- Page 1 Instruction Manual Ver.5...
-
Page 2: Safety Precautions
Safety Precautions If you do not operate this device properly, it may result in failure or accident. Please read through this instruction manual before operating the device. ●In this manual, safety precautions are indicated with “Warning” or “Caution”. Warning ：If you don’t observe this item properly, it may result in death or severe injury. -
Page 3: Precautions For Installation
Caution：Don’t stand or put a object on the unit. It may result in injuries due to drop or fall over. Caution：Before cleaning, maintenance or inspection, make sure to remove the power cable and check if the unit is not energized. It may result in electric shock. -
Page 4: Table Of Contents
Contents Safety Precautions ..................1 Precautions for Use ..................1 Precautions for installation ................2 Contents ...................... 3 Name of various parts ................... 3 １．How to attach the ＣＡＳＹ－６３７A .............. 4 ＜How to attach the ＣＡＳＹ－６３７A main body＞ ........4 ＜Adding of the Harness Inside the C370A＞... -
Page 5: １．How To Attach The Ｃａｓｙ－６３７A
１．How to attach the CASY-637A ＜How to attach the CASY-637A main body＞ ①Loosen the screw A to remove the air-nozzle, which is on the observers’ right, of the C370A cutter block. And then mount a provided air-nozzle for the CASY-637A. Ａ... - Page 6 ④Mount the CASY-637A main body to the fixing base. Make sure to set the pins of the body in the holes of the fixing base and fasten the screw C. Ｃ ⑤Adjust the level of the CASY-637A to the level of the C370A with the adjuster.. CASY-637A ＜How to Mount the CASY-637A Control Box＞...
-
Page 7: Adding Of The Harness Inside The C370A
＜Adding of the Harness Inside the C370A＞ ①Open the operation panel after removing the power cable of Ｃ370Ａ. ②Plug the provided harness connecter into the M5M6 (green) of the main board which is at the back of the operation panel. Plug the provided harness connecter B into the S6 (blue) of the main board. - Page 8 ③ Wire the provided harness inside device. When closing operation panel, make sure that the harness doesn’t touch the cutter Cutter Sensor sensor. カッターセンサー ④Plug the connecter C into the hole for 8P of the power box. The power box has several connectors for connecting to other devices. In order to prevent damage to the internal board due to incorrect connection, it is recommended to push unused connectors into the power supply box or attach empty connectors.
-
Page 9: External Connection
＜External Connection＞ Harness C Harness B Harness D ①Attach the Harness B・C・D like the picture. Be careful not to misconnect each harness. Incorrect connection may damage the internal board and render it inoperable. ② Connect up the power cord to the outlet of the back of the control box and the wall. -
Page 10: ２．Setting Screen
２．Setting Screen On the screen above, all the items which are to be displayed by the CASY-637A are displayed for purposes of illustration. According to the setting, there are some items to be displayed or not to be displayed. ①《CASY637A》：Select this function when using a twisting machine （CASY-637A）. The display changes depending on the situation of CASY-637A. - Page 11 ③《Normal Twist》《Reverse Twist》：Setting of the twisting direction at front side. Every touching, ･･･it switches. Ｂ Ａ Position of K-blades Position of K-blade when Knob for K-blade when knob to the left knob turn to the right Original twisting of a wire Front side Rear side Front side...
- Page 12 ⑦《Cutting Length》：Setting of the length when cutting after twist. It is displayed when selecting 《Cut After Twist》. On the picture above, [３] has been set. ⑧《Sheath Diameter》：Diameter of the sheath of the wire which is processing. (The K- blade twists by gripping the sheath.) ⑨《Twist》：Setting of twist function at rear side.
-
Page 13: ３．How To Handle The Ｃａｓｙ－６３７A
３．How to handle the CASY-637A ①Turn ON the power switch of the ＣＡＳＹ-６３７A Control Box. （At this point, the switch does not light.） ＯＮ ＯＦＦ ②Turn ON the power switch of the Ｃ３７０A.（Only when Ｃ３７０Ａ is ＯＮ, the control box becomes ON.） The K-blade of the ＣＡＳＹ-６３７A opens after closing. （It returns to the original point.）... - Page 14 ④Step by step processing begins by ［START］. ⑤Furthermore touch [Next] several times so that the K-blade grips the sheath which has been half-stripped. This is the value of 《Sheath Diameter》. At this time, check the condition that the K-blade is gripping the wire. If the wire is pressed too much, make the value of the 《Sheath Diameter》...
-
Page 15: ４．Replacement Of K-Blade
４．Replacement of K-blade K-blades are consumable goods. Replace them just like below. ①Turn the power OFF. ②Remove the 4 screws below to uncover the machine cover. ③Remove the 2 screws which fix the K-blade. ④After replacing a new K-blade, temporarily fasten it with the screws which have been removed at ③. -
Page 16: ５．Trouble Shooting
５．Trouble Shooting・・・ ◎K-blade steps out. →The position of the K-blade is wrong when starting? Refer to the seal which is on the upper side of the CASY-637A main body. ◎Twist is weak. →In some cases, wires become better just by making the value of the half strip a little bit smaller. -
Page 17: Specifications
Specifications Model CASY-637A Outer CASY-637A Main body W260mm×H155mm×D235mm dimensions Control Box W60mm×H260mm×D315mm CASY-637A Main body 6.5kg(NET) Weight Control Box 5.0kg(NET Power Supply AC100V ～ AC220V single (50/60Hz) Voltage Power 70VA(max.) (At 100V) Consumption Twist Capability Longer than 3ｍｍ at front and rear end. 0.03sq ~ 2.0sq (AWG #32 ~ 14) Wire size (Depends on the wire)
