- Page 1 ® MultiConnect Dragonfly MTQ-LAT3 Device Guide...
- Page 2 Legal Notices The MultiTech products are not designed, manufactured or intended for use, and should not be used, or sold or re-sold for use, in connection with applications requiring fail-safe performance or in applications where the failure of the products would reasonably be expected to result in personal injury or death, significant property damage, or serious physical or environmental damage.
-
Page 3: Table Of Contents
CONTENTS Contents Chapter 1 – Product Overview ..........................6 Overview ..................................6 Documentation ................................6 Product Build Options ..............................6 Chapter 2 – Mechanical Drawings..........................7 MTQ-LAT3 Models ................................ 7 Processor Model (-B01) .............................. 7 No Processor Model (-B02)............................8 Chapter 3 –... - Page 4 CONTENTS LTE Antenna Information ............................24 SMA to U.FL Cables ..............................25 Connecting an Antenna through the Developer Board Connectors................25 Antenna Diversity................................ 25 Placing External Antennas ............................26 Placing GPS Antennas .............................. 26 Selecting Antennas ..............................26 Antenna Approvals and Safety Considerations ......................26 Diversity and Power Draw ............................
- Page 5 CONTENTS Canadian Limitations..............................38 Industry Canada ................................ 39 Chapter 9 – Environmental Notices........................42 Waste Electrical and Electronic Equipment Statement ....................42 WEEE Directive................................42 Instructions for Disposal of WEEE by Users in the European Union ................ 42 REACH Statement ............................... 42 Registration of Substances............................
-
Page 6: Chapter 1 - Product Overview
Commands Reference Guide your device, used with firmware version 17.00.5x3. Rev 2 Note: If using the MTQ-LAT3-B01 model, additional documentation is available on the mbed site and at www.multitech.net. See Chapter 6, Getting Started for details. Product Build Options Product Description Region... -
Page 7: Chapter 2 - Mechanical Drawings
MECHANICAL DRAWINGS Chapter 2 – Mechanical Drawings MTQ-LAT3 Models Processor Model (-B01) ® MultiConnect Dragonfly MTQ-LAT3 Device Guide... -
Page 8: No Processor Model (-B02)
MECHANICAL DRAWINGS No Processor Model (-B02) ® MultiConnect Dragonfly MTQ-LAT3 Device Guide... -
Page 9: Chapter 3 - Hardware And Specifications
HARDWARE AND SPECIFICATIONS Chapter 3 – Hardware and Specifications Specifications Category Description General Standards LTE FDD Cat 1, 3GPP release 9 compliant HSPA+ 21 fallback SMS is based on CS/Packet-Switched (PS) domain of GSM and WCDMA USB Interface is CDC-ACM compliant Frequency Bands 4G: 700 (B12/B13)/850 (B5)/AWS 1700 (B4)/1900 (B2) 3G: 850 (B5)/1900 (B2) -
Page 10: Powering Down Your Device
HARDWARE AND SPECIFICATIONS Category Description Humidity 20%-90% RH, non-condensing Category Description Power Requirements Operating Voltage 5 V +/- 5% Input Current See Power Draw Certifications and Compliance EMC and Radio FCC Part 15 Class B Compliance FCC Part 22 FCC Part 24 Safety Compliance UL/cUL 60950-1 2nd Edition mbed has limited USB support for the processor. -
Page 11: 40-Pin Connector Definitions
HARDWARE AND SPECIFICATIONS 40-Pin Connector Definitions MTQ-xx-B01 Signal Name Logic Level Voltage In/Out Description DBX_TX ST Micro UART debug Tx output SWCLK See ST Microcontroller Guide CHARGE_MON 0 - VCC-IN Open-drain charging status indication output PWR_GOOD 0 - VCC-IN Open-drain power good status indication output Ground USB-DATA+... -
Page 12: Mtq-Xx-B02
HARDWARE AND SPECIFICATIONS Signal Name Logic Level Voltage In/Out Description IO_04 I = 0 - 7V, O = 0 - 3V General Purpose I/O from ST Microcontroller (STM 32F411) IO_05 IO_06 IO_07 IO_08 IO_09 IO_10 IO_11 IO_12 IO_13 IO_14 IO_15 IO_16 IO_17 Ground... - Page 13 HARDWARE AND SPECIFICATIONS Signal Name Logic Level Voltage In/Out Description Voltage PWR_GOOD 0- VCC-IN Open-drain power good status indication output Ground USB-DATA+ 0 - 3V 5.5V USB Data USB-DATA- VCC-IN 4.35V - 5.25V Power Input Main Power RADIO_RXD 0 - 3V 3.3V RADIO_DCD 0 - 3V...
