Chapter 3 – Specifications

MTSMC-L4xx and MTSMC-L4xx-U Specifications

Category
General
Standards
TCP/IP Functions
Frequency Bands
Speed
Data Speed
Interface
USB Interface
Serial Modem Interface Up to 921.6 Kbps
Physical Description
Weight
Dimensions
Connectors
Antenna Connector
SIM
Environment
Operating Temperature -40° C to +85° C
Storage Temperature
Humidity
Power Requirements
Input Voltage (USB
Models)
Input Voltage (Serial
Models)
®
SocketModem Cell MTSMC-L4N1 Device Guide for North America
Description
LTE FDD Cat 4, 3GPP release compliant
HSPA+ 21/GPRS fallback
USB Interface is CDC-ACM compliant
FTP, SMTP, SSL, TCP, UDP
4G: B2, B4, B5, B12, B13, B14, B66, B71
3G: B2, B4, B5
LTE: 150 Mbps downlink/50 Mbps uplink
DC HSPA+: 42 Mbps downlink
USB 2.0 HS/HSIC
0.4 oz. (10 g)
Refer to Mechanical Drawing for Dimensions.
2 surface mount UFL connectors for cellular and Rx diversity/MIMO.
1.8V and 3V SIM holder for mini-SIM card (2FF)
-40° C to +85° C
20%-90% RH, non-condensing
5.0 VDC
3.3 VDC or 5.0 VDC
SPECIFICATIONS
