Summary of Contents for Fujitsu Siemens Computers D1691
- Page 1 Technical Manual Mainboard D1691 English...
- Page 2 Are there ..any technical problems or other questions you need clarified? Please contact: • your sales partner • your sales outlet The latest information and updates (e. g. BIOS update) on our mainboards can be found on the Internet under: http://www.fujitsu-siemens.com...
- Page 4 Questo manuale è stato stampato su carta da riciclaggio. Denna handbok är tryckt på recyclingpapper. Dit handboek werd op recycling-papier gedrukt. Herausgegeben von/Published by Fujitsu Siemens Computers GmbH Bestell-Nr./Order No.: A26361-D1691-Z120-1-7619 Printed in the Federal Republic of Germany AG 0604...
-
Page 5: Mainboard D1691
English Mainboard D1691 Technical Manual June 2004 edition... - Page 7 Copyright ã Fujitsu Siemens Computers GmbH 2004 All rights, including rights of translation, reproduction by printing, copying or similar methods, even of parts are reserved.
-
Page 9: Table Of Contents
3.5 - Memory Installation Procedure ....................21 3.6 - Installing the Processor and Heatsink..................22 3.7 - Attaching Drive Cables ......................24 3.8 - Installing Add-In Cards ......................26 3.9 - Connecting External Devices....................27 3.10 - Installing the Power Supply....................27 3.11 - Finishing Up ..........................28 A26361-D1691-Z120-1-7619, Edition 1... - Page 10 Chapter 5: Diagnostics ......................... 53 5.1 - Beep Codes ..........................53 5.2 - Flash Utility ..........................53 Appendix I: Glossary........................54 Appendix II: Post Error Code for BIOS ..................60 Appendix III: SMDC Information....................65 Technical Support ........................... 66 A26361-D1691-Z120-1-7619, Edition 1...
-
Page 11: Mainboard D1691
This symbol indicates that you must press the Enter key. Text in this typeface indicates screen outputs. Text in this bold typeface indicates the entries you make via the keyboard. Text in italics indicates commands or menu items. "Quotation marks" indicate names of chapters or terms. A26361-D1691-Z120-1-7619, Edition 1... -
Page 12: Important Notes
The equipment and tools you use must be free of static charges. • Remove the power plug from the mains supply before inserting or removing boards containing ESDs. • Always hold boards with ESDs by their edges. • Never touch pins or conductors on boards fitted with ESDs. A26361-D1691-Z120-1-7619, Edition 1... -
Page 13: Before You Begin
1x I/O shield 1 x Serial ATA driver diskette 1 x Serial ATA power cable 2 x Serial ATA cables If any of these items are missing, please contact your vendor/dealer for replacement before continuing with the installation process. A26361-D1691-Z120-1-7619, Edition 1... -
Page 14: Chapter 1: Introduction
Visit Tyan’s website at http://www.tyan.com. There, you can find information on all of Tyan’s products with up-to-date FAQs, a list of worldwide distributors, Tyan software utilities, the latest drivers, memory compatibility listings, and BIOS setting explanations. A26361-D1691-Z120-1-7619, Edition 1... -
Page 15: Hardware Specifications
Four USB2.0 ports (2 front USB ports via ● Dual channel memory bus an optional cable) ● Supports ECC or non-ECC memory ● PS/2 mouse & keyboard ports ● Up to 16GB of Registered DDR-II DDR modules A26361-D1691-Z120-1-7619, Edition 1... -
Page 16: Software Specifications
● Microsoft Windows NT4.0 ● Red Hat 8.0, 9.0 ● SuSE Server 8.0 ● Other distributions of Linux pending validation TYAN reserves the right to add support or discontinue support for any OS with or without notice. A26361-D1691-Z120-1-7619, Edition 1... -
Page 17: Board Diagram
The above picture is purely representative. Due to engineering updates and new board revisions, certain components may change and or be repositioned. The picture above may or may not look exactly like the board you received. The following page includes details on the vital components of this motherboard. A26361-D1691-Z120-1-7619, Edition 1... -
