Set Up A Bridge For A Port Group - NETGEAR Nighthawk RS200 User Manual

Nighthawk WiFi 7 Dual-Band Router Model RS200, Model RS150v1
Some devices, such as an IPTV, cannot function behind the router's network address
translation (NAT) service or firewall. For example, an IPTV port might require an IP
address within the Internet service provider's (ISP's) network (also called an ISP intranet
address).
The way you set up an IPTV port is by creating a bridge connection from the router's
Internet port to the LAN port to which the IPTV device is connected. When IPTV is
connected through WiFi, the router must also support a bridge connection from the
Internet port to the WiFi network. The designated LAN port or WiFi network effectively
becomes an IPTV port with direct access to the WAN without going through NAT.
Based on what your ISP requires for the device to connect to the ISP's network directly,
you can enable the bridge between the IPTV device and the router's Internet port with
or without a VLAN tag.
NOTE: If your ISP provides instructions for how to set up a bridge for IPTV and
Internet service, follow those instruction.

Set up a bridge for a port group

If the devices that are connected to the router's Ethernet LAN port or WiFi network
include an IPTV device, your ISP might require you to set up a bridge for the IPTV device
and the router's Internet interface without a virtual local area network (VLAN) tag.
A bridge with a port group does not use VLAN tags and prevents packets that are sent
between the IPTV device and the router's Internet port from being processed through
the router's network address translation (NAT) service.
To configure a port group and enable the bridge:
1. Launch a web browser from a computer or mobile device that is connected to the
router network.
2. Enter http://www.routerlogin.net.
A login window displays.
3. Enter the router admin user name and password.
The user name is admin. The password is the one that you specified when you set
up your router. The user name and password are case-sensitive.
The BASIC Home page displays.
4. Select ADVANCED > Advanced Setup > VLAN / Bridge Settings.
The VLAN / Bridge Settings page displays.
5. Select the Enable VLAN / Bridge Settings check box.
The page expands.
6. Select the By bridge group radio button.
Manage the WAN and LAN
Network Settings
103 User Manual
