DMZ Settings

A DMZ (demilitarized zone) is a computer host or small network inserted as 'neutral
territory' between a private LAN and the Internet. It prevents outside users from
getting direct access to LAN computers while still being able to access services
hosted on the designated DMZ Computer.
When using NAPT to share your internet connection, LAN computers will still be able
to access the Internet when the DMZ host is enabled. Any direct communication
to the WAN port of your Modem that is not a reply to the original NAPT request is
forwarded to the DMZ host.
Option
Select your WAN
Connection:
Select LAN group:
Select a LAN IP
Address:
LAN Clients:
Click the Apply button to save the settings.To remove a rule from the Applied Rules
box, select the Rule and click on the Remove Button.
To save changes, click on Apply.
YML754 Rev1
www.netcomm.com.au
Description
Select the connection to which your
DMZ client is connected to.
Select the LAN group in which you want
to place the DMZ client.
Select the LAN IP address of the DMZ
client.
Click the LAN clients hyperlink to manu-
ally add a LAN client.
NB5Plus4/W User Guide
53
