Summary of Contents for Fujitsu Siemens Computers D1875

  • Page 1 Technical Manual Mainboard D1875 English...
  • Page 2 Sie haben ..technische Fragen oder Probleme? Wenden Sie sich bitte an: Ihren zuständigen Vertriebspartner Ihre Verkaufsstelle Aktuelle Informationen zu unseren Produkten, Tipps, Updates usw. finden Sie im Internet: http://www.fujitsu-siemens.com oder http://www.fujitsu-siemens.com/mainboards Are there ..any technical problems or other questions you need clarified? Please contact: your sales partner your sales outlet...
  • Page 4 Questo manuale è stato stampato su carta da riciclaggio. Denna handbok är tryckt på recyclingpapper. Dit handboek werd op recycling-papier gedrukt. Herausgegeben von/Published by Fujitsu Siemens Computers GmbH Bestell-Nr./Order No.: A26361-D1875-Z120-1-6319 Printed in the Federal Republic of Germany AG 0204...
  • Page 5 Deutsch English Mainboard D1875 Français Technisches Handbuch Technical Manual Ausgabe Februar 2004 February 2004 edition...
  • Page 6 Alle weiteren genannten Warenzeichen sind Warenzeichen oder eingetragene Warenzeichen der jeweiligen Inhaber und werden als geschützt anerkannt. Copyright ã Fujitsu Siemens Computers GmbH 2004 Alle Rechte vorbehalten, insbesondere (auch auszugsweise) die der Übersetzung, des Nachdrucks, der Wiedergabe durch Kopieren oder ähnliche Verfahren.
  • Page 7 Übersicht/Overview Mainboard D1875 1 = Stromversorgung / Interne Anschlüsse und Steckplätze / Power supply Internal connectors and slots 2 = Bedienfeld / Front panel 3 = Diskettenlaufwerk / Floppy disk drive 4 = USB 5 = USB 6 = IDE-Laufwerke 3/4 /...
  • Page 8: Table Of Contents

    Contents Übersicht/Overview Mainboard D1875 ..............Umschlag/Cover Mainboard D1875..........................1 Notational conventions.......................1 Important notes ..........................2 Information about boards ......................2 List of features...........................3 Special features.........................5 Brief instructions on installing mainboard...................6 Prior to installation ........................6 Interfaces and connectors ......................8 External ports ............................8 LAN connector...........................8 Audio ports and audio configuration...................9...
  • Page 10: Übersicht/Overview Mainboard D1875

    Text in this typeface indicates screen outputs. Text in this bold typeface indicates the entries you make via the keyboard. Text in italics indicates commands or menu items. "Quotation marks" indicate names of chapters or terms. A26361-D1875-Z120-1-6319, Edition: 1 English - 1...
  • Page 11: Important Notes

    The equipment and tools you use must be free of static charges. Remove the power plug from the mains supply before inserting or removing boards containing ESDs. Always hold boards with ESDs by their edges. Never touch pins or conductors on boards fitted with ESDs. 2 - English A26361-D1875-Z120-1-6319, Edition: 1...
  • Page 12: List Of Features

    ULTRA DMA interface (133 Mbyte/s) / Floppy interface S/PDIF * (5.1 digital Audio) OUT / IN - / - CD / AUX audio input - / 1 Front panel Audio (9-pin for headphone, microphone) A26361-D1875-Z120-1-6319, Edition: 1 English - 3...
  • Page 13 1 / 1 FireWire™ (6-Pin, IEEE 1394) USB (2.0, ~480MB/s) Serial Ports (RS232, FIFO, 16550 compatible) Parallel Ports (EPP/ECP) for use with internal devices or optional Front or Rear panel not supported by standard power supplies 4 - English A26361-D1875-Z120-1-6319, Edition: 1...
  • Page 14: Special Features

    USB Security is a BIOS function that offers protection against unauthorised access regardless of the operating system used. After the feature has been activated with a Fujitsu Siemens Memorybird, the system can only be started when this Memorybird is connected to one of the available USB ports.
  • Page 15: Brief Instructions On Installing Mainboard

    Equip the mainboard with the processor, heat sink and memory modules before installation if possible. Further information can be found in "Replacing processor" chapter. ► Open the casing as described in the operating manual. 6 - English A26361-D1875-Z120-1-6319, Edition: 1...
  • Page 16: Driver Installation

    Driver installation ► Install the drivers for the chipset. You may find the driver on the "Drivers & Utilities" CD. Please refer to chapter "Drivers" for a description of installing drivers. A26361-D1875-Z120-1-6319, Edition: 1 English - 7...
  • Page 17: Interfaces And Connectors