-
Page 14: 40-Pin Connector
HARDWARE AND SPECIFICATIONS Signal Name Logic Level Voltage In/Out Description Voltage LINK_STATUS Radio link status LED RESET 0 - 3V Radio reset Ground For -B02 models only: Pins 14, 15, 16, and 27 are part of the SPI interface. These pins are inputs. If you do not use them, connect them externally to a high level signal (preferably through a high pull-up resistor) to keep them from floating. - Page 15 HARDWARE AND SPECIFICATIONS Net Name Number Pin Name Details VDD3_3 VBAT Power 3G_ONOFF PC13 Enable line to the Radio 32K_XTAL_ PC14 RTC Clock 32K_XTAL PC15 RTC Clock 26MHZ_CLK_IN PH0-OSC_IN Main Clock 26MHZ_CLK_DRIVE PH1-OSC_OUT Main Clock N_RESET NRST External Reset in IO_10 GPIO/Analog capable pin IO_11...
- Page 16 HARDWARE AND SPECIFICATIONS Net Name Number Pin Name Details RADIO_CTS PB12 Serial comm with the radio IO_13 PB13 GPIO SPI-SS2 PB14 GPIO for use with external SPI IO_7 PB15 GPIO/SDIO_CK RADIO_TXD Serial comm with the radio RADIO_RXD Serial comm with the radio IO_17/SS2/SDIO_D0 GPIO/SDIO_D0 IO_14/SDIO_D1...
-
Page 17: Serial Flash Embedded Memory
HARDWARE AND SPECIFICATIONS Serial Flash Embedded Memory The M25P16 is a 16Mb (2Mb x 8) serial flash memory device with write protection mechanisms accessed by a SPI- compatible bus. The serial flash is accessible via the processor pinout on B01 devices. Features include: 75 MHz clock frequency (maximum) Page program (up to 256 bytes) in 0.64ms (TYP) Erase capability... -
Page 18: No Processor Model (B02)
HARDWARE AND SPECIFICATIONS No Processor Model (B02) Note: B02 provides a full UART interface as well as a USB interface. Electrical Characteristics Operating Conditions Parameter Minimum Volts Maximum Volts Supply Range - Vcc 4.35 Absolute Maximum Rating Parameter Minimum Volts Maximum Volts Voltage at any signal pin -0.3... -
Page 19: Input/Output Current Ratings
HARDWARE AND SPECIFICATIONS Parameter Conditions Minimum Volts Maximum Volts Reset (low active) input high CMOS port 2.31 =+8 mA (1) Guaranteed by characterization results, not tested in production. (2) Guaranteed by design, not tested in production. Note: See the ST Microcontroller data sheet (STM 32F411REF) and the Pin Connector Definitions table in Chapter 3 of this guide. - Page 20 HARDWARE AND SPECIFICATIONS Waveforms USB only inrush charge of 3.45 mC with 37.2 mS duration Total Inrush charge of 3.21 mC with 41.1 mS duration ® MultiConnect Dragonfly MTQ-LAT3 Device Guide...
-
Page 21: Mtq-Lat3-B02 (No Processor)
HARDWARE AND SPECIFICATIONS MTQ-LAT3-B02 (No Processor) Radio Radio On/Off Cellular (AVG) Measured TX Pulse (AVG) Total Inrush Protocol Mode Current Connection Idle Current at Max Amplitude Current for Charge Measured (Amps) (No Data) Power Peak Current for in Millicoulombs HSDPA/LTE 5 Volts WITHOUT unit in developer card WCDMA 25 mA... -
Page 22: Usb Cable Recommendations
Use USB 3.0 ports if available. These ports are typically rated for more current. You can order the USB cable through MultiTech. The part number is CA-USB-A-MICRO-B-3. 3G_ONOFF Signal Minimum pulse is 200 μs up to 900 msec. -
Page 23: Device Reset
HARDWARE AND SPECIFICATIONS Device Reset Processor Models (B01) To reset the processor, the minimum recommended reset pulse is 200 μs. The maximum reset pulse is less than 1 second. Refer to STM32F411 documentation for additional reset options available within the on-board microcontroller. -
Page 24: Chapter 4 - Antennas
The cellular radio portion of the device is approved with the following antenna or for alternate antennas meeting the given specifications. Manufacturer: EAD Ltd. Description: LTE Antenna with SMA-Male Connector Model Number: WTR7270 MultiTech Part Number: 45009760L MultiTech ordering information: Model Quantity ANLTE3-2HRA ANLTE3-10HRA ANLTE3-50HRA... -
Page 25: Sma To U.fl Cables
ANTENNAS SMA to U.FL Cables The developer kit includes three 4.5" SMA to U.FL cables which are preinstalled on the developer board. Consult the mechanical drawings for your device to determine which antenna to connect to which U.FL connector on the device. -
Page 26: Placing External Antennas
