- Page 1 Quad Monitor Desk Mount STAND-V004 Assembly Manual...
- Page 2 Better Products for a Better Workspace Experience We are dedicated to creating high-end ergonomic solutions for the office with top of the industry support. Explore Endless Workspace Solutions www.vivo-us.com...
- Page 3 If you do not understand these directions, or if you have any doubts about the safety of the installation, please contact our product support team at 309-278-5303 or help@vivo-us.com for further assistance. Check carefully to make sure there are no missing or defective parts. Failure to report missing parts within 30 days may result in denial of free replacement.
-
Page 4: Package Contents
Package Contents A (x4) C (x1) D (x1) B (x2) VESA Plate Clamp Lower Pole E (x1) F (x1) G (x2) H (x1) I (x4) Upper Pole Pole Connector Pole Cable Clip Grommet Plate VESA Cap J (x1) K (x5) L (x8) M (x1) Pole Cap... -
Page 5: Assembly Steps
Assembly Steps STEP 1 Press Pole Cap (J) into Upper Pole (E). -
Page 6: Option 1: Clamp Installation
STEP 2 Option 1: Clamp Installation Remove adhesive backing from Rubber Pads (K) and apply to the underside of Clamp (C). Attach Lower Pole (D) to Clamp using M5x16mm Screws (S-B). Tighten using 4mm Allen Wrench (T-B). Clamp the assembly to the desktop. 10-88mm Proceed to STEP 3 on Page 8... - Page 7 Option 2: Grommet Installation Disassemble the Clamp (C) using a Phillips screwdriver and remove the Clamp Bolt (C1). Remove adhesive backing from Rubber Pads (K) and apply to the bottom of Grommet Plate (H). Place Support Plate (M) onto Clamp Bolt (C1) and thread it through the grommet hole and into Lower Pole (D) as shown.
- Page 8 STEP 3 Slide one Pole Cable Clip (G) onto Lower Pole (D) and Arm Cable Clips (L) onto Arms (B). Slide Arm down Lower Pole at the desired height and secure by tightening the back screw using 6mm Allen Wrench (T-D).
- Page 9 STEP 4 Thread Pole Connector (F) onto Lower Pole (D), then thread Upper Pole (E) into Pole Connector. Poles Won’t Thread Into Connector? If Poles (D,E) are difficult to thread into Pole Connector, the two set screws may need to be loosened.
- Page 10 STEP 5 Slide the remaining Pole Cable Clip (G) and Arm (B) down Upper Pole (E) at the desired height. Secure by tightening the back screw using 6mm Allen Wrench (T-D).
- Page 11 STEP 6 Use 5mm Allen Wrench (T-C) to adjust the Arm (B) joint tension. ** WARNING ** To avoid the risk of damaging monitors, never adjust the tension with monitors installed. Secure VESA Plates (A) to the back of monitors using approprate Screws (M-A thru M-D) and M5 Washers (M-E).
- Page 12 STEP 7 Slide VESA Plates (A) with monitors attached onto Arms (B). Secure monitors using VESA Caps (I) and M3x8mm Screws (S-A), tightening with a Phillips screwdriver. Tighten the Tilt Joint Screws (B1) on Arms (B) using 6mm Allen Wrench (T-D) to secure the monitors in a straight position.
- Page 13 STEP 8 Use Cable Clips (G,L) to manage cables. Store Allen Wrenches (T-A thru T-D) in Pole Cable Clips (G).
- Page 14 Adjustments Turn the VESA Caps (I) using 6mm Allen Wrench (T-D) to shift the monitors up or down. Adjust as desired. +45° 360° -45° +45° 360° -45° +45° 360° 360° +45° -45° 360° -45°...
- Page 15 Love Your New Setup? Tag Us on Social! @ VIVO-us @ vivo_us @VIVOus VIVO...
- Page 16 Need Help? We’re Here For You Monday-Friday from 7am-7pm CST Saturday 8am-4pm CST Email Us Chat with Live Agent Give Us a Call help@vivo-us.com www.vivo-us.com 309-278-5303 ext. 1 FOR MORE GREAT VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: WWW.VIVO-US.COM VIVO-us @vivo_us @VIVOus VIVO...
