INDOOR UNIT
OUTDOOR UNIT
Air outlet grille
Note: all the illustrations in this manual are for explanation purpose only. Your air conditioner may be slightly
different. The actual shape shall prevail.
V 06/24
DESCRIPTION OF PARTS
Air inlet grille
Panel
Air filter
Air louver
Air vent
Air outlet
Air inlet
Emergency button
Air outlet
Air inlet
Pipe protection ring
Connecting pipe
Drain hose
37