ANTENNAS Antenna diversity is unnecessary when the device has an unobstructed signal path from the cell tower, such as in a flat area away from buildings. In good reception environments, the product application might prohibit using two receive antennas. Placing External Antennas Antennas are usually a quarter wavelength apart from each other. -
Page 27: Host Labeling
ANTENNAS FCC Definitions Portable: (§2.1093) — A portable device is defined as a transmitting device designed to be used so that the radiating structure(s) of the device is/are within 20 centimeters of the body of the user. Mobile: (§2.1091) — A mobile device is defined as a transmitting device designed to be used in other than fixed locations and to generally be used in such a way that a separation distance of at least 20 centimeters is normally maintained between the transmitter’s radiating structure(s) and the body of the user or nearby persons. -
Page 28: Chapter 5 - Safety Information
SAFETY INFORMATION Chapter 5 – Safety Information Handling Precautions To avoid damage due to the accumulation of static charge, use proper precautions when handling any cellular device. Although input protection circuitry has been incorporated into the devices to minimize the effect of static build-up, use proper precautions to avoid exposure to electronic discharge during handling and mounting the device. -
Page 29: General Safety
SAFETY INFORMATION Éteignez votre appareil sans fil dans les hôpitaux ou dans toutes les zones où des appareils médicaux sont susceptibles d'être utilisés. General Safety The device is designed for and intended to be used in fixed and mobile applications. Fixed means the device is physically secured at one location and cannot be easily moved to another location. -
Page 30: Device Maintenance
Do not place the device alongside computer discs, credit or travel cards, or other magnetic media. The information contained on discs or cards may be affected by the device. Using accessories, such as antennas, that MultiTech has not authorized or that are not compliant with MultiTech's accessory specifications may invalidate the warranty. -
Page 31: Chapter 6 - Getting Started With The Mtq-Lat3-B01
GETTING STARTED WITH THE MTQ-LAT3-B01 Chapter 6 – Getting Started with the MTQ-LAT3-B01 Developing with an MTQ in mbed Build applications written for the MTQ are built on top of the mbed library and can include the MTSAS library for easy cellular radio use. -
Page 32: Mbed Links
Handbook: http://developer.mbed.org/handbook/Homepage Serial Flash Datasheet: https://www.micron.com/~/media/documents/products/data-sheet/nor-flash/serial- nor/m25p/m25p16.pdf Additional Information: http://www.multitech.net/developer/products/multiconnect-dragonfly/ MTQ Platform The MTQ mbed page includes the MTSAS library and example programs. https://developer.mbed.org/platforms/MTS-Dragonfly ST Microelectronics STM32F411xC/E For information on the STM32F411xC/E microcontroller, refer to: Reference Manual: http://www.st.com/st-web- ui/static/active/en/resource/technical/document/reference_manual/DM00119316.pdf... - Page 33 GETTING STARTED WITH THE MTQ-LAT3-B01 The device will not send an SMS and this message appears: Error! SMS message time out (60) seconds waiting on +CMGS:". ® MultiConnect Dragonfly MTQ-LAT3 Device Guide...
-
Page 34: Chapter 7 - Labels
This device is an industry and/or carrier approved modem. In most cases, when integrated and used with an antenna system that was part of the MultiTech modem certification, additional approvals or certifications are not required for the device that you develop as long as the following requirements are met: PTCRB Requirements: The antenna system cannot be altered. -
Page 35: Chapter 8 - Regulatory Information
REGULATORY INFORMATION Chapter 8 – Regulatory Information 47 CFR Part 15 Regulation Class B Devices This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. - Page 36 REGULATORY INFORMATION FCC Rule Parts Frequency Range Output Watts Frequency Tolerance Emission Designator (MHz) 1850.7 - 1909.3 0.218 1.0 PM 1M09G7D 1850.7 - 1909.3 0.185 1.0 PM 1M08W7D 1851.5 - 1908.5 0.218 1.0 PM 2M69G7D 1851.5 - 1908.5 0.18 1.0 PM 2M69W7D 1852.5 - 1907.5 0.219...