    (FIFO) and supports WOL function through Magic Packetä. The LAN RJ45 connector has two LEDs (light emitting diodes). LED 1 lights green: A connection exists (e.g. to a hub). flashes green: Activity LED 2 glows yellow: 100 Mbit/s off: 10 Mbit/s 8 - English A26361-D1875-Z120-1-6319, Edition: 1...
  • Page 18: Audio Ports And Audio Configuration

    Depending on driver, software or hardware version and operating system the functions may differ from this presentation. If necessary, further information is provided in the respective help system as well as in the "Audio configuration" section. A26361-D1875-Z120-1-6319, Edition: 1 English - 9...
  • Page 19: Internal Ports And Connectors

    An ultra ATA/66, ultra ATA/100 or ultra ATA/133 hard disk must be connected with a cable especially designed for the ultra ATA/66, ultra ATA/100 or ultra ATA/133 mode. ► Connect the end of the cable marked with blue to the mainboard. 10 - English A26361-D1875-Z120-1-6319, Edition: 1...
  • Page 20: Pin Assignment Of Internal Ports

    Power On LED Indicates the system state APM or ACPI (see chapter "APM and ACPI system status, energy-saving modes"). Password see "Settings with switches and jumpers" chapter Recovery see "Settings with switches and jumpers" chapter A26361-D1875-Z120-1-6319, Edition: 1 English - 11...
  • Page 21: Ide Interface

    Data 0 (high asserted) CS 1 (low asserted) Data 15 (high asserted) CS 3 (low asserted) IDE-LED (low asserted) Serial ATA (internal) Signal Signal Transmit data positive Transmit data negative Receive data negative Receive data positive 12 - English A26361-D1875-Z120-1-6319, Edition: 1...
  • Page 22: Floppy Interface

    Motor A Enable (low asserted) Write Protect (low asserted) Drive B Select (low asserted) Read Data (low asserted) Drive A Select (low asserted) Side 1 Select (low asserted) Motor B Enable (low asserted) Disk Change (low asserted) A26361-D1875-Z120-1-6319, Edition: 1 English - 13...
  • Page 23: Audio Front Panel

    Analogue VCC Right line output Right line return not connected Left line output Left line return If the audio front panel is not used, you must plug jumpers on pin pairs 5/6 and 9/10. 14 - English A26361-D1875-Z120-1-6319, Edition: 1...
  • Page 24 Fan 1 (CPU) (processor fan - only for 3 pin fans) Signal Controlled FAN voltage (0V, +6V, ... +12V, max. 1A) or fix Fan voltage (+12 V, max. 1 A) Fan sense A26361-D1875-Z120-1-6319, Edition: 1 English - 15...
  • Page 25 -12V (P12VN) +5V (VCC) PS on (low asserted) +5V (VCC) Powergood (high asserted) -5V (5PVN) +5V Auxiliary (VCC Aux) +5V (VCC) +12V (P12VP) +5V (VCC) Power supply ATX12 V Signal Signal +12 V +12 V 16 - English A26361-D1875-Z120-1-6319, Edition: 1...
  • Page 26: Settings With Switches And Jumpers

    Pin pair A inserted = Skipping system and BIOS Setup password Pin pair B inserted = System BIOS recovery Pin pair C inserted = factory setting Please pay attention on the exact position of the pin pairs! A26361-D1875-Z120-1-6319, Edition: 1 English - 17...
  • Page 27 Diskette" restores the System BIOS on the mainboard. Off / not inserted Normal operation (default setting). Reserved - switch 3 and switch 4 (if present) Switch 3 and 4 are reserved. The position of the switch doesn't matter. 18 - English A26361-D1875-Z120-1-6319, Edition: 1...
  • Page 28: Add-On Modules / Upgrading

    (A) with regard to the position (4). The angled corner of the processor can also be at a different location than shown in the illustration. ► Push the lever back down until it clicks into place (5). A26361-D1875-Z120-1-6319, Edition: 1 English - 19...
  • Page 29: Mounting Heat Sink

    Depending on the processor variant, clips may also be supplied for mounting the heat sink that fix it in place. When you have mounted the optional fan, Ê connect the fan plug to the corresponding connection on the mainboard. 20 - English A26361-D1875-Z120-1-6319, Edition: 1...
  • Page 30: Upgrading Main Memory

    Push the holders on each side of the memory slot outwards. ► Insert the memory module into the location (1). ► At the same time flip the lateral holders upwards until the memory module snaps in place (2). A26361-D1875-Z120-1-6319, Edition: 1 English - 21...
  • Page 31: Upgrading Agp Screen Controllers

