EN
PORTABLE AIR CONDITIONER (LOCAL)
CRONO
OPERATING INSTRUCTIONS
Read the instructions carefully before operating the appliance or carrying out maintenance work.
Observe all the safety instructions; failure to do so may lead to accidents and/or damage. Store these
instructions in a safe place for future reference.
V 12/19
17

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CRONO and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Argo CRONO

Summary of Contents for Argo CRONO

  • Page 1 PORTABLE AIR CONDITIONER (LOCAL) CRONO OPERATING INSTRUCTIONS Read the instructions carefully before operating the appliance or carrying out maintenance work. Observe all the safety instructions; failure to do so may lead to accidents and/or damage. Store these instructions in a safe place for future reference.
  • Page 2 Appliance filled with flammable gas R290. Before installing and using the appliance, read the owner’s manual. Before repairing the appliance, read the service manual. The Refrigerant R290  To realize the function of the air conditioner unit, a special refrigerant circulates in the system.
  • Page 3 GENERAL OPERATING AND SAFETY INSTRUCTIONS  This appliance is a local air conditioner designed for domestic use.  Only use this air-conditioner as described in this manual.  Ensure that the required voltage and frequency (220-240V/50 Hz) match the available power source. ...
  • Page 4  Do not use the plug as a means by which to start/stop the air conditioner: use the ON/OFF button on the remote control or on the control panel.  Do not install the air conditioner in rooms where it may receive water splashes (e.g.
  • Page 5 PRECAUTION!  Do not insert any objects into the air conditioner: this is very dangerous as the fan turns at high speed.  Ensure that air circulates freely around the unit. Do not cover the air intake and delivery grilles with drapes or any other means.

  • Page 6: Description Of The Appliance

     Close all open windows to maximise air conditioning efficiency. The manufacturer will not be held liable if safety and accident prevention rules are not observed. DESCRIPTION OF THE APPLIANCE FRONT VIEW REAR VIEW UPPER PANEL 8) BASE CONTROL PANEL 9) UPPER FILTER SIDE PLATE 10) CONTINOUS DRAINAGE HOLE (DEHUMIDIFICATION)

  • Page 7: Appliance Start-Up

    PRE-OPERATING CHECKS AND OPERATIONS The following space must be maintained to ensure the operating efficiency of the portable air conditioner. 50 cm 50 cm APPLIANCE START-UP Open the packaging and pull out the box. Remove the product and the other elements supplied (illustrated in the box below).
  • Page 8 USE WITH END FITTING FOR WINDOW 1. Stretch the flexible hose sufficiently so that it 2. Open the window and lock one of the two leaves reaches the outside (max 1.5 m) and hook it to the rear with the handle. part of the air conditioner.

  • Page 9: How To Use The Appliance

    Connect the power cord to a suitable electric socket (220–240 V). Insert the supplied batteries into the remote control and make sure the poles match. Select the desired operating mode from the remote control. Avoid tight bends or folds in the hose. If the air conditioner is not used for prolonged periods, disconnect the pipe and plug the window unit.

  • Page 10: Operating Modes

    OPERATING MODES 1. COOLING MODE  The “Cool” LED on the control panel will turn on.  The temperature can be adjusted to between 16 °C and 31 °C.  In this mode, each time the ON/OFF button is pressed the unit switches off, the appliance saves the temperature setting and retains this setting when it is switched on again.

  • Page 11: Remote Control Operation

    Continuous drainage Dehumidification WARNING! When using the air conditioner in dehumidification mode, it is advisable to always arrange for continuous drainage, so as to maximise dehumidification efficiency. Connect one end of the PVC pipe (not provided) to the upper discharge hole and place the other end above a drain.
  • Page 12 FOR OPTIMAL REMOTE CONTROL OPERATION, POINT THE TRANSMITTER HEAD TOWARDS THE RECEIVER ON THE AIR CONDITIONER. ON/OFF BUTTON TIMER BUTTON DOWN BUTTON MODE BUTTON UP BUTTON FAN BUTTON SLEEP BUTTON 1) ON/OFF BUTTON 7) MODE BUTTON (FAN) 2) DOWN BUTTON 8) MODE BUTTON (DEHUMIDIFICATION) 3) UP BUTTON 9) MODE (COOLING)
  • Page 13 (1) ON/OFF BUTTON Press this button to switch the unit on or off. (2) DOWN BUTTON Press this button to adjust the temperature and set the time. (3) UP BUTTON Press this button to adjust the temperature and set the time. (4) SLEEP BUTTON In cooling mode, press the UP and FAN buttons to activate the Sleep mode, after which the unit will return to the silent mode and save energy.

  • Page 14: Care And Maintenance

    CARE AND MAINTENANCE WARNING! Before carrying out any cleaning or maintenance operations, unplug the appliance. Cleaning the air filters The air filters must be checked at least once every two weeks of use. Operating the appliance with dirty or clogged filters will decrease the air conditioner's efficiency and may cause serious problems.
  • Page 15 REGULATION (EU) No. 517/2014 – F-GAS The unit contains R290, a natural greenhouse gas with global warming potential (GWP) = 3 - Kg. 0.13 = 0.00039 Tons CO equiv. Do not release R290 into the atmosphere. INFORMATION FOR THE CORRECT DISPOSAL OF THE PRODUCT IN ACCORDANCE WITH EUROPEAN DIRECTIVE 2012/19/EU This appliance may not be scrapped with domestic waste at the end of its life cycle.
