500/540/550 STD&HD, 580HD/600HD/620HD
S 4 P
3 B 1
T9.600, T9.615, T9.645, T9.670, T9.670HD, T9.700
FIT-UP & PARTS
CASE STEIGER
NEW HOLLAND T9 SERIES
MANUAL
143424 v1.2
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Degelman SILAGE KING NANT
Summary of Contents for Degelman SILAGE KING NANT
- Page 1 FIT-UP & PARTS MANUAL 143424 v1.2 CASE STEIGER D E G E L M A N I N D U S T R I E S B O X 8 3 0 - 2 7 2 I N D U S T R I A L D R I V E , 500/540/550 STD&HD, 580HD/600HD/620HD R E G I N A ,...
-
Page 3: Reference Information
QUICK GUIDE INDEX Introduction Pivot & Main Frame (No-Angle Models) Pivot & Main Frame (Models with Hydraulic Angle) Mounting Brackets Hydraulic Fitting Overview Hydraulic Routing Mounting Procedure Warranty REFERENCE INFORMATION NANT (No-Angle with No-Tilt Model) NAHT (No-Angle with Hydraulic Tilt Model) HANT (Hydraulic Angle with No-Tilt Model) HAHT... - Page 4 Introduction HARDWARE TORQUE SETTINGS MANUAL OVERVIEW The tables below give correct torque values for various The documentaion for this particular fit-up has been bolts and capscrews. Tighten all bolts to values in divided into two manuals: charts unless otherwise noted. Check tightness of bolts 1) Silage King Blade Components, Operation, periodically, using torque charts as a guide.
- Page 5 Silage King Pivot & Main Frame - Silage King Blade Models with No-Angle CASE STEIGER / NEW HOLLAND T9 OPTIONAL GRILLE GUARD 790485 - Tractor Grille Guard Assembly Mounts With: 118747 - Bolt, M20 x 80 (2) 118775 - Flat Washer, 3/4 F436 (4) 118750 - Lock Nut, M20 (2) Tow Cable (if applicable) Mounts With: 117548 - Bolt, M24 x 70 (1)
- Page 6 Pivot & Main Frame - Silage King Blade Models with Hydraulic Angle HANT (Models with No-Tilt) PIVOT & MAIN FRAME OVERVIEW 795326 - Parking Station Bracket (1) 118503 - Lock Washer, 3/8 (2) 118003 - Bolt, 3/8 x 3/4 (2) Included with Hydraulic Coupler Assembly...
- Page 7 Side/Axle Bracket CASE STEIGER/NH T9 - SIDE FRAME BRACKETS 789544 - Drill Template, Side Bracket (1) 117416 - Lock Nut, 7/8 GRC Unitorq (8) 118774 - Flat Washer, 7/8 F436 (14) 118767 - Bolt, 7/8 x 3 GR8 (2) 118954 - Bolt, 7/8 x 6 GR8 (1) 118981 - Flat Washer, 1-1/32 x 3/8 (2) 789540 - Side...
- Page 8 Side/Axle Bracket Installation CASE STEIGER/NH T9 SERIES Important: The front Dual Tires need to be removed in order for adequate clearance to drill holes in frame for bracket installation. The front end of the tractor needs to be safely and securely supported. Remove front weight stack and toolboxes.
- Page 9 Radar & Hose Holder Mounting Brackets GROUND SPEED RADAR EXTENSION BRACKET Re-use Existing Hardware to mount 789605 - Bracket, Ground Speed Radar Extension (1) 118718 - Lock Nut, 5/16 (3) Re-use Existing Bracket Radar Bracket Install Location 118731 - Flat Washer, 5/16 (6) 118145 - Bolt, 5/16 x 1-1/4 (3) FRONT TOW CABLE HOLDER BRACKET*...
- Page 10 Hydraulic Fitting Overview COMMON FITTINGS This is a quick visual reference of the most common hydraulic fittings used in our dozer blade hydraulic systems. The icon and numbers are used for reference in the routing diagrams on the following pages. Please note, this particular fit-up may only use a few of the fitting types shown in the reference chart below.
-
Page 11: Hydraulic Routing
Hydraulic Routing LIFT CYLINDER ROUTING (All Models) 126692 - Hose, 1/2 x 60 (1) 126561 - Hose, 1/2 x 82 (2) 126694 - Hose, 1/2 x 130 (1) Ports 141504 - 90° Elbow, 3/4 JIC-m x ORB (2) Face Up 141518 - 90°... - Page 12 Hydraulic Routing ANGLE CYLINDER ROUTING (HANT & HAHT) Refer to Silage King Blade Manual (For Hydraulic Angle Models) 126521 - Hose, 1/2 x 138 (2) 123227 - Cylinder, Monarch - 4-1/2 x 16 x 2-1/2 (2) (Pin-Eye Ends with Bushing Inserts / Seals) (Seal Kit: 123230) 138 138 Replacement Bushing,...
- Page 13 Hydraulic Coupler Brackets 118995 - Bolt, M10 x 65 (1) 141597 - Ball Valve, HYDRAULIC HOSE/COUPLER 118686 - Flat Washer, 3/8 USS L9 (1) 3/4 ORB (1) MOUNTING BRACKET 141616 - 45° Elbow, 118731 - Flat Washer, 5/16 (4) 3/4 JIC-m x ORB (1) 118718 - Lock Nut, 5/16 (4) 141616 - 45°...
- Page 14 Hydraulic Routing REAR HOSE ROUTING DETAIL 141504 - 90° Elbow, 3/4 JIC-m x ORB (4, 6 or 8) 141676 - Connector, 3/4 ORB-m 141581 - Quick Coupler-m - 3/4 ORB (4, 6 or 8) 141577 - Dust Cap Coupler-m (4, 6 or 8) 126610 - Hose, 1/2 x 311 (2, 4 or 6) Refer to Front Hydraulic Connection Details...
- Page 15 Mounting HYDRAULIC QUICK-TACH 10 STEP MOUNTING PROCEDURE Procedure to mount blade: Please note: The brackets, frame, & blade assembly for your particular fit-up may 1. Align the tractor behind the main frame. differ significantly from those used in the (Unhook & lower front Tow Cable - if applicable) diagram, however, the basic mounting 2.
- Page 16 2. To any goods that have sustained damage or deterioration attributable to a lack of routine maintenance (eg. Re- torque of mounting hardware.) 3. If parts not made or supplied by Degelman have been used in the connection with the unit, if, in the sole judgement of Degelman such use affects its performance, safety, stability or reliability.