Page 18: Chapter 2: Choose Proper Parts For Your System
FSB frequency, core frequency, and have the same internal cache sizes. Mixing processors operating at different FSB frequency, core frequency, or cache sizes may cause system non-operation or damages on processors and/or the motherboard. A26361-D1691-Z120-1-7619, Edition 1... -
Page 19: Memory Considerations
6 motherboard-mounting holes and 8 CPU heat-sink mounting holes, should be removed to preventing from short-circuit or motherboard damage. ● Others As a system integrator, the air-flow/thermal, EMI/EMC, shock/vibration, and system packing should be also considered for choosing a proper enclosure. A26361-D1691-Z120-1-7619, Edition 1... -
Page 20: Power Supply Considerations
24-pin and 6-pin power connectors 32-bit PCI +12V, +5V and +3.3V 24-pin and 6-pin power connectors Cooling fans +12V 24-pin and 6-pin power connectors IDE/SATA hard drives +12V and +5V From PSU CDROM/DVD drives +12V and +5V From PSU A26361-D1691-Z120-1-7619, Edition 1... -
Page 21: Chapter 3: Board Installation
In last sections of this chapter, we will cover the details on how to install your motherboard into your chassis, as well as installing the processor, memory, disk drives and cables. Note: DO NOT APPLY POWER TO THE BOARD IF IT HAS BEEN DAMAGED A26361-D1691-Z120-1-7619, Edition 1... -
Page 22: Key Component View
This jumper diagram is representative of the latest board revision available at the time of publishing. The board you receive may or may not look exactly like the above diagram. The board parts are not to scale. A26361-D1691-Z120-1-7619, Edition 1... -
Page 23: Jumper Settings & Definitions
BIOS write protect J104 LCD connector J106 TPM Disable J107 Clear CMOS J108 PSU PC98 Connector J109 FAN 1Connector J110 FAN 2 Connector J111 FAN 4 Connector J112 FAN 3 Connector J113 SPDIF J114 LAN Disable J137 A26361-D1691-Z120-1-7619, Edition 1... -
Page 24: Clear Cmos Switch
There are three 3-pin fan connectors on Thunder i7525 S2676 board. Use these connectors to connect chassis and processor cooling fans to your motherboard. Cooling fans can keep the system stable and reliable for its product’s life. A26361-D1691-Z120-1-7619, Edition 1... -
Page 25: Front Panel Header
The front panel header (marked as "P5") has been implemented on Thunder i7525 S2676 board for such purposes. Front Panel Header (J86) Function PIN # PIN # Function HDD LED+ LED_GRN HDD LED# LED_YEL GND1 FP_PBTN# FP_RESET GND2 FP_SLP# IRRX GND3 GND4 IRTX IR_PWR RSVD1 RSVD2 A26361-D1691-Z120-1-7619, Edition 1... -
Page 26: Front Usb Connector (Usb2)
Chapter 3: Board Installation 3.2.4 - Front USB Connector (USB2) Front USB Header (P24) Function Pin# Pin# Function Power Power USB6- USB7- USB6+ USB7+ Reserved 3.2.5 - External HDD LED Input Header (P29) Pin# Function LED2- LED2- A26361-D1691-Z120-1-7619, Edition 1... -
Page 27: Serial Ata Connectors (Sata0 & Sata1)
Windows 2000 operating systems. SATA0 & SATA1 Serial ATA connectors For information regarding the setup of SATA/RAID, you may search the contents of the driver CD that shipped with your motherboard or visit our website at: HTTP://WWW.TYAN.COM/ A26361-D1691-Z120-1-7619, Edition 1... -
Page 28: Mounting The Motherboard
The Thunder i7525 S2676 supports DDR-II Registered type memory modules and requires minimum two memory modules to power up the system. Unbuffered or DDR-I Memory is NOT supported. Below is a chart detailing what the most common motherboard studs look like and how they should be installed it. A26361-D1691-Z120-1-7619, Edition 1... -
Page 29: Mounting The Motherboard
Although the plastic studs are usable, TYAN recommends using metal studs with screws that will fasten the motherboard more securely in place. TIP: Use metal studs if possible, as they hold the motherboard into place more securely than plastic standoffs. A26361-D1691-Z120-1-7619, Edition 1... -
Page 30: Installing The Memory
