Tosibox Lock 210 Quick Start Manual

Matching the Lock with the Key

1
TOSIBOX
1. Connect the operating voltage of 12-48 V DC to the Lock and wait for 1 minute. In case you have a
product version with Power Source kit, use the conversion cable. It converts the AC adapter's coaxial
connector output to stripped wires that are needed to power the Lock 210/250. Follow the polarity
symbols in the front panel. Use + and - terminals to power the device.
2. Insert the Key into the USB port of the Lock. When the LED on the Key turns off, (after approx.
10 seconds) the matching is complete, and you can remove the Key from the USB port.
3. Go to 2a if deploying into broadband networks (ethernet) or
networks. If deploying Locks as DHCP client into existing networks, please see the TOSIBOX
user manual.

Deploying into Broadband Networks

2a
PC
®
TOSIBOX
Mobile
Client
1. Connect an Internet-connected ethernet cable
to the Lock's WAN port.
2. Plug the devices into the Lock's LAN ports
(LAN 1-3). If the devices have static IP
addresses, please see
in the TOSIBOX
Lock 210/250
Quick Start Guide
Copyright © Tosibox Oy, 2020
® Lock 210/250
Power source Kit
VPN tunnel through Internet
®
TOSIBOX
Key
Deploying the Lock
® user manual.
WAN: Internet/xDSL router
USB Connection
TOSIBOX ® Key
2b if deploying into mobile
L
W
®
TOSIBOX
A
A
Lock
N
N
Firewall
®
HMI
PLC
Camera
PC
