- Page 1 User manual Swing doors ASSA ABLOY SW300-S Experience a safer and more open world Original instructions...
-
Page 2: Document Identification
Version: Publication date: 2024-11-12 Content subject to change without notice. ASSA ABLOY as word and logo are trademarks owned by the ASSA ABLOY Group. Copyright © ASSA ABLOY. ® The Bluetooth word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by ASSA ABLOY is under license. -
Page 3: Table Of Contents
Table of Contents List of abbreviations ......................Safety............................Presentation of warning signs................General hazards....................... Product specific hazards..................12 Electronic equipment reception interference ..........12 State of technology ....................13 Personal protective equipment ................. 13 Product liability ....................... 13 Warranty ........................14 General information...................... - Page 4 Program selector (OFF/AUTO/OPEN) ............... 26 Inspection and maintenance ..................... 27 Inspection........................27 7.1.1 Daily inspection................27 7.1.2 Cleaning ....................28 Maintenance......................28 7.2.1 Maintenance intervals..............28 Troubleshooting........................30 Troubleshooting...................... 30 Taking out of service and disposal..................31 Decommissioning....................31 Dismantling and disposal..................31 4/32 2024-11-12 1023429_en_3.0...
-
Page 5: List Of Abbreviations
List of abbreviations Declaration of Conformity Ecology Hold Open Time Push and Go Protective earth 1023429_en_3.0 2024-11-12 5/32... -
Page 6: Safety
1 Safety 1.1 Presentation of warning signs DANGER Warning against an imminent or latent hazardous situation that can lead to electric shock and cause serious injury or death. DANGER Warning against an imminent hazardous situation that can lead to severe injury or death. WARNING Warning against a latent hazardous situation that can lead to severe injuries or death and cause substantial property damage. - Page 7 DANGER Electric current. In case of contact with live parts, there is an immediate danger to life because of electric shock. Damage to or removal of the insulation or individual components can be life-threatening. • Make sure that only approved personnel work on the electrical system. •...
- Page 8 DANGER Faulty safety devices of the fire protection system. Danger to life if the safety devices of the fire protection system do not work. This can cause severe injuries or death. • Do not disconnect the fire protection system from the power supply overnight. •...
- Page 9 Make sure that all connection points between the door system and the building are suffi- ciently strong, even and level. • Only use ASSA ABLOY approved components. Other components may have a negative ef- fect on the safety of the system. WARNING Heavy parts.
- Page 10 WARNING Locked in persons in the building. Risk of personal injuries and material damage. • Before the system is set to locked, make sure that the locked area is empty and that no persons are locked in. WARNING The system can open, close, or turn unexpectedly. Risk of material damage or personal injuries because of unforeseen opening, closing, or turning of the system.
- Page 11 CAUTION Insufficient cleaning or care. Insufficient or inattentive cleaning or care of the system can lead to malfunctions, material damage or personal injuries. • Examine the sensors regularly for dirt and clean them if necessary. • Regularly remove dirt accumulations from the product and its close surroundings, for ex- ample the floor, in the floor rail, or under the floor mat.
-
Page 12: Product Specific Hazards
• The system or the battery can not be in excessive temperatures. • Only use ASSA ABLOY approved batteries. Other batteries can have a negative effect on the safety of the system. 1.4 Electronic equipment reception interference The equipment can generate and use radio frequency energy. If the equipment is not installed and used prop- erly it can cause interference to radio, television reception or other radio frequency type systems. -
Page 13: State Of Technology
Turn the equipment ON and OFF to determine interference. Reorient the receiving antenna. Move the receiver with respect to the equipment. Move the receiver away from the equipment. Connect the receiver into a different outlet so that equipment and receiver are on different branch cir- cuits. -
Page 14: Warranty
1.8 Warranty ASSA ABLOY warrants its products to be free from defects in material and workmanship under intended use and service for a warranty time of 12 months, beginning at time of delivery. This warranty extends only to the original buyer of the equipment. -
Page 15: General Information
2 General information 2.1 Terms and definitions Term Definition Approved personnel Authorised personnel are entitled to perform the following work: • Disassembly • Assembly • Commissioning • Operation • Audit • Maintenance • Troubleshooting • Decommissioning The approved personnel have several years of professional experience in the technical field, for example, as mechanics or machine fitters. -
Page 16: Purpose And Use Of The Instructions
The manual can be handed over in extracts to instructed personnel who are familiar with the operation of the system. The illustrations are for basic understanding and may differ from the actual presentation. Specific representa- tions are contained in the drawings. 2.3 Manufacturer ASSA ABLOY Entrance Systems Box 131 SE-261 22 Landskrona Sweden Phone: +46 10 4747 000 2.4 Target groups... -
Page 17: Description
The ASSA ABLOY SW300-S is an automatic swing door operator developed to make life easier for everyone who can benefit from automatic doors. The ASSA ABLOY SW300-S is a low-energy as well as a full power operator us- ing a DC motor and a gear-reduction system to drive an arm system, which opens the door. It is to be installed indoors where it is suitable for almost all types of external and internal swing doors. -
Page 18: Overview
3.2 Overview Item Description Item Descriptions Operator Door seals Arm system Finger protection Cables Lock Program selector Manual activation unit Hinges Automatic activation unit Door and glass Safety sensor Door leaf and door frame Mains power supply 18/32 2024-11-12 1023429_en_3.0... -
Page 19: Signage
3.3 Signage CAUTION Without marking on the moving door leaf the glass pane is difficult to see. Risk of personal injuries or material damages. • It is a requirement in EN 16005 that the glass surface is clearly recognizable, for example with markings or stickers. Always place marking on the moving leaf. •... -
Page 20: Function Description
3.4 Function description The swing door operator ASSA ABLOY SW300-S uses a DC motor and a gear reduction system to drive an arm system which opens the door. Closing power is controlled by a motor and a closing spring. A highly sophistic- ated electronic control unit uses a motor encoder and a microprocessor to control the door’s movement. - Page 21 The operator ASSA ABLOY SW300-S can be set in three or four different modes, refer to 6.1 Program selector (OFF/AUTO/OPEN) on page 26 4.1 Program selector (PS-4C) on page 22. In fully manual use (or in case of a power failure) the operator ASSA ABLOY SW300-S acts as a door closer. 1023429_en_3.0 2024-11-12 21/32...
