- Page 1 ® MultiConnect Dragonfly MTQ-MNA1-B01 Device Guide...
- Page 2 Legal Notices The MultiTech products are not designed, manufactured or intended for use, and should not be used, or sold or re-sold for use, in connection with applications requiring fail-safe performance or in applications where the failure of the products would reasonably be expected to result in personal injury or death, significant property damage, or serious physical or environmental damage.
-
Page 3: Table Of Contents
CONTENTS Contents Chapter 1 – Product Overview ..........................6 Overview ..................................6 Documentation ................................6 Product Build Options ..............................6 Chapter 2 – MTQ-MNA1 Mechanical Drawing ......................7 Chapter 3 – Hardware and Specifications......................... 8 Specifications ................................8 40-Pin Connector Definitions ............................9 MTQ-xx-B01 ................................ - Page 4 CONTENTS Vehicle Safety................................20 Device Maintenance ..............................21 User Responsibility..............................21 Chapter 6 – Getting Started ..........................22 Installing a SIM Card on a DragonFly ......................... 22 Device Drivers ................................22 USB Cable Recommendations............................. 22 Communications Flow..............................23 Processor Model (B01).............................. 23 Communicating with the Device..........................
- Page 5 CONTENTS Registration of Substances............................34 Restriction of the Use of Hazardous Substances (RoHS) .................... 34 Chapter 11 – Using Connection Manager ....................... 36 Installing Connection Manager ........................... 36 Setting Up a Serial Device in Windows Device Manager.................... 37 Connecting a Device..............................39 Uninstalling Connection Manager..........................
-
Page 6: Chapter 1 - Product Overview
Telit ME910C1 AT Commands Lists AT commands and parameters used to configure your 80529ST10815A Reference Guide device. Rev 2 Note: Additional documentation is available on the mbed site and at www.multitech.net. See Getting Started with MTQ-MAT1-B01 for details. Product Build Options Product Description... -
Page 7: Chapter 2 - Mtq-Mna1 Mechanical Drawing
MTQ-MNA1 MECHANICAL DRAWING Chapter 2 – MTQ-MNA1 Mechanical Drawing ® MultiConnect Dragonfly MTQ-MNA1-B01 Device Guide... -
Page 8: Chapter 3 - Hardware And Specifications
HARDWARE AND SPECIFICATIONS Chapter 3 – Hardware and Specifications Specifications Category Description General Standards LTE UE Category M1, 3GPP release 13 compliant USB Interface is CDC-ACM compliant Frequency Bands AT&T Verizon 4G: 1900 (B2) / 700 (B12) /AWS 1700 (B4) 4G: 700 (B13) One, link status Speed... -
Page 9: 40-Pin Connector Definitions
HARDWARE AND SPECIFICATIONS Category Description Certifications and Compliance EMC and Radio FCC Part 15 Class B Compliance FCC Part 22 FCC Part 24 Safety Compliance UL/cUL 60950-1 2nd Edition Carrier AT&T/PTCRB/Verizon Note: Mbed has limited USB support for the processor. Software controls routing to processor or directly to radio. - Page 10 HARDWARE AND SPECIFICATIONS Signal Name Logic Level Voltage In/Out Description USB-DATA+ 0 - 3V USB-DATA- VCC-IN 4.35 - 5.25 Power Input Main Power IO_00 I = 0 - 7V, O = 0 - 3V General Purpose I/O from ST Microcontroller (STM 32F411) IO_01 IO_02 IO_03...
-
Page 11: 40-Pin Connector
HARDWARE AND SPECIFICATIONS Signal Name Logic Level Voltage In/Out Description SWDIO DBG_RX ST Micro UART debug Tx input A hyphen (-) indicates a range of acceptable logic levels. USB D+D-: 5V tolerant inputs / 3V drive-level output 40-Pin Connector Manufacturer: Hirose Electric Co LTD Description: Plug... - Page 12 HARDWARE AND SPECIFICATIONS Net Name Number Pin Name Details 26MHZ_CLK_DRIVE PH1-OSC_OUT Main Clock N_RESET NRST External Reset in IO_10 GPIO/Analog capable pin IO_11 GPIO/Analog capable pin IO_8 GPIO RADIO_PWR Voltage enable for Telit VSSA Power VDD3_3 VDDA Power IO_18/RTS GPIO/Analog capable pin/USART2_CTS IO_03/CTS GPIO/Analog capable pin/USART2_RTS IO_00/RXD...
