu Siemens Computers monitors and controls the fans in the PC and thus prevents any unnecessary noise annoyance. Should the processor become in spite of full turning ventilator too hot, then the processor clock rate will automatically be reduced so that the system continues to run stably. - Page 18 USB Security is a BIOS function that offers protection against unauthorised access regardless of the operating system used. If USB Security is activated, the system can only be started, if the MemoryBird of Fujitsu Siemens Computers is connected to one of the existing USB-ports.
-
Page 19: Brief Instructions On Installing Mainboard
Installation Equip the mainboard with the processor, heat sink and memory modules before installation if Ê possible. Further information can be found in "Replacing processor" chapter. ► Open the casing as described in the operating manual. English - 9 A26361-D1562-Z121-1-6319... -
Page 20: Driver Installation
Ê connections on the mainboard. Driver installation Install the drivers for the chipset. You may find the driver on the "Drivers & Utilities" CD. Please Ê refer to chapter "Drivers" for a description of installing drivers. 10 - English A26361-D1562-Z121-1-6319... -
Page 21: Interfaces And Connectors
LED 2 lights differently with the two possible LAN controllers: Link Mode: the LAN connection is active. WOL mode: a Magic Packet is being received. 82562EZ 82547EI 82562EZ 82547EI 10 Mbit/s 10 Mbit/s 100 Mbit/s yellow green 100 Mbit/s yellow green 1000 Mbit/s yellow English - 11 A26361-D1562-Z121-1-6319... -
Page 22: Graphics Port - Supported Screen Resolutions
If you have connected audio devices to both Line out connections, only the connection on the front of the system is active. If you have connected audio devices to both Microphone connections, only the connection on the back of the system is active. 12 - English A26361-D1562-Z121-1-6319... -
Page 23: Pin Assignment Of Internal Ports
Indicates the system state APM or ACPI together with the Sleep LED (see chapter entitled "APM and ACPI system status, energy-saving modes"). Speaker 0,5 W at 8 Ohm Power On LED II Signal Power On LED (Anode) Power On LED (Anode) Power On LED (Cathode) English - 13 A26361-D1562-Z121-1-6319... - Page 24 Cable select DAK (low asserted) IRQ (high asserted) not connected ADR 1 (high asserted) ATA66 Detect (low asserted) ADR 0 (high asserted) ADR 2 (high asserted) CS 1 (low asserted) CS 3 (low asserted) IDE-LED (low asserted) 14 - English A26361-D1562-Z121-1-6319...
- Page 25 Audio S/PDIF Signal SPDIF out CD audio input Signal Left CD audio input CD GND CD GND Right CD audio input AUX audio in Signal Left AUX audio input Analogue GND Analogue GND Right AUX audio input English - 15 A26361-D1562-Z121-1-6319...
- Page 26 Micro bias Analogue VCC Right line output Right line return not connected Left line output Left line return If the audio front panel is not used, you must plug jumpers on pin pairs 5/6 and 9/10. 16 - English A26361-D1562-Z121-1-6319...
-
Page 27: Serial Port 2
DTR 2 RI 2 Fan 1 (CPU) (processor fan - only for 3 pin fans) Signal Controlled FAN voltage (0V, +6V, ... +12V, max. 1A) or fix Fan voltage (+12 V, max. 1 A) Fan sense English - 17 A26361-D1562-Z121-1-6319... - Page 28 -12V (P12VN) +5V (VCC) PS on (low asserted) +5V (VCC) Powergood (high asserted) -5V (5PVN) +5V Auxiliary (VCC Aux) +5V (VCC) +12V (P12VP) +5V (VCC) Additional power supply ATX12 V Signal Signal +12 V +12 V 18 - English A26361-D1562-Z121-1-6319...
-
Page 29: Settings With Switches And Jumpers
The System BIOS executes from floppy drive A: and the inserted "Flash-BIOS- Diskette" restores the System BIOS on the mainboard. Normal operation (default setting). Reserved - switch 3 and switch 4 (if present) Switch 3 and 4 are reserved. English - 19 A26361-D1562-Z121-1-6319... -
Page 30: Add-On Modules / Upgrading
Celeron with 400 MHz Processor System Bus in the mPGA478 design A current list of the processors supported by this mainboard is available on the Internet at: www.fujitsu-siemens.com/mainboards . Removing and installing processors Remove the fan that there may be and the heat sink. -
Page 31: Mounting Heat Sink
Depending on the processor variant, clips may also be supplied for mounting the heat sink that fix it in place. ► When you have mounted the optional fan, connect the fan plug to the corresponding connection on the mainboard. English - 21 A26361-D1562-Z121-1-6319... -
Page 32: Upgrading Main Memory
128, 256, 512 or 1024 Mbyte for one socket A current list of the memory modules recommended for this mainboard is available on the Internet at: www.fujitsu-siemens.com/mainboards. At least one memory module must be installed. Memory modules with different memory capacities can be combined. - Page 33 At the same time flip the lateral holders upwards until the memory module snaps in place (2). Ê Removing a memory module ► Push the clips on the right and left of the memory slot outward (1). ► Pull the memory module out of the memory slot (2). English - 23 A26361-D1562-Z121-1-6319...