    3.3 V AGP graphics cards can cause serious damage to the mainboard and the AGP graphics cards. Adding PCI cards Technical data: 32 bit / 33 MHz PCI slots 5 V and 3.3 V supply voltage 3.3 V auxiliary voltage 22 - English A26361-D1875-Z120-1-6319, Edition: 1...
  • Page 32: Pci Bus Interrupts - Selecting Correct Pci Slot

    PCI slot with IRQ sharing, check whether the expansion card properly supports IRQ sharing with the other devices on this PCI IRQ Line. The drivers of all cards and components on this PCI IRQ Line must also support IRQ sharing. A26361-D1875-Z120-1-6319, Edition: 1 English - 23...
  • Page 33: Replacing The Lithium Battery

    Press the locking lug in the direction of the arrow; the battery jumps somewhat out of the holder (1). ► Remove the battery (2). ► Push the new lithium battery of the identical type into the holder (3) and press it downward until it engages (4). 24 - English A26361-D1875-Z120-1-6319, Edition: 1...
  • Page 34: Bios Update

    BIOS update BIOS update When should a BIOS update be carried out? Fujitsu Siemens Computers makes new BIOS versions available to ensure compatibility to new operating systems, new software or new hardware. In addition, new BIOS functions can also be integrated.
  • Page 35: Bios Recovery - Recovering System Bios

    Save the change and terminate BIOS Setup . The BIOS recovery has now been completed. The system restarts. Detailed information on the BIOS recovery is contained in the manual "BIOS Setup" ("Drivers & Utilities" CD). 26 - English A26361-D1875-Z120-1-6319, Edition: 1...
  • Page 36: Microcode Update

    Intel refers to the use of the processor without microcode updates as operation outside the specifications. Safety for processor on Fujitsu Siemens Computers mainboards If the processor uses an old or incorrect microcode, error-free operation cannot be ensured. Fujitsu Siemens Computers has therefore implemented a function on its mainboards that interrupts the booting process if no suitable microcode is available for the installed processor.
  • Page 37: Drivers

    Insert the CD "Drivers & Utilities Collection" into the CD-ROM drive. ► If the CD does not start automatically, run the START.EXE programme in the main directory of the CD. ► Select DeskUpdate - Fully automatic installation . ► Follow the instructions on screen. 28 - English A26361-D1875-Z120-1-6319, Edition: 1...
  • Page 38: Annex

    Mainboard current requirement You require a Pentium4 power supply nit as per the ATX12V specification for this mainboard. If you do not have a PC from Fujitsu Siemens Computers, make sure that the power supply unit provides the required amperages.
  • Page 39: Apm And Acpi System Status, Energy-Saving Modes

    The power supply unit must provide sufficiently loadable 5 V standby voltage. To use the WOL functionality the power supply must provide a 5 V auxiliary voltage (5V SB) of at least 1 A. 30 - English A26361-D1875-Z120-1-6319, Edition: 1...
  • Page 40: Mainboard Revision And Bios Version

    . Mainboard Revision The revision status of the mainboard exactly identifies which mainboard you have. It is indicated on a sticker on the edge of the mainboard: D1875-C22 GS 1 05618476 Example Mainboard-Revision BIOS version The BIOS version can be displayed in the BIOS Setup .
  • Page 41: Error Messages

    Available CPUs do not support the same bus frequency - System halted! Memory type mixing detected Non Fujitsu Siemens Memory Module detected - Warranty void There are more than 32 RDRAM devices in the system Check whether the system configuration has changed. If necessary, correct the settings.
  • Page 42 Keyboard error Check that the keyboard is connected properly. Keyboard error nn nn Stuck Key Release the key on the keyboard ( nn is the hexadecimal code for the key). A26361-D1875-Z120-1-6319, Edition: 1 English - 33...
  • Page 43 = Group number x = Number of SEs found on the communication bus y = Number of SEs entered in Number of connected SE k1, k2 ... = Device ID of the storage extensions found 34 - English A26361-D1875-Z120-1-6319, Edition: 1...
  • Page 44 Switch the device off and on again. If the message is still displayed, please contact your sales outlet or customer service centre. Verify CPU frequency selection in Setup The frequency setting for the processor is invalid. Correct the BIOS Setup and the setting. A26361-D1875-Z120-1-6319, Edition: 1 English - 35...
  • Page 45: Glossary

    Graphics and Memory Controller SVGA Super Video Graphic Adapter TEMP Temperature Graphics Performance Universal Serial Bus Accelerator Hard Disk Drive Video Graphic Adapter Inter Integrated Circuit IAPC Instantly Available Power Wake On LAN Managed Desktop PC Design A26361-D1875-Z120-1-6319, Edition: 1 English - 36...
