SPX POWER TEAM PE604T Operating Instructions Manual

SPX Corporation
5885 11th Street
Rockford, IL 61109-3699 USA
Internet Address:
http://www.powerteam.com
Maximum Capacity: 10,000 PSI for PE604T, PE604T-220, PE604T-COOL,
NOTE:
•
Carefully inspect the pump upon arrival. The carrier, not the manufacturer, is responsible for any damage
resulting from shipment.
•
Read and carefully follow these instructions. Most problems with new equipment are caused by improper
operation or installation.
•
The hydraulic power unit can be ordered with "building block" flexibility. The customer can choose from a
variety of motors, controls, and other options. Because of the many options available, these instructions
will include directions for options that your particular pump may not have.
•
Do not change motors without consulting the pump manufacturer's Technical Services Department.
WARNING: To help prevent personal injury,
GENERAL
•
Hydraulic equipment must be assembled correctly and then checked for proper function before use. Use
hydraulic components of the same ratings. An appropriate hydraulic pressure gauge is recommended to
monitor pressure.
HYDRAULIC HOSE
•
Before operating the pump, all hose connections must be tightened with the proper tools. Do not
overtighten. Connections should only be tightened securely and leak-free. Overtightening can cause
premature thread failure or high pressure fittings to split at pressures lower than their rated capacities.
•
Always shut off the electric motor before breaking any connections in the system.
•
Should a hydraulic hose ever rupture, burst, or need to be disconnected, immediately shut off the pump.
Never attempt to grasp a leaking pressurized hose with your hands. The force of escaping hydraulic fluid
could cause serious injury.
•
Do not subject the hose to potential hazard such as fire, sharp surfaces, extreme heat or cold, or heavy
impact. Do not let the hose kink, twist, curl or bend so tightly that oil flow within the hose is blocked or
reduced. Periodically inspect the hose for wear, because any of these conditions can damage the hose.
•
Do not use the hose to move attached equipment. Stress can damage the hose, causing personal injury.
•
Hose material and coupler seals must be compatible with the hydraulic fluid used. Hoses also must not
come in contact with corrosive materials such as creosote-impregnated objects and some paints. Consult
the manufacturer before painting a hose. Never paint the couplers. Hose deterioration due to corrosive
materials can result in personal injury.
© 2005 SPX Corporation
Tech. Services: (800) 477-8326
Fax: (800) 765-8326
Order Entry: (800) 541-1418
Fax: (800) 288-7031
ELECTRIC
TWO-STAGE HYDRAULIC PUMP
PE604PT & PE604PT-220
Maximum Capacity: 5,000 PSI for PE904T-PJA
SAFETY PRECAUTIONS
®
Operating Instructions
for:
PE604T
PE604T-220
PE604T-COOL
Sheet No.
Rev 4
Form No. 102921
PE604PT
PE604PT-220
PE904T-PJA
1 of 5
Date: 21 Mar 2005
