Omcan MS-IT-0370-S Instruction Manual page 19

Model MS-IT-0370-S
Item No. Description
AO320 Assy Sharpener for 46088
66110 Sharpener Assy for 46088
AO321 Shaft Flywheel Vose9 for 46088
AO322 Cogged Shaft for 46088
66111 Flatbed Shaft for 46088
AO323 Shaft for Mob.Protection Slide for 46088
AO324 Shaft for Lower Wheel. Z.36 for 46088
AO325 Unique Blade Holder Shaft for 46088
AO326 Spring for 46088
19604 Ring 7 for 46088
16902 Ring El.Benzing 8 for 46088
El.Seeger Ext. Ring Stainless Steel for
36538
46088
64355 Ring El.Seeger Ext.12 for 46088
66112 Ring El.Seeger Int.47 for 46088
19484 Ring 52 for 46088
17287 O-Ring 123 17.86x2.62 for 46088
AO327 Ring Seal Orm 0020-10 2x1 for 46088
66113 Spacer Bearing Ring for 46088
AO328 Profile Bar for Flat Trolley H for 46088
Square Bar Lower+Upper Pair Car-S9
AO329
for 46088
AO330 BS Rod for 46088
AO331 Round Bar Trolley for 46088
AO332 Round Bar Transv. Trolley for 46088
AO333 Connecting Rod BS for 46088
AO334 Connecting Rod for 46088
AO335 Crank for 46088
AO336 Plate Feeding Connecting Rod for 46088
AO337 Block for 46088
AO338 Brake Block for 46088
66114 Arm Block for 46088
66115 Block Door Magnet for 46088
19618 Bushing 8x10x8 for 46088
AO339 Cylindrical Bushing for 46088
16904 Bushing Sharpener for 46088
AO340 Bushing SI.25x32x40xØ40 for 46088
17303 Bushing DU 12x14x15 for 46088
AK403 Bushing DU 25x28x20 for 46088
46088
Position Item No. Description
A1069 17305 Bushing DU 18x20x15 for 46088
A1109 AO341 Blind Bushing for 46088
A3078 16906 Bush Sharpening for 46088
A3090 AO342 Bushing 16x22x16 for 46088
A3112 AO343 Bushing Rollers (HF2520 INA) for 46088
A3151 AO344 Bushing DU 16x18x10 for 46088
A3159 36570 Bushing DU 16x18x20 for 46088
A317501 66116 Bushing Door Spring BS for 46088
A5015 66117 Bushing DU 10x12x20 for 46088
A5405 AO345 Bushing SI 6x8x14 for 46088
A5406 77552 Bushing for Plate for 46088
A5442X AO346 Busher for Finishing Stone for 46088
A5444 66118 Bushing SI 6x8x8 for 46088
A5480 AO347 Special Arm for 46088
A5485 AO348 Special Assy Arm NSF for 46088
A5852 AO349 Sharpen Canopy NSF Red for 46088
A5863 AO350 Cart Vol. M Blade 370 Arm TH for 46088
A5925 AO351 Trolley for 46088
Roller Chain 3/8 x7/32"L.81pClosed
B0801 AO352
for 46088
B1003 17317 Pin .11 for 46088
B1268 36601 Rivet 1.9x5 for 46088
B1714 AO353 Bottom Cover for 46088
B1739 36623 Foot Cover for 46088
B4007A AO354 Bar Cover for 46088
B4008 AO355 Front Bar Cover for 46088
B4009 64361 Sharpener Body for 46088
B4080 AO356 Lower Cover for 46088
B5019 AO357 Flat Cover NSF for 46088
B5062 AO358 Rear Crankcase for 46088
B5093 AO359 Shoulder Side Cover for 46088
B5128 AO360 SE 9-S9 Adjustment Rack for 46088
B6009 64123 Spring Support for 46088
B6018 19251 Nylon Bearing 6x19x6 for 46088
B6048 64362 Bearing 2Z-626 6x19x6 for 46088
B6049 16922 Bearing 2Z-6202 for 46088
B6052 16925 Bearing 2RS-6204 20x47x14 for 46088
B6056 36631 Bearing 2RS-6205 25x52x15 for 46088
Parts Breakdown
Position Item No.
B6057 AO361
B6069 AO362
B6075 66119
B6107 AO363
B6143 77535
B6218 36636
B6246 64363
B6247 36638
B6252 74408
B6289 77508
B6332 66365
B633401 66120
B6346 66121
B7910 19644
B7923 36646
C1620R 36648
C180701 36652
C1886 AO364
C3004 AO365
C4602 AO366
C4640 65163
C6646 66123
C6682 AO367
C6686 66124
C6687 AO368
C680764 AO369
C7010 AO370
C7011 66125
C7012 AO371
C713301 AO372
C7202 AO373
C7203 AO374
C8005 36663
C8012 AO375
C8014 AO376
C8024 AO377
C8056 AO378
19
Description Position
Bearing Axial with Balls 51104 20x35x10
C8075
for 46088
Nut U5587 M5 6S for 46088 D0103
Self-Locking Nut M6 U7474 Inox for
D011115
46088
Nut Fix. Knob Hinge for 46088 D0115
Special Nut M10 for 46088 D0116
Nut U5589 M6 Stainless Steel for 46088 D0133X
Nut Din 917 M10 Inox for 46088 D013615
Nut U5589 M10 Stainless Steel for
D0137X
46088
Stainless Steel Nut Din 917 M6 for
D014115
46088
Stainless Steel Nut U5588 M12 for
D014215
46088
Domed Nut Din 917 M8 Stainless Steel
D014515
for 46088
Domed Nut U5721 M4 Inox for 46088 D015115
Special Domed Nut M6 Inox for 46088 D0158X
Nut M6 for 46088 D0163
Nut U5588 M6 Stainless Steel for 46088 D0163X
Nut U5588 M8 for 46088 D0165X
Nut M25x1.5 for 46088 D0198
Special Nut M12P1 for 46088 D0201
Low Nut U5589 M5 for 46088 D0202
Foot Spacer for 46088 D5308
Conical Spacer Øi7x18x22x10 for 46088 D5315
Spacer for 46088 D5320
Fixed Protection Spacer for 46088 D5321
Teflon Pin for 46088 D5331
Spacer for Lever Ø8x16x22 for 46088 D5478
Hex Spacer 10pm 80am for 46088 D560601
Spacer Screw Endless for 46088 D5639
Spacer Bearing for 46088 D5648
Spacer Transmission Blade for 46088 D5662
Spacer for Spring for 46088 D5663
Lower Shaft Spacer for 46088 D5705
Foot Spacer for 46088 D5708
Locknut Pacer for 46088 D577016
Spacer for Spring AD Propeller for 46088 D5869
Eccentric Adjustment for 46088 E1423
Eccentric Advancement Plate for 46088 E1450
Eccentric Trolley for 46088 E1484
