- Page 1 For C370A, C371A,C371AF For C373AF OPERATING INSTRUCTIONS Ver.4...
-
Page 2: Safety
Safety Erroneous operations cause faults or accidents. Please read over carefully these instructions contained herein before installation, and use this unit properly in the optimum method. ●In this section, safety motes are shown under two categories, “Warning” and “Caution”. Warning: If not observed, mortal or serious injury may result. Caution: If not observed, minor or moderate injury, objective damage may result. -
Page 3: Precautions In Installation Site
Cautions・Before cleaning, maintenance, or inspection, pull out the socket from the wall outlet and make sure that there is no power supply. If not observer, injury or electric shock may result. Cautions・Please consult your local sales agent for repair. If not repaired properly, it may cause electric shock or fire Caution：The measure attached to this unit is only for reference. -
Page 4: Table Of Contents
This machine is designed to be used in conjunction with CASTING as an option. Because this manual deals with the use of CSL-501 / CSL-503 in connection with CASTING, should you find any terms or points which you are unclear about, please... -
Page 5: Name Of Each Part
1. NAME OF EACH PART Slitting lade cassette Chuck Stopper Main pressure Chuck pressure adjustment knob adjustment knob Main pressure dial Dial chuck pressure Main pressure Plug receptacle (attachment) Brace Adjustment valve Chuck pressure Fuse holder... -
Page 6: Installation （For C37_A Series
2. INSTALLATION （For C37_A series ） ① Open the operation panel after checking if the power switch for casting is Off. ② Plug the connecter A of the provided harness into the S5 (green) on the board which is back of the operation panel. Plug the Pin B of the provided harness into the 7 of the SOL1-4 connecter and the Pin C into the 8... - Page 7 ③The provided harness should be wired inside the unit like the left picture. When closing the operation panel, make sure that the harness does not get into touch with the「Cutter Sensor」. Cutter Sensor ④Plug the connecter D into the hole for 4P of the power box.
- Page 8 ③ Attach the brace to CSL-501 / CSL-503 by the 4×8 cap screws, and to the main body of CASTING by the 5×15 cap screws. 4×8 Cap screw C371 5×15 Cap screw...
- Page 9 ④Plug the black 4P into the black 4P of the back side of CSL-501 / CSL-503 and the opposite side of the black 4P into the black 4P of the back side of the casting respectively. Black 4P 黒４Ｐ 白８Ｐ...
-
Page 10: When Changing To Use Flat Cables With C371A
3. WHEN CHANGING TO USE FLAT CABLES WITH C371A Diagram SG unit Cutter block Righthand wire guide ① The power switch for C371A should be OFF. ② Unscrew the two screws A and remove the wire roller guide unit. (See Diagram ③... - Page 11 ⑤ Unscrew the three screws D in Diagram 1, and remove the SG unit. As the SG unit harness is joined part way by a relay connector, these two connections must be pulled apart. (See Diagram 3) Green Diagram 3 Relay connector Green Substitute the removed unit for the flat cable SG unit.
- Page 12 ⑦ Attaching the guide pipe to the SG unit, tighten screw E. (See blow) ⑧ Entering-guide set adjustment Loosen screws F and make adjustment so that the width of the guide matches exactly that of the flat cable, but allowing for sooth advancement of the wire, then tighten screws F.
-
Page 13: Operation
③ The slitting length should be set. (See P.14 setting of slitting length) ④ CASTING settings should be made. {Example} If the wire below is to be processed : 30mm 30mm Slitting length - 60mm ・・・ CSL-501 / CSL-503 Front & rear end slitting - [Motion][Slitter][Slitter] ・・・ CASTING ［Front Slit Point］［３］［０］［ＳＥＴ］... - Page 14 CHUCK PRESSURE ADJUSTMENT For adjustment the wire gripping pressure : Pull the pressure adjustment knob up and turn anti-clockwise to reduce the pressure. As the dials only read during operation, do the adjusting at this time. Main pressure Chuck pressure adjustment knob adjustment knob Main pressure dial...
-
Page 15: Setting Of Slitting Length
SETTING OF SLITTING LENGTH Slitting length = Total length to be slit at front and rear ends. Front end Rear end Loosen the four stopper cap screws and adjust the stopper. Line up the stopper standard indicating line with the measurement scale with respect to the desired length. -
Page 16: How To Set The Casting
For example, if the slit size of CSL-501 / CSL503 is set by ３０ｍｍ, front end slit is set by 15mm, and 「Middle Silt Point」 is set by ５０mm, Middle Slit will be began from the distantly positioned point of 15mm for front slit + 50mm to the front end by 30mm. - Page 17 １５ｍｍ ３０ｍｍ １５ｍｍ ５０ｍｍ ★Caution★ ・Please note that the length of the middle slit is equal to the slit length （total of the front and rear end slit sizes）. ・If the value of the middle slit is longer than the total length, it will occur an error.
-
Page 18: Special Usage Of Csl-501 / Csl503
SPECIAL USAGE OF CSL-501 / CSL503 Usually the slit length that CSL-501 / CSL503 can process is that the total slit length of front and rear is under 200mm. But when you process following the procedure below, you can process the wire that the total slit length of front and rear is under400mm. -
Page 19: Blade Replacement
5. BLADE REPLACEMENT * Important: Make sure the power is OFF before beginning blade replacement. ･ Slitting blade cassette replacement : When you remove cap screws A (below) you will be able to remove the cassette. * Because the upper cassette contains the slitting blades, take extra care with it. * After replacing release the air pressure and check that the upper lower cassettes bite together perfectly. -
Page 20: Chuck Gripper Replacement
6. CHUCK GRIPPER REPLACEMENT Loosen the four screws A above and below, then remove each of the two grippers and replace. -
Page 21: Specifications
SPECIFICATIONS Model CSL-501 / CSL-503 Drive Air cylinder Power Source AC 100V or AC220V Single 50/60Hz Power Consumption 5W (at AC100V) Maximum Slitting Length 200mm Operational Pressure 4～7kg/㎠ Range CSL-501 : 18mm Maximum Wire Width CSL-503 : 40mm CSL-501 : Ｗ:500mm×D:325mm×H:230mm Outer Dimensions CSL-503 : W:550mm×D:310mm×H:270mm...