NOTE: While using ECC type memory, it will take longer time to post. Due to the manner in which it counts the memory and has to write zero’s to every bit of the stick before progressing through the POST. A26361-D1691-Z120-1-7619, Edition 1... -
Page 31: Memory Installation Procedure
Note: You MUST unplug the power connector to the motherboard before performing system hardware changes, to avoid damaging the board or expansion device. A26361-D1691-Z120-1-7619, Edition 1... -
Page 32: Installing The Processor And Heatsink
Because there are many different types of heatsinks available from many different manufacturers, a lot of them have their own method of installation. For the safest method of installation and information on choosing the appropriate heatsink, please refer to INTEL’s website at www.Intel.com. A26361-D1691-Z120-1-7619, Edition 1... -
Page 33: Heatsink Installation
Then proceed to installing the heatsink. securing it down to avoid damaging the Instructions on how to install heatsinks should be processor, the heatsink or both. provided with the heatsink itself. A26361-D1691-Z120-1-7619, Edition 1... -
Page 34: Attaching Drive Cables
The BLUE connector that is furthest away from the other two is the end that connects to the motherboard. The other two connectors are used to connect to drives. TIP: Pin 1 on the IDE cable (usually designated by a colored wire) faces the drive’s power connector. A26361-D1691-Z120-1-7619, Edition 1... - Page 35 Refer to your floppy drive’s installation instructions (if available), or contact your dealer if you are unsure about how to attach the floppy drive(s). Remember, you can only have 2 floppy drives connected at any given time. A26361-D1691-Z120-1-7619, Edition 1...
-
Page 36: Installing Add-In Cards
This allows air to more easily circulate within the chassis, providing improved cooling for all installed devices. Note: YOU MUST unplug the power connector to the motherboard before performing system hardware changes, to avoid damaging the board or expansion device. A26361-D1691-Z120-1-7619, Edition 1... -
Page 37: Connecting External Devices
CPU +12V regulator power source. Therefore, the CPU will not be powered if you do not connect the 8-pin square 12V power connector. NOTE: YOU MUST unplug the power supply before plugging in the 24-pin and 8-pin power cables to motherboard connectors. A26361-D1691-Z120-1-7619, Edition 1... -
Page 38: Finishing Up
In the rare circumstance that you have experienced difficulty, you can find help by asking your vendor for assistance. If they are not available for assistance, please find setup information and documentation online at our website or by calling your vendor’s support line. A26361-D1691-Z120-1-7619, Edition 1... -
Page 39: Chapter 4: Bios Setup
The table below shows how to navigate in the setup program using the keyboard. Function Moves from one selection to the next Left/Right Arrow Keys Change from one menu to the next Up/Down Arrow Keys More between selections Enter Opens highlighted section PgUp/PgDn Keys Change settings. A26361-D1691-Z120-1-7619, Edition 1... -
Page 40: Getting Help
Your system designer may decide that certain items should not be available for user configuration, and remove them from the BIOS setup program. NOTE: On the following pages, options written in bold type represent the BIOS Setup default. A26361-D1691-Z120-1-7619, Edition 1... -
Page 41: Main Bios Setup
<Tab>, <Shift-Tab> or <Enter> selects field. System Date: 01/01/1980 ... 12/31/2079 <Tab>, <Shift-Tab> or <Enter> selects field. Legacy Diskette A: Disabled Selects floppy type. 360 KB 5¼" 1.2 MB 5¼" 720 KB 3½" 1.44/1.25 MB 3½" 2.88 MB 3½" A26361-D1691-Z120-1-7619, Edition 1... - Page 42 Select the operating system installed on your system which you will use Windows 32 bit most commonly. Windows 64 bit Note: An incorrect setting Linux can cause some operating systems to display unexpected behaviour. System Information View system information. A26361-D1691-Z120-1-7619, Edition 1...
