DSR
Switch
Installer/User Guide
For models: DSR1020, DSR2020, DSR4020, DSR8020
Avocent, the Avocent logo,The Power of Being There, DSR, DSView,
Dambrackas Video Compression and OSCAR are trademarks or
registered trademarks of Avocent Corporation or its affiliates. The
GoAhead web server is copyright (c) 2005 GoAhead Software, Inc. All
rights reserved. All other marks are the property of their
respective owners.
©
2005 Avocent Corporation. All rights reserved. 590-419-501B