-
Page 13: Serial Flash Embedded Memory
HARDWARE AND SPECIFICATIONS Net Name Number Pin Name Details RADIO_RXD Serial comm with the radio IO_17/SS2/SDIO_D0 GPIO/SDIO_D0 IO_14/SDIO_D1 GPIO/SDIO_D1 IO_20/DTR GPIO IO_19/DSR GPIO/SDIO_D2 USB_DIR/VBUS USB Switch control, 0=Telit, 1=STM FS_DM PA11 FS_DP PA12 J_TMS /SWDIO PA13 JTAG VCAP_2/VSS Power VDD3_3 VDD_2 Power J_TCK/SWCLK... -
Page 14: Electrical Characteristics
HARDWARE AND SPECIFICATIONS Erase capability Sector erase: 512Kb in 0.6 s (TYP) Bulk erase: 16Mb in 13 s (TYP) Write protection Hardware write protection (protected area size defined by non-volatile bits BP0, BP1, BP2) Deep power down: 1µA (TYP) Electronic signature JEDEC standard 2-byte signature (2015h) Unique ID code (UID) and 16 bytes of read-only data available upon customer request RES command, one-byte signature (14h) for backward compatibility... -
Page 15: Input/Output Current Ratings
HARDWARE AND SPECIFICATIONS Parameter Conditions Minimum Volts Maximum Volts Output low level voltage for an I/O pin =+4 mA Output high level voltage for an I/O pin -0.4 RESET (low active) input low CMOS port 0.99 =+8 mA RESET (low active) input high CMOS port 2.31 =+8 mA... -
Page 16: Chapter 4 - Antennas
The required antenna impedance is 50 ohms. External Antenna Option Wieson Antenna Devices were approved with the following antenna: Manufacturer: Wieson Description: LTE GY115HT467-017 Model Number: 11320Y11194A1 MultiTech ordering information: Model Quantity ANLTE2-1HRA ANLTE2-10HRA ANLTE2-50HRA Antenna Specifications Category Description Frequency Range .069~0.96GHz, 1.71~2.17GHz, 2.3GHz~2.69GHz... -
Page 17: Sma To U.fl Cables
ANTENNAS SMA to U.FL Cables The developer kit includes three 4.5" SMA to U.FL cables which are preinstalled on the developer board. Consult the mechanical drawings for your device to determine which antenna to connect to which U.FL connector on the device. -
Page 18: Fcc Grant Notes
ANTENNAS FCC Grant Notes The OEM should follow all the grant notes listed below. Otherwise, further testing and device approvals may be necessary. FCC Definitions Portable: (§2.1093) — A portable device is defined as a transmitting device designed to be used so that the radiating structure(s) of the device is/are within 20 centimeters of the body of the user. -
Page 19: Chapter 5 - Safety Information
SAFETY INFORMATION Chapter 5 – Safety Information Handling Precautions To avoid damage due to the accumulation of static charge, use proper precautions when handling any cellular device. Although input protection circuitry has been incorporated into the devices to minimize the effect of static build-up, use proper precautions to avoid exposure to electronic discharge during handling and mounting the device. -
Page 20: General Safety
SAFETY INFORMATION Éteignez votre appareil sans fil dans les hôpitaux ou dans toutes les zones où des appareils médicaux sont susceptibles d'être utilisés. General Safety The device is designed for and intended to be used in fixed and mobile applications. Fixed means the device is physically secured at one location and cannot be easily moved to another location. -
Page 21: Device Maintenance
Do not place the device alongside computer discs, credit or travel cards, or other magnetic media. The information contained on discs or cards may be affected by the device. Using accessories, such as antennas, that MultiTech has not authorized or that are not compliant with MultiTech's accessory specifications may invalidate the warranty. -
Page 22: Chapter 6 - Getting Started