-
Page 37: Industry Canada Class B Notice
REGULATORY INFORMATION FCC Rule Parts Frequency Range Output Watts Frequency Tolerance Emission Designator (MHz) 779.5 - 784.5 0.194 1.0 PM 4M47G7D 779.5 - 784.5 0.157 1.0 PM 4M47W7D 782.0 - 782.0 0.188 1.0 PM 8M96G7D 782.0 - 782.0 0.155 1.0 PM 8M95W7D 824.7 - 848.3 0.191... -
Page 38: Canadian Limitations
REGULATORY INFORMATION the device may not cause interference, and this device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes: l'appareil ne doit pas produire de brouillage, et l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en... -
Page 39: Industry Canada
REGULATORY INFORMATION Industry Canada Certification Number/No. de Certification 5131A-LE910NAV2 Type of Radio Equipment/Genre de Matériel Modular Approval Advanced Wireless Services Equipment/Matériel des services sans fil évolués (1710-1755 MHz and 2110-2155 MHz) Cellular Mobile GSM/ Téléphone cellulaire mobile GSM (824-849 MHZ) Cellular Mobile New Technologies/Téléphone cellulaire mobile - Nouvelles technologies (824-849 MHz) PCS Mobile/Téléphone mobile SCP (1850-1910 MHz) - Page 40 REGULATORY INFORMATION From RF Power (W) RF Power Occupied Bandwidth Emmission Frequency/De Frequency/Á Minimum (kHz) Designation / Fréquences (MHz) Fréquences Maximum Designation (MHz) D’émission 1711.5 1753.5 0.199 0.199 2688.2 1711.5 1753.5 0.174 0.174 2694 1712.5 1752.5 4473.9 1712.5 1752.5 0.17 0.17 4465.7 1715.0...
- Page 41 REGULATORY INFORMATION From RF Power (W) RF Power Occupied Bandwidth Emmission Frequency/De Frequency/Á Minimum (kHz) Designation / Fréquences (MHz) Fréquences Maximum Designation (MHz) D’émission 706.5 713.5 0.161 0.161 4477 0.197 0.197 8956.8 0.164 0.164 8950.7 Certification of equipment means only that the equipment has met the requirements of the above noted specification.
-
Page 42: Chapter 9 - Environmental Notices
Substances) complements the WEEE Directive by banning the presence of specific hazardous substances in the products at the design phase. The WEEE Directive covers all MultiTech products imported into the EU as of August 13, 2005. EU-based manufacturers, distributors, retailers and importers are obliged to finance the costs of recovery from municipal collection points, reuse, and recycling of specified percentages per the WEEE requirements. -
Page 43: Restriction Of The Use Of Hazardous Substances (Rohs)
2011/65/EU of the European Parliament (Restriction of the use of certain Hazardous Substances in electrical and electronic equipment - RoHS). These MultiTech products do not contain the following banned chemicals Lead, [Pb] < 1000 PPM Mercury, [Hg] <... -
Page 44: Chapter 10 - Connection Manager Overview
Follow these steps in order. Attempting to plug in the device before the appropriate drivers are installed can cause the connection to fail. Go to www.multitech.com/connectionmanager.go. Click Connection Manager. Open or unzip the Connection Manager file and run the installer (.msi file). -
Page 45: Setting Up A Serial Device
CONNECTION MANAGER OVERVIEW Setting Up a Serial Device Connect the serial device to the PC. Navigate to Control Panel > Device Manager. Make note of the COM port number for the connected device (in COM Ports). Example: COM port is COM31. In the Action drop-down menu, select Add legacy hardware to add a new device. - Page 46 CONNECTION MANAGER OVERVIEW Click Browse and select the installation folder. Example: C:\Program Files (x86)\Multi-Tech Systems\Multi-Tech Connection Manager. The list of available TELIT models appears. Select the model number for your device, then click Next. ® MultiConnect Dragonfly MTQ-LAT3 Device Guide...
-
Page 47: Troubleshooting
CONNECTION MANAGER OVERVIEW Select the COM port that you noted from COM ports, then click Next. Click Finish to exit the Wizard. Navigate to Device Manager > Modems and confirm that the device is added. Troubleshooting Serial COM port is not available in the Serial Modem Settings This can happen if the modem was installed while Connection Manager was running. -
Page 48: Multiconnect Cell Usb Modem Is Not Detected
CONNECTION MANAGER OVERVIEW Restart Connection Manager. Disconnect and reconnect the device. MultiConnect Cell USB Modem is not detected Check the Power and LS LEDs on the device. If they are not continuously lit, then the problem is with the power supply. Check the cable and connections. USB device: Make sure that the device is connected to the PC and that the correct USB cable is in use. -
Page 49: Index
INDEX Index host labeling..............26 absolute maximum rating ..........18 activation...............44 antenna Industrie Canada ............38 connecting ...............25 Industry Canada ............38 39 diversity..............25 Class B ..............37 LTE................24 interférence des radiofréquences.........28 AT passthrough .............31 AT#SHDN ...............10 KDB 447498 Section 8 ..........26 build options ..............6 labeling host ................26 cable................25... - Page 50 INDEX MTQ-LAT3-B02............21 static................28 processor pins ...............14 sécurité interférences RF............28 radio frequency interference........28 RoHS................43 troubleshooting.............47 safety U.FL ................25 modem..............29 user responsibility............30 RF interference ............28 vehicle..............29 shutdown ..............10 SIM card, installing............23 vehicle safety ..............29 sleep mode..............23 SMA to U.FL..............25 SMA to U.FL cable ............25 specifications..............9 ®...
