- Page 1 USER MANUAL TOSIBOX ® TOSIBOX ® Version 3.4...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Regulatory information 1.1 TOSIBOX Node intended use ® 1.2 Important notice for wireless operation of TOSIBOX ® 1.3 Safety and hazards Technical data Warranty Legal Notices Declarations... - Page 3 Congratulations for choosing TOSIBOX solution! It consists of modular TECHNICAL SUPPORT ® components that offer unlimited expandability and flexibility. All products support@tosibox.com are compatible with each other as well as internet connection, operator, and device agnostic. The system works both in internal and external networks. GLOBAL TOSIBOX Key is a client used to access the network. ® • +358 10 57 30533 TOSIBOX Node is a router with firewall sharing access to devices. ® • Business hours: from 8 am till 5 pm Mon – Fri In physical matching, the Key is inserted to the Lock’s USB port.
-
Page 4: Regulatory Information
TOSIBOX Node with cellular Lock 500: Office, residential and light industrial environment ® modem, or for failure of the TOSIBOX Node with cellular ® Norway: Use of this radio equipment (Wi-Fi) is not allowed modem to transmit or receive such data. -
Page 5: Safety And Hazards
1.3 SAFETY AND HAZARDS At least 20 cm separation distance between the antennas and persons must be maintained at all times. Do not operate your Node with internal or external cellular modem: In areas where blasting is in progress • Where explosive atmospheres may be present including • refuelling points, fuel depots, and chemical plants Near medical equipment, life support equipment, or any • equipment which may be susceptible to any form of radio interference. In such areas, the Node and the cellular modem MUST BE POWERED OFF. -
Page 6: Technical Data
TECHNICAL DATA TOSIBOX ® Ports Physical properties • 1 x RJ-45 WAN connection, 10/100 Mbps, • 145 mm x 114 mm x 45 mm / 5.71” x 4.49” x 1.77” (W x H x L) auto-negotiation (MDI / MDI-X) • Protection class IP30 • 4 x RJ-45 LAN connection, 10/100 Mbps, • Weight 630 g / 1.39 lbs (net weight article) auto-negotiation (MDI / MDI-X) • Storage temperature -35 °C … +75 °C / -31 °F … +167 °F • 1 x USB 2.0, type A •... - Page 7 TOSIBOX ® Ports Physical properties • 1 x RJ-45 WAN connection, 10/100 Mbps, auto-negotiation (MDI • 145 mm x 114 mm x 45 mm / 5.71” x 4.49” x 1.77” (W x H x L) / MDI-X) • Protection class IP30 • 4 x RJ-45 LAN connection, 10/100 Mbps, auto-negotiation (MDI • Weight 630 g / 1.39 lbs (net weight article) / MDI-X) • Storage temperature -35 °C … +75 °C / -31 °F … +167 °F • 1 x USB 2.0, type A • Operating temperature -40 °C … +80 °C / -40 °F … +176 °F • Power supply operating temperature 0 °C ... +40 °C /32°F … +104 °F WAN connection features • Power storage temperature -20 °C ... +80 °C /-4°F … +176 °F • 3-way WAN priority • Proxy server support Powering requirements •...
-
Page 8: Limited Warranty
United States of America or any of the IS PROVIDED IN LIEU OF ALL OTHER WARRANTIES, territories or possessions thereof, or from a U.S. Military EXPRESS OR IMPLIED. IN NO EVENT SHALL TOSIBOX exchange. OY BE LIABLE, WHETHER IN CONTRACT OR TORT... -
Page 9: Legal Notices
11. LEGAL NOTICES 11. MENTIONS LÉGALES © 2024 Tosibox Oy. All rights reserved. © 2024 Tosibox Oy. Tous les droits sont réservés. Reproduction, distribution or storage of part or all of La reproduction, la distribution ou le stockage de tout ou the content of this document without the prior written partie du contenu de ce document sans l’autorisation écrite permission of Tosibox is prohibited. préalable de Tosibox est interdite. Because of continuous product development, Tosibox En raison du développement continu du produit, Tosibox reserves the right to change and improve any product se réserve le droit de modifier et d’améliorer tous produits... -
Page 10: Federal Communication Commission Interference Statement
TOSIBOX FEDERAL COMMUNICATION COMMISSION ® INTERFERENCE STATEMENT EU DECLARATION OF CONFORMITY Hereby, Tosibox Oy declares that the radio equipment type 350 is in 350 FCC ID: 2AHCNNODE350 compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the This radio device has been tested to operate with the external antenna following Internet address: types listed below with the maximum permissible gain and required antenna impedance for each antenna type indicated. Antenna types https://www.tosibox.com/tosibox-for-sites not included in this list, having a gain greater than the maximum gain UL DECLARATION OF CONFORMITY indicated for that type, are strictly prohibited for use with this device. - Page 11 FEDERAL COMMUNICATION COMMISSION (FCC) STATEMENT Any Changes or modifications not expressly approved by the party FCC Radiation Exposure Statement: responsible for compliance could void the user’s authority to This equipment complies with FCC radiation exposure limits set operate the equipment. forth for an uncontrolled environment.
- Page 12 TOSIBOX ® EU DECLARATION OF CONFORMITY Hereby, Tosibox Oy declares that the radio equipment type 375 is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following Internet address: https://www.tosibox.com/tosibox-for-sites UL DECLARATION OF CONFORMITY This device is UL listed in USA and Canada with UL file number E497243.
- Page 13 Elektroniikkatie 2A, 7th floor FIN-90590 Oulu www.tosibox.com Copyright © Tosibox Oy 2024...