If possible, use a USB port that connects directly to the motherboard rather than a USB port with added cabling inside the computer chassis. Use USB 3.0 ports if available. These ports are typically rated for more current. You can order the USB cable through MultiTech. The part number is CA-USB-A-MICRO-B-3. ® MultiConnect... -
Page 23: Communications Flow
USB connector on the device. There is no connection to pins 6 and 7 on the developer board. Establish serial communication using Multitech developer board MTUDK2. See the Universal Developer Kit 2.0 Developer Guide (PN S000610) for more information. -
Page 24: Powering Down Your Device
GETTING STARTED The device is configured for Verizon. To switch carrier networks: From AT&T to Verizon: AT#FWSWITCH=1,1 From Verizon to AT&T: AT#FWSWITCH=0,1 Note: For the Link status (LS) LED to function, you must issue the command AT#GPIO=1,0,2 any time you use the firmware switch command (AT#FWSWITCH=0 or AT#FWSWITCH=1). -
Page 25: Processor
GETTING STARTED Processor To reset the processor, the minimum recommended reset pulse is 200 μs. The maximum reset pulse is less than 1 second. Refer to STM32F411 documentation for additional reset options available within the on-board microcontroller. - Reset is controlled via PC13 on the on-board microcontroller. - Refer to 3G_ONOFF Signal for instructions on managing radio module reset. -
Page 26: Mbed Tm Documentation
Mbed Handbook: http://developer.mbed.org/handbook/Homepage Serial Flash Datasheet: https://www.micron.com/~/media/documents/products/data-sheet/nor-flash/serial- nor/m25p/m25p16.pdf Additional Information: http://www.multitech.net/developer/products/multiconnect-dragonfly/ MTQ Platform The MTQ Mbed page includes the MTSCellularInterface library and example programs. https://developer.mbed.org/platforms/MTS-Dragonfly ST Microelectronics STM32F411xC/E For information on the STM32F411xC/E microcontroller, refer to: Reference Manual: http://www.st.com/st-web- ui/static/active/en/resource/technical/document/reference_manual/DM00119316.pdf... -
Page 27: Chapter 7 - Verizon Fota Information
MultiTech has developed a script for customers to use in order to initiate a FOTA update from the (the customer’s) local host processor (pull FOTA). MultiTech LTE Category M1, Cat 1, and Cat 4 devices for Verizon will allow the customer to initiate a FOTA update from a remote server (push FOTA) as required and communicated by Verizon. - Page 28 VERIZON FOTA INFORMATION Before deploying devices with your Telit cellular radio module, create code in the host system code to perform the following sequence at a defined interval (nightly, weekly, daily, monthly). Issue following command to your cellular radio module to configure socket connection settings: AT#SCFG=1,3,300,90,600,50 If data APN has not previously been programmed, issue the following command: AT+CGDCONT=3,"IPV4V6","CorrectAPNForAccount"...
-
Page 29: Fota Client Example Session Log
VERIZON FOTA INFORMATION If version does not match value indicated in firmwarecheck.csv issue, appropriate commands listed earlier as needed in order to attempt to download and process the firmware file again. Issue following command to close FTP session: AT#FTPCLOSE Issue following command to close data session: AT#SGACT=3,0 End Process Note:... - Page 30 VERIZON FOTA INFORMATION [Tue Jan 09 13:18:26.159 2018] CONNECT [Tue Jan 09 13:18:26.237 2018] 30.00.001-B026_FOTA,30.00.001- B026_FOTA.bin,2017-01-31,204.26.122.49,USERNAME,PASSWORD [Tue Jan 09 13:18:26.253 2018] NO CARRIER [Tue Jan 09 13:18:26.767 2018] AT+GMR [Tue Jan 09 13:18:26.861 2018] 30.00.001-B026 [Tue Jan 09 13:18:26.861 2018] [Tue Jan 09 13:18:26.861 2018] OK [Tue Jan 09 13:18:27.742 2018] AT#CFVR [Tue Jan 09 13:18:27.750 2018] #CFVR: 1...
