RJ11 connector and cable

An RJ-11 connector is the small, modular plug used for most analog telephones. It
has six pin slots in the head, but usually only two or four of them are used.

605 to RJ-11 adapter

The 605 to RJ-11 adaptor is provided to comply with the older
610 Telstra wall socket. The 605 to RJ-11 adapter may be used
to convert the supplied RJ-11 cable, if the older connection is
required.
NB5Plus4/W User Guide
100
RJ-11 Connector
Pin Assignment
1
2
3
4
5
6
Figure 5
Normal Assignment
Not Connected
Not connected
Line
Line
Not Connected
Not Connected
