- Page 1 TECHNICAL DATA & SERVICE MANUAL ULISSE 13PCLA AUG38PCLI Model No. Product Code No. AUG38PCLI 39.7028.942 0.8180.516.0 11/2006...
- Page 2 IMPORTANT! • Ground the unit following local electrical codes. Please read before installation • The Yellow/Green wire cannot be used for any connection different from the ground connection. • Connect all wiring tightly. Loose wiring may cause overheating This air conditioning system meets strict safety and operating at connection points and a possible fire hazard.
-
Page 3: Table Of Contents
Table of Contents Page 1. SPECIFICATIONS 1-1 Unit specifications 1-2 Major Component specifications 1-3 Other Component specifications 2. DIMENSIONAL DATA 2-1 Unit Dimensions 3. REFRIGERANT FLOW DATA 3-1 Refrigerant Flow Diagram 4. ELECTRICAL DATA 4-1 Electric Wiring Diagram 5. PERFORMANCE DATA 5-1 Performance Chart 6. -
Page 4: Specifications
1. SPECIFICATIONS 1-1 Unit Specifications AUG38PCLI 230 V ~ 50 Hz Power Source Voltage Rating 198 - 264 Available Voltage Range 5,60 Running Ampere 1245 Power Input 0,96 Power Factor 3,21 C.O.P. Compressor Locked Rotor Amperes Performance 13640 Capacity BTU/h... -
Page 5: Major Component Specifications
1-2 Major Component Specifications AUG38PCLI Controller PCB SAC ON-OFF IDU Model Microprocessor Controls 250VAC - 3,15A - T Control Circuit Fuse (F1) 2,54mm - 5 pcs Jumper Setting JP1 … JP5 SAC WREM Remote Control Unit NTC (with Brass Pipe) Thermistor Coil Sensor 10 ±... -
Page 6: Other Component Specifications
AUG38PCLI Condensate Pump PC 95643 Model 230V - 50Hz Rating 12 ± 10% Nominal Input Coil Resistance at 20°C Ω 122 ± 10% Safety Float Switch F83161,3 Model 10(4)A - 250VAC Contact Rating Float Open Close Down Heat Exchanger Coil (Evaporator) -
Page 7: Dimensional Data
2. DIMENSIONAL DATA 2-1 Unit Dimensions AUG38PCLI... -
Page 8: Refrigerant Flow Data
3. REFRIGERANT FLOW DATA 3-1 Refrigerant Flow Diagram... -
Page 9: Electrical Data
4. ELECTRICAL DATA 4-1 Electric Wiring Diagram Controller SWITCH Switch Assy Indoor fan motor Indicator assy Compressor motor Thermistor Overload relay Terminal plate Outdoor fan motor Float switch Capacitor Drain Pump... -
Page 10: Performance Data
5. PERFORMANCE DATA 5-1 Performance Chart Operation characteristics with relative humidity around 50%. AUG38PCLI 32 °C 27 °C 21 °C EXTERNAL TEMPERATURE (°C) -
Page 11: Functions
6. FUNCTIONS 6-1 Cool Mode Operation In Cooling Mode, the operation of the compressor (CM), Outdoor Fan (FMO) and Indoor Fan (FMI) are determined by the difference between the room air temperature (RAT) and the set point temperature (SPT) as shown in the graph. NOTES 1. -
Page 12: Dry Mode Operation
6-2 Dry Mode Operation Dry operation remove moisture from indoor air running, in cooling mode, at a low level without reducing the ambient temperature. This is done cycling ON and OFF indoor and outdoor units according to below. ROOM DRY LEVEL TEMPERATURE ≥... -
Page 13: Forced Mode
6-5 Forced Mode In this mode the system operates (COOLING or HEATING mode – fixed settings) or is switched off by means of the MODE button of the indoor unit control board. The operation modes can be selected pressing the button in a cyclic way (OFF COOL HEAT OFF…). -
Page 14: I Feel Function
6-7 I FEEL Function As standard configuration the air conditioner operates detecting the room temperature through the sensor equipped in the wireless remote controller (icon I FEEL shown on the display). This feature provides a personalised environment since the temperature can be detected where the remote controller is located. It is possible to de-activate this option pressing the I FEEL button on the remote controller. -
Page 15: Diagnostic
7. DIAGNOSTIC With this feature is possible to have a visual signal that a trouble is occurring. This mode is always active and the signalling is made through the display board LEDS . In case of no troubles the LEDS status follows its normal function. NOTES The troubles are showed according a priority list that is in case of more than one trouble present, is always showed, at first, the one with the highest priority (1... -
Page 16: Jumpers Configuration
8. JUMPERS CONFIGURATION Jumpers are located on the indoor PCB near the MODE button. Unit is shipped with jumpers set according to the following table: JUMPER STATUS open closed open closed closed... -
Page 17: Maintenance
9. MAINTENANCE Changing the Address of the Air Conditioner In case of more than one air conditioner operating in the same room, it may be necessary to assign an address to each unit in order to avoid operation conflicts. Address is set acting on the dip-switches located on the indoor PCB and on the remote controller. -
Page 18: Troubleshooting
10. TROUBLESHOOTING CHECK BEFORE AND AFTER «TROUBLESHOOTING» (A) Check power supply wiring. • Check the power supply wires are correctly connected. (B) Check power supply. • Check that voltage is in specified range (±10% of the rating). • Check that power is being supplied. •... - Page 19 2 • The unit does not run. C WATER LEVEL ALARM - OPERATION LAMP IS BLINKING. Malfunctioning of the condensate drainanege system. NOTE: In case of emergency the air conditioner can work by draining the condensate from the little pipe into a rather short container. Extract the little pipe and remove the cap.
- Page 20 D UNIT AND COMPRESSOR DO NOT RUN. The unit does not run when air conditioner is in the follwing conditions: • When the room temperature is below the setting temperature. • During the protection modes.
- Page 21 E SOME PARTS OF THE AIR CONDITIONER DO NOT OPERATE.
- Page 22 F AIR CONDITIONER OPERATES, BUT ABNORMALITIES ARE OBSERVED.
- Page 24 G POOR COOLING OR HEATING.
- Page 25 H EXCESSIVE COOLING OR HEATING. I A SENSOR IS DEFECTIVE.
-
Page 26: Checking Electrical Components
11. CHECKING ELECTRICAL COMPONENTS... - Page 28 Via Varese, 90 - 21013 Gallarate - VA - Italy Tel. +39 0331 755111 - Fax +39 0331 776240 www.argoclima.com...
