MRS Series
1.0

Introduction

Overview

The intent of this manual is to provide information regarding general safety, installation, operation, and
maintenance of this low intensity patio heater. You must read and understand all instructions and safety
warnings before installing or servicing the radiant tube heater.

Heater Components

Prior to installation, verify that the heater's gas type and voltage (as listed on the rating plate) match that of
your application. Also verify that you have received all heater components included with your patio heater.
Refer to page 40 for a list of the kit contents for your series heater. Materials not included in the heater kit
contents (e.g., screws, terminals, etc.) are the responsibility of the installer. Notify your product
representative or Modine of any discrepancy or missing kit contents prior to installing unit.

Specifications

Chart 1.1 • MRS Specifications
Model
Number Gas Type
MRS-15-50N Natural
MRS-15-50P Propane
* Typical or recommended mounting heights are provided as a guideline. Actual conditions may dictate variations
from this data.
This product can expose you to chemicals including lead and carbon monoxide, which are known to the
State of California to cause birth defects or other reproductive harm.
For more information, go to www.P65Warnings.ca.gov.
1.0 Introduction
BTU/h BTU/h
(High Fire) (Low Fire)
50,000 35,000
50,000 45,000
WARNING
!
California Proposition 65
3
• Overview • Heater Components
Unit
Weight Recommended
Length (lbs.) Mounting Height*
108" 115
108" 115
• Specifications
Radiant
Surface
Area
(sq. ft.)
9' to 16' 20.2
9' to 16' 20.2
