SPX POWER TEAM P124-10 Manual

Two-stage hydraulic pump

Advertisement

SPX Corporation
5885 11th Street
Rockford, IL 61109-3699 USA
Internet Address:
http://www.powerteam.com
MODEL A (for P124-10, P124-50-220, & P124-50-3380),
NOTE:
● ●
Read and carefully follow these instructions. Most problems with new equipment are caused by improper
operation or installation.
WARNING:
To help avoid personal injury,
Hydraulic Hose
● ●
Before operating the pump, all hose connections must be tightened with the proper tools. Do not
overtighten. Connections should only be tightened securely and leak-free. Overtightening can cause
premature thread failure or high pressure fittings to split at pressures lower than their rated capacities.
● ●
Should a hydraulic hose ever rupture, burst, or need to be disconnected, immediately shut off the pump
and shift the control valve twice to release all pressure. Never attempt to grasp a leaking hose under
pressure with your hands. The force of escaping hydraulic fluid could cause serious injury.
● ●
Do not subject the hose to potential hazard such as fire, sharp surfaces, extreme heat or cold, or heavy
impact. Do not allow the hose to kink, twist, curl, or bend so tightly that the oil flow within the hose is
blocked or reduced. Periodically inspect the hose for wear, because any of these conditions can damage
the hose and result in personal injury.
● ●
Do not use the hose to move attached equipment. Stress can damage the hose and cause personal injury.
● ●
Hose material and coupler seals must be compatible with the hydraulic fluid used. Hoses also must not
come in contact with corrosive materials such as creosote-impregnated objects and some paints. Consult
the manufacturer before painting a hose. Never paint the couplers. Hose deterioration due to corrosive
materials can result in personal injury.
Pump
● ●
Do not exceed the PSI hydraulic pressure rating noted on the pump nameplate or tamper with the internal
high pressure relief valve. Creating pressure beyond rated capacities can result in personal injury.
● ●
Before replenishing the oil level, retract the system to prevent overfilling the pump reservoir. An overfill
can cause personal injury due to excess reservoir pressure created when cylinders are retracted.
Cylinder
● ●
Do not exceed rated capacities of the cylinders. Excess pressure can result in personal injury.
● ●
Do not set poorly-balanced or off-center loads on a cylinder. The load can tip and cause personal injury.
© SPX Corporation
Tech. Services: (800) 477-8326
Fax: (800) 765-8326
Order Entry: (800) 541-1418
Fax: (800) 288-7031
MODEL D (for P125-10), MODEL B (for P126-10)
ELECTRIC
TWO-STAGE HYDRAULIC PUMP
SAFETY PRECAUTIONS
®
Operating
Instructions for:
Form No. 102811
P124-10
P124-50-220
P124-50-380
P125-10
P126-10
Sheet No.
1 of 4
Issue Date:
Rev. 9-1-93

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the P124-10 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for SPX POWER TEAM P124-10

  • Page 1 Fax: (800) 288-7031 P124-50-380 P125-10 Internet Address: http://www.powerteam.com P126-10 MODEL A (for P124-10, P124-50-220, & P124-50-3380), MODEL D (for P125-10), MODEL B (for P126-10) ELECTRIC TWO-STAGE HYDRAULIC PUMP NOTE: ● ● Read and carefully follow these instructions. Most problems with new equipment are caused by improper operation or installation.
  • Page 2: Operating Procedure

    Operating Instructions, Form No. 102811, Back sheet 1 of 4 WARNING: cont'd Power Supply (Electric) ● ● Do not use an ungrounded (two-prong) extension cord with this unit. ● ● Avoid any conditions that could create an electrical hazard. ● ● Any electrical work must be done by a qualified electrician.
  • Page 3: Preventive Maintenance

    Operating Instructions Form No. 102811 Pump Operation (Auto/Manual Valve) When operating the pump for the first time: 1. All valve and hose connections should be secure, and the reservoir should be filled to the proper level. Connect the power supply. 2.
  • Page 4: Maintenance & Cleaning

    3. Use a clean funnel with filter when adding oil. 4. Use only Power Team hydraulic fluids. HYDRAULIC SCHEMATIC Max. Pressure Safety Relief Valve 7,400 / 7,800 PSI (for P125-10) 10,100 / 10,700 PSI (for P124-10, P124-50-220, Supercharge P124-50-380, Relief Valve & P126-10) 185 PSI Pilot oil for P125-10 &...
  • Page 5: Troubleshooting

    ● ● Refer to Parts List #101331 (for P124-10 & P124-50-220), Parts List #101337 (For P124-50-380), Parts List #101308 (for P125-10), or #101309 (for P126-10) and the hydraulic and electrical schematics when using this trouble-shooting guide.
  • Page 6 Operating Instructions, Form No. 102811, Back sheet 3 of 4 PROBLEM CAUSE SOLUTION Pump is not delivering oil or 1. Oil level too low. 1. Fill reservoir to within 1" of filler delivers only enough oil to plug with all rams retracted. advance ram(s) partially or 2.
  • Page 7 Operating Instructions Form No. 102811 PROBLEM CAUSE SOLUTION Pump will not build full pressure. 1. Faulty pressure gauge. Calibrate gauge. 2. Check for external leakage. 2. Seal any faulty pipe fitting with pipe sealant. 3. Check the relief valve setting. 3.
