NETGEAR Nighthawk RS200 User Manual page 20

Nighthawk WiFi 7 Dual-Band Router Model RS200, Model RS150v1
Figure 5. Cable your router
To cable your router:
1. Unplug your modem, remove and reinsert the backup battery if it uses one, and
then plug the modem back in.
2. Use the Ethernet cable to connect the modem to the yellow Internet port on the
router.
NOTE: If your Internet connection does not require a modem, connect the
Ethernet cable going to your home to the yellow Internet port on the router.
3. Connect the power adapter to your router and plug the power adapter into an outlet.
The router's Power LED lights solid white when the router is ready.
After you connect your router to a modem and power it on, finish your router's installation
process using the Nighthawk app or router web interface. For more information, see
Connect to the Router Network and Access the Router on page 21.
Hardware Setup 20 User Manual