-
Page 43: Main Submenu Standard / Native Ide
PIO 4 PIO 5 (only view the current setting, it should not be selectable!!) DMA Mode: None UDMA 1 UDMA 2 UDMA 3 UDMA 4 UDMA 5 (only view the current setting, it should not be selectable!!) A26361-D1691-Z120-1-7619, Edition 1... -
Page 44: Main Submenu System Information
Must reflect the Build date of the current installed BIOS version. Format must be MM/DD/YYYY Ident-Nr.: System: System Version: System Serial: Board: Board Version: Asset Tag: MAC Address: Must display the MAC address of the onboard LAN. A26361-D1691-Z120-1-7619, Edition 1... -
Page 45: Advanced Bios Features
Reset Configuration Data: Select 'Yes' if you want to clear the Extended System Configuration Data (ESCD) area. In Advanced BIOS features, you will be able to adjust many of the feature that effect system speed and boot-up options. A26361-D1691-Z120-1-7619, Edition 1... -
Page 46: Advanced Submenu Hardware Monitoring
Please display all available sensors on All items on this menu can board and describe them clear (e.g. not be modified. CPU1 settings missing or how can I determine which one is ADT1 and which one is ADT0?). A26361-D1691-Z120-1-7619, Edition 1... -
Page 47: Advanced Submenu Bios Event Logging
View BIOS Event Log: Enter Select <Enter> to view the content of the BIOS event log. Clear BIOS Event Log: Disabled Setting this to enabled, will clear BIOS event log after rebooting the system. Enabled A26361-D1691-Z120-1-7619, Edition 1... -
Page 48: Advanced Submenu Processors
Display the current maximum FSB speed CPU1 Type: Display the current installed CPU type CPU1 Speed: Display the current installed CPU speed CPU1 ID: Display the current installed CPU ID CPU1 Patch ID: Display the current installed Patch ID A26361-D1691-Z120-1-7619, Edition 1... -
Page 49: Advanced Submenu Chipset
Disabled selection enables ECC mode. 4.3.6 - Advanced Submenu Diskette Controller Diskette Controller: [Enabled] Setup Item Selections Item Specific Help (Default values are in bold) Diskette Controller: Enabled Enable/Disable the floppy disk controller. Disabled A26361-D1691-Z120-1-7619, Edition 1... -
Page 50: Advanced Submenu Ata Controller
S-ATA Mode: Compatible [Compatible] Serial ATA is mapped to the standard IDE drive interface. RAID [RAID] Requires two identical SATA drives. Native [Native] Serial ATA configured in native mode. Some operating systems do not support native IDE devices. A26361-D1691-Z120-1-7619, Edition 1... -
Page 51: Advanced Submenu Integrated Scsi Controller
Enables the onboard LAN Disabled controller. Option ROM Scan: Enabled Initialize device expansion Disabled ROM. Latency Timer: Default Minimum guaranteed time slice 0020h allotted for bus master in units 0040h of PCI bus clocks. 0060h 0080h 00A0h 00C0h 00E0h A26361-D1691-Z120-1-7619, Edition 1... -
Page 52: Advanced Submenu Integrated Audio
Integrated USB 1.1: Enabled Enables or Disables the USB hardware. Disabled Integrated USB 2.0: Enabled Enables or Disables the USB 2.0 hardware. Disabled USB Legacy Enabled Enable legacy keyboard support for the Universal Support: Disabled Serial Bus. A26361-D1691-Z120-1-7619, Edition 1... -
Page 53: Advanced Submenu I/O Device Configuration
Set the base I/O address for the serial port. Address: Interrupt: IRQ3 Set the IRQ for the serial port. IRQ4 Parallel Port: Configure parallel port using options: Auto [Auto] BIOS or OS chooses configuration. Enabled [Enabled] User configuration Disabled [Disabled] No configuration A26361-D1691-Z120-1-7619, Edition 1... -
Page 54: Advanced Submenu Pci Configuration