-
Page 22: Options
The system complies with all applicable safety regulations, but it is possible to enhance the safety and comfort with the add-ons. Contact the local ASSA ABLOY company for a detailed description. 4.1 Program selector (PS-4C) PS-4C has four modes and can also operate the electric lock. -
Page 23: Battery Back-Up Unit
4.4 Battery back-up unit DANGER Connection of the battery back-up unit • Disconnect mains when replacing battery back-up unit. • Risk of battery explosion if the wrong type of battery is used. 4.5 Battery management module 4.6 LED cable 1023429_en_3.0 2024-11-12 23/32... -
Page 24: Sensor
4.7 Sensor Alt. 2 Alt. 1 Option 1 Option 2 4.8 Reset and indication device for fire doors A Reset & Indication device Reset and indication device B Smoke detector Smoke detector 24/32 2024-11-12 1023429_en_3.0... -
Page 25: Specification
5 Specification 5.1 Technical specification Type ASSA ABLOY SW300-S Mains power supply 100-240 V AC ±10%, 50/60 Hz Mains fuse maximum 10 A (building installation) Power consumption 350 W Power save mode Maximum 0.3 W (with the ECO module) Temperature range -20°C to +45°C... -
Page 26: Operation
6 Operation 6.1 Program selector (OFF/AUTO/OPEN) Mode Function The door is closed and locked (if an electromechanical locking device has been fit- ted). The door can be opened with a key switch (if fitted). AUTO The door can be opened with the inner and outer manual and/or automatic activ- ators. -
Page 27: Inspection And Maintenance
When you have a service agreement with ASSA ABLOY , approved representatives do the service and adjust- ments. ASSA ABLOY makes sure that there is a safe and proper operation of your automatic door unit. Remember to keep the Maintenance documentation, the Site Acceptance Test, and the Risk Assessment docu- ments available. -
Page 28: Cleaning
Service and adjustments performed by your ASSA ABLOY representative will ensure safe and proper operation of your automatic door unit. This product may contain batteries that should only be replaced by an ASSA ABLOY trained and skilled techni- cian. Remember to keep “Service Log Book” and “Site Acceptance Test and Risk Assessment” documents (PRA-0007) available. - Page 29 Part Cycles/hour in operation Abusive environment <10 <100 >100 Medium High traffic traffic traffic Stop arm kit Battery assembly Transmission unit kit Control unit with the ECO module Control unit without the ECO module 1023429_en_3.0 2024-11-12 29/32...
-
Page 30: Troubleshooting
The door opens and closes continuously. • Make sure that there is no moving object within 1 to 1.5 m from the door if an automatic activa- tion unit is fitted. If the problem continues, please contact your ASSA ABLOY representative. 30/32 2024-11-12 1023429_en_3.0... -
Page 31: Taking Out Of Service And Disposal
9 Taking out of service and disposal 9.1 Decommissioning NOTICE After each temporary shutdown a new commissioning must be carried out. When the system is taken out of service: Disconnect the system from the mains supply. Unplug from any existing battery. 9.2 Dismantling and disposal NOTICE All parts must be separated, sorted by the type of material, and disposed of. - Page 32 ASSA ABLOY Entrance Systems is a leading supplier of entrance auto- mation solutions for efficient flow of goods and people. Building on the long-term success of the Besam, Crawford, Albany and Megadoor brands, we offer our solutions under the ASSA ABLOY brand. Our products and services are dedicated to satisfying end-user needs for safe, secure, convenient and sustainable operations.
