  • Page 1 ® ™ MultiConnect Dragonfly Nano MTQN-MNG1-B01 Device Guide...
  • Page 2 Legal Notices The MultiTech products are not designed, manufactured or intended for use, and should not be used, or sold or re-sold for use, in connection with applications requiring fail-safe performance or in applications where the failure of the products would reasonably be expected to result in personal injury or death, significant property damage, or serious physical or environmental damage.

  • Page 3: Table Of Contents

    CONTENTS Contents Chapter 1 – Product Overview ..........................5 Overview ..................................5 Documentation ................................5 Product Build Options ..............................5 Chapter 2 – Mechanical Drawings..........................6 MTQN-MNG1-B01................................. 6 Chapter 3 – Hardware and Specifications......................... 7 Specifications ................................7 40-Pin Connector Definitions ............................8 MTQN-MNG1-B01 Pin Definitions ..........................
  • Page 4 CONTENTS Chapter 6 – Getting Started ........................... 27 Developing with an MTQN in Mbed ........................... 27 Mbed Documentation............................... 27 ST Microcontroller STM32L471QG ........................... 28 Chapter 7 – Labels..............................29 Approvals and Certifications ............................29 Example Labels................................29 Chapter 8 – Regulatory Information........................30 47 CFR Part 15 Regulation Class B Devices .........................

  • Page 5: Chapter 1 - Product Overview

    UBX-17003787, Rev. Commands Manual your device. Note: Additional documentation is available on the mbed site at https://os.mbed.com/platforms/MTS- Dragonfly-Nano/ and at www.multitech.net. See Chapter 6, Getting Started for details. Product Build Options The available Dragonfly Nano modules are: Model Description Region MTQN-MNG1-B01 Embedded LTE Cat M1 Cellular SoM (Verizon/AT&T)

  • Page 6: Chapter 2 - Mechanical Drawings

    MECHANICAL DRAWINGS Chapter 2 – Mechanical Drawings MTQN-MNG1-B01 ® ™ MultiConnect Dragonfly Nano MTQN-MNG1-B01 Device Guide...

  • Page 7: Chapter 3 - Hardware And Specifications

    HARDWARE AND SPECIFICATIONS Chapter 3 – Hardware and Specifications Specifications Category Description Performance 3GPP Release 13 Cat M1 Half Duplex (Up to 375K bps downlink and uplink) Frequency Band AT&T Verizon (MHz) 700 MHz (B12), 850 MHz (B5), 700 MHz (B13) AWS1700 MHz (B4) and 1900 MHz (B2) Interface...

  • Page 8: 40-Pin Connector Definitions

    HARDWARE AND SPECIFICATIONS Category Description EMC Compliance FCC Part 15 Class B Radio Compliance FCC Part 22, 24, 27 Safety Compliance UL/cUL 60950-1 2nd ED, IEC 60950-1 2nd ED +Am.2 Network PTCRB Carrier AT&T Verizon 40-Pin Connector Definitions The Dragonfly™ Nano offers developers an FCC and carrier certified solution that makes connecting sensors and other edge-of-network devices quick and easy.

  • Page 9: Mtqn-Mng1-B01 Pin Definitions

    HARDWARE AND SPECIFICATIONS MTQN-MNG1-B01 Pin Definitions Note: To program and use the Dragonfly™ Nano, you will need a UDK2 Developer Kit. For more pinout information and other details, refer to the STM32L471QG processor manual. In addition to their stated functions, all GPIO pins (PA_*, PB_*, PC_*, PG_*) can also be used as Digital-In and Digital-Out interfaces. Hardware Pinout Information Processor Pin Processor Pin...
  • Page 10 HARDWARE AND SPECIFICATIONS Processor Pin Processor Pin IO Type Net name 40 Pin UDK2 pin Primary Number Name /Arduino Function FT_a IO_01/DCD Serial Comm output from MTQN TT_a IO_02/RI Serial Comm output from MTQN FT_a IO_03/RTS Serial Comm input to MTQN FT_a IO_04/MOSI1 GPIO / MOSI...
  • Page 11 HARDWARE AND SPECIFICATIONS Processor Pin Processor Pin IO Type Net name 40 Pin UDK2 pin Primary Number Name /Arduino Function FT_fs IO_20/DTR Serial Comm input to MTQN IO_21/TXD Serial Comm input to MTQN Link status output from Cell radio, 47K pull up FT_a J_TDO/SWO...
  • Page 12 HARDWARE AND SPECIFICATIONS Processor Pin Processor Pin IO Type Net name 40 Pin UDK2 pin Primary Number Name /Arduino Function PC15_OSC32O 32K Clock 32K Clock FT_a RADIO_PWR RADIO_PWR, enable for cell regulator, 47K pull down FT_a 1V8_MON Radio Control Feedback, 100K pull down BUF_EN...
  • Page 13 HARDWARE AND SPECIFICATIONS Processor Pin Processor Pin IO Type Net name 40 Pin UDK2 pin Primary Number Name /Arduino Function VUSB_DET USB Select, Active low for Serial mode, 100K pull down RADIO_ONOFF Radio power control, 100K pull down FT_a RADIO_RESET RADIO_RESET control, 100K pull down...
  • Page 14 HARDWARE AND SPECIFICATIONS Software Pinout Information The names in this table are defined in the PinNames.h file in mbed-os at the following path: mbed- os\targets\target_stm\target_stm32l4\target_mts_dragonfly_l471qg UDK2 Primary Alternate names PA_0 UART2_CTS TIM5_1, ADC1_IN13, ADC2_IN13, SERIAL_CTS, IO_18, WAKEUP, LED1, LED2, LED3, LED4 PA_1 UART2_RTS TIM5_2, ADC1_IN6,...
  • Page 15 HARDWARE AND SPECIFICATIONS UDK2 Primary Alternate names PC_11 SPI3_MISO PC_12 SPI3_MOSI PC_13 IO_10 PC_14 PC_15 PC_2 SPI2_MISO ADC1_IN3, ADC2_IN3, ADC3_IN3, IO_08, ADC1_IN1, ADC2_IN1, ADC3_IN1 PC_3 RADIO_PWR PC_4 IO_12 ADC1_IN13, ADC2_IN13 PC_5 MON_1V8 PC_6 BUF_EN PC_8 IO_17 TIM8_3 PD_10 RADIO_RI MDMRI PD_11 RADIO_CTS MDMCTS, UART3_CTS...

