Internal I/O Specifications - Maple Systems PLC-ES1616P User Manual

Items
Rated I/O
Voltage
(High Speed Counter)
Rated I/O
Current
CH1–4: DC 10 V/4 mA
On V/A
CH5–16: DC 14 V/4 mA
CH1–4: DC 6 V/1 mA
Off V/A
CH5–16: DC 12 V/1 mA
Response time
Operation
indicator
Insulation
method
Input method
Output method
Circuit Diagram

Internal I/O Specifications

DC Input
DC 24 V
DC 12 V/24 V
4 mA
3 ms or less
Input ON, LED ON
Photocoupler
insulation
Sink/Source
-
Relay Output
AC 220 V/DC 24 V
1 point 2 A/COM 5 A
-
-
10 ms or less
Input ON, LED ON
Relay insulation
-
Relay
12
TR Output
DC 24 V
1 point 0.2 A/COM 2 A
-
-
1 ms or less
Input ON, LED ON
Photocoupler
insulation
-
Source