-
Page 31: Chapter 8 - Labels
This device is an industry and/or carrier approved modem. In most cases, when integrated and used with an antenna system that was part of the MultiTech modem certification, additional approvals or certifications are not required for the device that you develop as long as the following requirements are met: PTCRB Requirements: The antenna system cannot be altered. -
Page 32: Chapter 9 - Regulatory Information
REGULATORY INFORMATION Chapter 9 – Regulatory Information 47 CFR Part 15 Regulation Class B Devices This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 33: Fcc Grant Information
REGULATORY INFORMATION FCC Grant Information FCC Identifier: RI7ME910C1NA Equipment Class: PCS Licensed Transmitter Notes: ME910C1-NA LTE Module CAT M Approval: Single Modular FCC Rule Part Frequency Range Output Watts Frequency Tolerance Emission (MHz) Designator 699 - 716 0.22751 1.0 PM 1M17G7D 699 - 716 0.27861... -
Page 34: Chapter 10 - Environmental Notices
Substances) complements the WEEE Directive by banning the presence of specific hazardous substances in the products at the design phase. The WEEE Directive covers all MultiTech products imported into the EU as of August 13, 2005. EU-based manufacturers, distributors, retailers and importers are obliged to finance the costs of recovery from municipal collection points, reuse, and recycling of specified percentages per the WEEE requirements. - Page 35 2015/863 of the European Parliament (Restriction of the use of certain Hazardous Substances in electrical and electronic equipment - RoHS). These MultiTech products do not contain the following banned chemicals Lead, [Pb] < 1000 PPM Mercury, [Hg] <...
-
Page 36: Chapter 11 - Using Connection Manager
Click Connection Manager. Open or unzip the Connection Manager file and run the installer (.msi file). In the MultiTech Connection Manager Setup Wizard, read the end-user license agreement and check I accept the terms in the License Agreement. Click Next to have the installer automatically disable the native WWAN AutoConfig service in Windows. -
Page 37: Setting Up A Serial Device In Windows Device Manager
To specify a folder for Connection Manager, use the default folder or click Change to browse to the folder you want to use. Click Install. A separate wizard opens for installing Telit drivers. Some MultiTech devices use embedded modules from Telit Wireless Solutions to provide cellular connectivity; these devices require Telit drivers. Select Complete setup type. - Page 38 USING CONNECTION MANAGER In the Add Hardware Wizard: Click Next. Select Install the hardware that I manually select from a list, then click Next. Select Modems, then click Next. Check Don't detect my modem; I will select it from a list, then click Next. Select Standard Modem Types, then select Standard 33600 bps Modem on the right.
-
Page 39: Connecting A Device
USING CONNECTION MANAGER Connecting a Device Before You Begin Make sure that your device is connected to the computer where Connection Manager is installed. Set up the device in Device Manager. Refer to Setting Up a Serial Device in Windows Device Manager. -
Page 40: Uninstalling Connection Manager
The steps above describe how to uninstall Connection Manager using Control Panel. You can also uninstall the application by using the installer file (.msi). Double-click the file, in the MultiTech Connection Manager Setup Wizard, click Next, and then select Remove on the next two pages. -
Page 41: Main Tab
USING CONNECTION MANAGER Connection Details Terminal Charts Main tab The Main tab displays the following: Status of device connection: Searching, Connecting, Connected, Disconnecting, or Disconnected The action button, which changes according to the current device connection status: Detect, Connect, or Disconnect Signal strength bars and percentage indicator (only when connection to the carrier's network is established) Note:... -
Page 42: Settings Tab
USING CONNECTION MANAGER Settings tab Use the Settings tab to specify the type of device: USB Modem or Serial Modem. If USB Modem is selected, the tab displays USB settings. These settings cannot be edited. If Serial Modem is selected, the tab displays the serial settings that match the serial-port settings for the device. -
Page 43: Multiconnect Cell Usb Modem Is Not Detected
USING CONNECTION MANAGER Try the following steps: Click the Settings tab and make sure that the appropriate modem type is selected: USB or Serial. If you are connecting a serial device, make sure that all serial modem settings correspond to the serial modem and serial port configuration. -
Page 44: Index
INDEX Index absolute maximum rating ..........14 electrical characteristics..........14 activation...............36 antenna .................16 connecting ...............17 AT passthrough .............25 AT#SHDN ...............24 grant notes...............17 FCC certification ............33 FCC Notice Class B ..............32 build options ..............6 firmware................25 cable................17 hazardous substances ...........34 certification host labeling..............17 FCC ................33 Class B ................32 communicating with the device........23 Connection Manager... - Page 45 INDEX SMA to U.FL..............17 SMA to U.FL cable ............17 specifications..............8 connector definitions..........9 static................19 processor ..............11 sécurité pin connector ..............11 interférences RF............19 power down ..............24 power draw..............15 processor pins ...............11 troubleshooting Connection Manager ..........42 radio frequency interference........19 RoHS................34 U.FL ................17 user responsibility............21 safety modem..............20 RF interference ............19...