  • Page 16: Communications Flow

    HARDWARE AND SPECIFICATIONS UDK2 Primary Alternate names PG_7 UART2_DTR I2C3_SCL, SERIAL_DTR, IO_20 PG_8 IO_14 I2C3_SDA Communications Flow MTQN-MNG1-B01 The MTQN-MNG1-B01 provides full UART from the cellular radio to the processor as well as the user application. Model B01 provides a direct USB interface connection to the radio, but not through the 40-pin connector. Switching between the USB interface and serial port requires a reset.

  • Page 17: Nominal Ratings

    HARDWARE AND SPECIFICATIONS Symbol Description Conditions Min. Max. Unit tstg Storage Temperature °C Voltage at any pin Voltage at any signal pin -0.3 External voltage -0.3 DDIO2 Input Voltage Input voltage on FT_xxx pins -0.3 min (V DDIO2 3 & 4 Input voltage on TT_xx pins -0.3 Input voltage on BOOT0 pin...

  • Page 18: Power Draw

    HARDWARE AND SPECIFICATIONS Symbol Ratings Max Voltage (mA) Output current sunk by any I/O and control pin except FT_f IO(PIN) Output current sunk by any FT_f pin Output current sourced by any I/O and control pin ΣI Total output current sunk by sum of all I/Os and control IO(PIN) pins Total output current sourced by sum of all I/Os and control...

  • Page 19: Usb Cable Recommendations

    If possible, use a USB port that connects directly to the motherboard rather than a USB port with added cabling inside the computer chassis. Use USB 3.0 ports if available. These ports are typically rated for more current. You can order the USB cable through MultiTech. The part number is: CA-USB-A-MICRO-B-3. Device Reset MTQN-MNG1-B01 There are two components to reset.

  • Page 20: Installing A Sim Card

    HARDWARE AND SPECIFICATIONS WARNING:If your application is using the on board flash memory part, make sure any flash accesses are complete before removing power or the memory may be corrupted. Cellular Radio Low Power Note: Refer to the U-blox AT command guide for details on AT commands. Powering Down - See Powering Down The Cellular Radio section PSM mode- AT+CPSMS command eDRX- AT+CEDRXS command...

  • Page 21: Configuring U-Blox Cellular Radio

    HARDWARE AND SPECIFICATIONS Configuring u-blox Cellular Radio This MNG1 device uses a cellular radio that can operate on different carrier networks (not simultaneously). Your device is configured in the factory for Cat M1 mode and to automatically detect your SIM to register on your carrier network provided their network is on supported list of MNOs for the u-blox cellular radio.

  • Page 22: Usb Driver Installation

    For the Windows USB driver, refer to the SARA-R4 USB Driver Installation Guide on the product page of the Multitech website. The driver is located under the Downloads section of the product page. For the Linux USB driver, if your Linux OS does not automatically detect your device, you may need to execute a script.

  • Page 23: Chapter 4 - Antennas

    Chapter 4 – Antennas Antenna Devices were approved with the following antenna or for alternate antennas meeting the given specifications: Manufacturer: Wieson Description: LTE Antenna with SMA-Male Connector Model Number GY115IE002-001 MultiTech ordering information: Model Quantity ANLTE4-1HRA ANLTE4-2HRA ANLTE4-10HRA ANLTE4-50HRA Antenna Specifications Category...

