Tosibox 175 Quick Start Manual

Power On

1
1. Connect the operating voltage of 9-35 V DC to the device and wait for few seconds.
2. Connect ethernet cable into LAN port of TOSIBOX® 175 and
the other end of the cable into LAN port of your computer.
TOSIBOX® 175 LAN port is DHCP enabled. Your
!
computer receives the IP address from TOSIBOX® 175.

Set Up Router

2
1. Visit 10.10.10.254 in your browser to set up your device.
2. Log in using "admin" account. The password can be found from the bottom of the Node.
3. Change password (required password policy) and click save.
4. Accept the EULA (End user license agreement) by clicking accept.
5. TOSIBOX® 175 needs an Internet connection to function. Go to
broadband networks (ethernet) or
3a

Connect to the Internet using Ethernet connection

1. Connect TOSIBOX® 175 from the WAN port to the Internet with Ethernet cable.
2. When the WAN LED is lit on the front plate of the Node, the Internet connection is
working. If the light is not lit, investigate possible connectivity issues.
TOSIBOX® 175
Quick Start Guide
Copyright © Tosibox Oy, 2022
3b
if deploying into wireless connection.
3a
if deploying into