Configuration of the Specific PCI device. PCI Device, Slot #4 Configuration of the Specific PCI device. PCI Device, Slot #5 Configuration of the Specific PCI device. PCI/PNP IRQ Exclusion Reserve specific IRQs for use by legacy devices. A26361-D1691-Z120-1-7619, Edition 1... -
Page 55: Advanced Pci Configuration Submenu Pci Device, Slot #X
(Default values are in bold) Option ROM Scan: Enabled Initialize device expansion ROM. Disabled Latency Timer: Default Minimum guaranteed time slice allotted for bus master in units 0020h of PCI bus clocks. 0040h 0060h 0080h 00A0h 00C0h 00E0h A26361-D1691-Z120-1-7619, Edition 1... -
Page 56: Advanced Pci Configuration Submenu Pci/Pnp Irq Exclusion
Reserved IRQ7 Available Reserves the specified IRQ for use by legacy devices. Reserved IRQ10 Available Reserves the specified IRQ for use by legacy devices. Reserved IRQ11 Available Reserves the specified IRQ for use by legacy devices. Reserved A26361-D1691-Z120-1-7619, Edition 1... -
Page 57: Security Menu
Set User Password: Enter User Password controls access to the system at boot. Use at least 4 characters for the password; otherwise the system can be tampered easily. Password on boot: Disabled Enable/Disable password entry on boot. Enabled A26361-D1691-Z120-1-7619, Edition 1... - Page 58 When set to enabled the BIOS Flash Memory will be write protected. Enabled Cabinet Monitoring: Disabled When enabled, the system’s housing is monitored. Enabled Trusted Platform Disabled Allows to enable the Trusted Platform Module Module: (TPM). Enabled A26361-D1691-Z120-1-7619, Edition 1...
-
Page 59: Power Menu
Minimum Power Savings [Minimum Power Saving] Maximum power consumption. Standby Timeout: Disabled Time the system is inactive before entering Standby mode. In Standby mode the screen 2 min is dark. 5 min 10 min 15 min 30 min A26361-D1691-Z120-1-7619, Edition 1... - Page 60 Enabled Power Failure After recovery form power failure: Recovery: Last State [Last State] Switch to the state the system was in before power failure. Stay Off [Stay off] Switch off. Power On [Power On] Switch on. A26361-D1691-Z120-1-7619, Edition 1...
-
Page 61: Boot Menu
Allows you to bypass the normal sequence of boot devices. Before Disabled loading the OS press <F12> and select an alternate boot device from a menu. Boot Device Priority Select which order the BIOS should use between devices when trying to boot. A26361-D1691-Z120-1-7619, Edition 1... -
Page 62: Boot Submenu Boot Device Priority
Exit System Setup and save your changes to CMOS. Discard Changes & Exit Exit utility without saving Setup data to CMOS. Get Default Values Load default values for all Setup items. Load Previous Values Load Previous values from CMOS for all Setup items. A26361-D1691-Z120-1-7619, Edition 1... -
Page 63: Chapter 5: Diagnostics
BIOS. There are no exceptions. TYAN does not have a policy for replacing BIOS chips directly with end users. In no event will TYAN be held responsible for damages done by the end user. A26361-D1691-Z120-1-7619, Edition 1... -
Page 64: Appendix I: Glossary
Bus: a data pathway. The term is used especially to refer to the connection between the processor and system memory, and between the processor and PCI or ISA local buses. Bus mastering: allows peripheral devices and IDEs to access the system memory without going through the CPU (similar to DMA channels). A26361-D1691-Z120-1-7619, Edition 1... - Page 65 DRAM three to ten times slower than non-recharged RAM such as SRAM. ECC (Error Correction Code or Error Checking and Correcting): allows data to be checked for errors during run-time. Errors can subsequently be corrected at the same time that they’re found. A26361-D1691-Z120-1-7619, Edition 1...