-
Page 34: Upgrading Agp Screen Controllers
Monofunctional expansions cards: Standard AGP and PCI expansion cards require a maximum of one interrupt, which is called the PCI interrupt INT A. Expansion cards that do not require an interrupt can be installed in any desired slot. 24 - English A26361-D1562-Z121-1-6319... - Page 35 PCI slot with IRQ sharing, check whether the expansion card properly supports IRQ sharing with the other devices on this PCI IRQ Line. The drivers of all cards and components on this PCI IRQ Line must also support IRQ sharing. English - 25 A26361-D1562-Z121-1-6319...
-
Page 36: Replacing The Lithium Battery
Press the locking lug in the direction of the arrow; the battery jumps somewhat out of the Ê holder (1). Remove the battery (2). Ê Push the new lithium battery of the identical type into the holder (3) and press it downward until Ê it engages (4). 26 - English A26361-D1562-Z121-1-6319... -
Page 37: Bios Update
BIOS update BIOS update When should a BIOS update be carried out? Fujitsu Siemens Computers makes new BIOS versions available to ensure compatibility to new operating systems, new software or new hardware. In addition, new BIOS functions can also be integrated. -
Page 38: Bios Recovery - Recovering System Bios
Save the change and terminate BIOS Setup . Ê The BIOS recovery has now been completed. The system restarts. Detailed information on the BIOS recovery is contained in the manual "BIOS Setup" ("Drivers & Utilities" CD). 28 - English A26361-D1562-Z121-1-6319... -
Page 39: Microcode Update
Safety for processor on Fujitsu Siemens Computers mainboards If the processor uses an old or incorrect microcode, error-free operation cannot be ensured. Fujitsu Siemens Computers has therefore implemented a function on its mainboards that interrupts the booting process if no suitable microcode is available for the installed processor. -
Page 40: Drivers
Insert the CD "Drivers & Utilities Collection" into the CD-ROM drive. If the CD does not start automatically, run the START.EXE programme in the main directory of Ê the CD. Select DeskUpdate - Fully automatic installation . Ê Follow the instructions on screen. Ê 30 - English A26361-D1562-Z121-1-6319... -
Page 41: Annex
USB port G 500 mA USB port H 500 mA The fuses on this mainboard can be used several times (polyfuses). Shortly after the error state has been eliminated, the fuses reset to the original state. English - 31 A26361-D1562-Z121-1-6319... -
Page 42: Apm And Acpi System Status, Energy-Saving Modes
Mainboard current requirement You require a Pentium4 power supply nit as per the ATX12V specification for this mainboard. If you do not have a PC from Fujitsu Siemens Computer, make sure that the power supply unit provides the required amperages. -
Page 43: Mainboard Revision And Bios Version
. Mainboard Revision The revision status of the mainboard exactly identifies which mainboard you have. It is indicated on a sticker on the edge of the mainboard: D1562-A21 GS 1 05618476 Example Mainboard-Revision BIOS version The BIOS version can be displayed in the BIOS Setup . -
Page 44: Error Messages
Available CPUs do not support the same bus frequency - System halted! Memory type mixing detected Non Fujitsu Siemens Memory Module detected - Warranty void There are more than 32 32 RDRAM devices in the system Check whether the system configuration has changed. If necessary, correct the settings. - Page 45 Keyboard error Check that the keyboard is connected properly. Keyboard error nn nn Stuck Key Release the key on the keyboard ( nn is the hexadecimal code for the key). English - 35 A26361-D1562-Z121-1-6319...
- Page 46 = Group number x = Number of SEs found on the communication bus y = Number of SEs entered in Number of connected SE k1, k2 ... = Device ID of the storage extensions found 36 - English A26361-D1562-Z121-1-6319...
- Page 47 Switch the device off and on again. If the message is still displayed, please contact your sales outlet or customer service centre. Verify CPU frequency selection in Setup The frequency setting for the processor is invalid. Correct the BIOS Setup and the setting. English - 37 A26361-D1562-Z121-1-6319...
-
Page 48: Glossary
Universal Serial Bus GMCH Graphics and Memory Controller Video Graphic Adapter Graphics Performance Wake On LAN Accelerator Inter Integrated Circuit IAPC Instantly Available Power Managed Desktop PC Design I/O Controller Hub Intelligent Drive Electronics IPSEC Internet Protocol Security 38 - English A26361-D1562-Z121-1-6319...
