Power Measurements

Multi-Tech Systems, Inc. recommends that you incorporate a 10% buffer into your power source when determining
product load.
Note:
The following notes apply to the following tables.
Tx Pulse: The average peak current during a GSM850 transmission burst period or HSDPA/LTE
connection. The transmission burst duration for GSM850 can vary, depending on what transmission
scheme is being deployed (GPRS Class 8, Class 10, GSM, etc.).
Maximum Power: The continuous current during maximum data rate with the radio transmitter at
maximum power.
Inrush Charge: The input current during power up, or a reset.

MTSMC-L4N1 Power Draw

Radio Sleep Mode
Protocol w/
Connection
to Live
Network
(Active SIM
Installed)
3.3 Volts
WCDMA 6 mA
(WS46=22)
LTE 8 mA
(WS46=28)
5 Volts
WCDMA 3 mA
(WS46=22)
LTE 4 mA
(WS46=28)

MTSMC-L4N1-U Power Draw

Radio Sleep Mode
Protocol w/ Connection
to Live
Network
(Active SIM
Installed)
(Amps)
3.3 Volts
WCDMA N/A
®
SocketModem Cell MTSMC-L4N1 Device Guide for North America
Cellular (AVG)
Connection Measured
Idle (No Current at
Data) Max Power
26 mA 1.08 A
32 mA 1.01 A
16 mA 648 mA
20 mA 615 mA
Cellular (AVG)
Connection Measured
Idle (No Data) Current
(Amps) (Amps) at Max
Power
32 mA 1.21 A
TX Pulse (AVG) Total Inrush
Peak Current Charge
for LTE measured in
MilliCoulombs
1.27 A 1.43 mC
1.16 A 1.43 mC
736 mA 1.51 mC
708 mA 1.51 mC
TX Pulse (AVG) Total Inrush
Peak Current Charge
for LTE measured in
MilliCoulombs
(mC)
1.42 A 3.36 mC
SPECIFICATIONS
Total Inrush
Charge
DURATION
during Powerup
(INRUSH
Duration)
1.39 mS
1.39 mS
1.23 mS
1.23 mS
Total Inrush
Charge
DURATION
during Powerup
(INRUSH
Duration)
5.08 mS