- Page 66 Initial Program Load (IPL): a feature built into BBS-compliant devices, describing those devices as capable of loading and executing an OS, as well as being able to provide control back to the BIOS if the loading attempt fails. IPL: see Initial Program Load. A26361-D1691-Z120-1-7619, Edition 1...
- Page 67 Plug-n-Play aware operating system (such as Windows 98), and go to work. Devices and operating systems that are not Plug-n-Play require you to reconfigure your system each time you add or change any part of your hardware. A26361-D1691-Z120-1-7619, Edition 1...
- Page 68 SIMM (Single In-line Memory Module): formally the most common form of RAM for motherboards. They must be installed in pairs, and do not have the carrying capacity or the speed of DIMM modules. Sleep/Suspend mode: in this mode, all devices except the CPU shut down. A26361-D1691-Z120-1-7619, Edition 1...
- Page 69 CPU pins. The CPU is lightly placed in an open ZIF socket, and a lever is pulled down. This shift the processor over and down, guiding into the board and locking it into place. A26361-D1691-Z120-1-7619, Edition 1...
-
Page 70: Appendix Ii: Post Error Code For Bios
14h: Program chipset default values into chipset. Chipset default values are MODBINable by OEM customers. 16h: Initial onboard clock generator if Early_Init_Onboard_Generator is defined. See also POST 26h. A26361-D1691-Z120-1-7619, Edition 1... - Page 71 2. Put information on screen display, including Award title, CPU type, CPU speed, full screen logo. 33h: Reset keyboard if Early_Reset_KB is defined e.g. Winbond 977 series Super I/O chips. See also POST 63h. 35h: Test DMA Channel 0 A26361-D1691-Z120-1-7619, Edition 1...
- Page 72 1. Initialize Init_Onboard_Super_IO 2. Initialize Init_Onbaord_AUDIO. 60h: Okay to enter Setup utility; i.e. not until this POST stage can users enter the CMOS setup utility. 63h: Reset keyboard if Early_Reset_KB is not defined. 65h: Initialize PS/2 Mouse A26361-D1691-Z120-1-7619, Edition 1...
- Page 73 Switch back to text mode if full screen logo is supported. – If errors occur, report errors & wait for keys – If no errors occur or F1 key is pressed to continue: w Clear EPA or customization logo. A26361-D1691-Z120-1-7619, Edition 1...
- Page 74 Update keyboard LED & typematic rate 96h: Build MP table Build & update ESCD Set CMOS century to 20h or 19h Load CMOS time into DOS timer tick Build MSIRQ routing table. FFh: Boot attempt (INT 19h) A26361-D1691-Z120-1-7619, Edition 1...
-
Page 75: Appendix Iii: Smdc Information
By adding SMDC, Tyan’s server board becomes a highly manageable and IPMI compatible system with all the advanced features suggesting in IPMI Spec. More detailed information on Tyan’s SMDC card can be found on our website: http://www.tyan.com A26361-D1691-Z120-1-7619, Edition 1... -
Page 76: Technical Support
Return Merchandise Authorization (RMA) number. The RMA number should be prominently displayed on the outside of the shipping carton and the package should be mailed prepaid. TYAN will pay to have the board shipped back to you. A26361-D1691-Z120-1-7619, Edition 1... - Page 77 Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by manufacturer. Dispose of used battery according to manufacturer instructions and in accordance with your local regulations. Document #: D1588 - 100 A26361-D1691-Z120-1-7619, Edition 1...