  • Page 24: Chapter 5 - Safety Information

    SAFETY INFORMATION Chapter 5 – Safety Information Handling Precautions To avoid damage due to the accumulation of static charge, use proper precautions when handling any cellular device. Although input protection circuitry has been incorporated into the devices to minimize the effect of static build-up, use proper precautions to avoid exposure to electronic discharge during handling and mounting the device.

  • Page 25: General Safety

    SAFETY INFORMATION General Safety The device is designed for and intended to be used in fixed and mobile applications. Fixed means the device is physically secured at one location and cannot be easily moved to another location. Mobile means the device is used in other than fixed locations.

  • Page 26: Device Maintenance

    Do not place the device alongside computer discs, credit or travel cards, or other magnetic media. The information contained on discs or cards may be affected by the device. Using accessories, such as antennas, that MultiTech has not authorized or that are not compliant with MultiTech's accessory specifications may invalidate the warranty.

  • Page 27: Chapter 6 - Getting Started

    MTQN software is open source. Useful Links Description Link MTQN Mbed page: https://os.mbed.com/platforms/MTS-Dragonfly-Nano/ Explore Mbed: https://os.mbed.com/explore/ MTUDK2-ST-CELL developer https://www.multitech.com/models/94557065LF guides (see Manuals for different versions) Documentation on Mbed: https://os.mbed.com/docs/latest Serial Flash Datasheet (pdf): http://www.micron.com (refer to P/N M25P16) Additional Information: https://www.multitech.com/brands/multiconnect-dragonfly-nano...

  • Page 28: St Microcontroller Stm32L471Qg

    GETTING STARTED Keep the device on the opposite side of the body from the pacemaker to add extra distance between the pacemaker and the device. Avoid placing a turned-on device next to the pacemaker (for example, don’t carry the device in a shirt or jacket pocket directly over the pacemaker).

  • Page 29: Chapter 7 - Labels

    This device is an industry and/or carrier approved modem. In most cases, when integrated and used with an antenna system that was part of the MultiTech modem certification, additional approvals or certifications are not required for the device that you develop as long as the following requirements are met: PTCRB Requirements: The antenna system cannot be altered.

  • Page 30: Chapter 8 - Regulatory Information

    REGULATORY INFORMATION Chapter 8 – Regulatory Information 47 CFR Part 15 Regulation Class B Devices This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 31 REGULATORY INFORMATION UMTS CH 2 UP UMTS CH 25 UP UMTS CH 35 DOWN The following table provides the certified radio frequency data for this device: FCC Rule Frequency Range Output Watts (mW) Frequency Tolerance Emission Parts Designator 699 - 716 MHz 0.316 1.0 PM 1M11G7D...

  • Page 32: Chapter 9 - Environmental Notices

    Substances) complements the WEEE Directive by banning the presence of specific hazardous substances in the products at the design phase. The WEEE Directive covers all MultiTech products imported into the EU as of August 13, 2005. EU-based manufacturers, distributors, retailers and importers are obliged to finance the costs of recovery from municipal collection points, reuse, and recycling of specified percentages per the WEEE requirements.

  • Page 33: Reach Statement

    ENVIRONMENTAL NOTICES Hexavalent Chromium, [Cr+6] < 1000 PPM Cadmium, [Cd] < 100 PPM Polybrominated Biphenyl, [PBB] < 1000 PPM Polybrominated Diphenyl Ether, [PBDE] < 1000 PPM Environmental considerations: Moisture Sensitivity Level (MSL) =1 Maximum Soldering temperature = 260C (in SMT reflow oven) Lead usage in some components is exempted by the following RoHS annex, therefore higher lead concentration would be found in some modules (>1000 PPM);...

  • Page 34: Information On Hs/Ts Substances According To Chinese Standards (In Chinese)

    ENVIRONMENTAL NOTICES Information on HS/TS Substances According to Chinese Standards (in Chinese) 依 依 照 照 中 中 国 国 标 标 准 准 的 的 有 有 毒 毒 有 有 害 害 物 物 质 质 信 信 息 息 根据中华人民共和国信息产业部...

  • Page 35: Information On Hs/Ts Substances According To Chinese Standards

    ENVIRONMENTAL NOTICES Information on HS/TS Substances According to Chinese Standards In accordance with China's Administrative Measures on the Control of Pollution Caused by Electronic Information Products (EIP) # 39, also known as China RoHS, the following information is provided regarding the names and concentration levels of Toxic Substances (TS) or Hazardous Substances (HS) which may be contained in Multi-Tech Systems Inc.

  • Page 36: Index

    INDEX Index absolute maximum rating ..........16 labels ................29 antenna .................23 operating conditions .............16 build options ..............5 Chinese hazardous substances connector definitions..........8 Chinese version............34 power down device............19 English version ............35 power draw MTQN-MNG1-B01............18 processor.................6 documentation..............5 RoHS................32 electrical characteristics..........16 sleep mode..............19 specifications..............7 hazardous substances ...........32 usb cable ...............19 install SIM card..............20...
