DECLARATION OF CONFORMITY
This product is marked
– Low voltage no. 73/23 EEC and 93/68 EEC.
– Electromagnetic compatibility no. 89/336 ECC, 92/31 EEC
and 93/68 EEC.
This declaration will become void in case of misuse and/or non
observance though partial of manufacturer's installation and/or
operating instructions.
COOLING ONLY MODELS
OPERATING LIMITS
Maximum conditions
Outdoor temperature : 43°C D.B.
Room temperature
: 32°C D.B. / 23°C W.B.
Minimum conditions
Outdoor temperature : 19°C D.B.
Room temperature
: 19°C D.B. / 14°C W.B.
HEAT PUMP MODELS
OPERATING LIMITS
Cooling Maximum conditions
Outdoor temperature : 43°C D.B.
Room temperature
: 32°C D.B. / 23°C W.B.
Cooling Minimum conditions
Outdoor temperature : 19°C D.B.
Room temperature
: 19°C D.B. / 14°C W.B.
Heating Maximum conditions
Outdoor temperature : 24°C D.B. / 18°C W.B.
Room temperature
: 27°C D.B.
Heating Minimum conditions
Outdoor temperature : –8°C D.B. / –9°C W.B.
ACCESSORIES SUPPLIED WITH THE UNIT
PARTS
FIGURE
Q.TY
RAWL PLUG
5/7
TAPPING
5/7
SCREW
REMOTE
1
CONTROL UNIT
AAA ALKALINE
2
BATTERY
*
Available only for AE518DH.
as it satisfies Directives:
PARTS
FIGURE
Q.TY
DRAIN
1
*
ELBOW
AIR CLEAN
2
FILTER
37.4140.312.0
INSTALLATION INSTRUCTIONS
- Split system air conditioner -
Model Combinations
Combine indoor and outdoor units only as listed below.
COOLING ONLY MODELS R22
Indoor Units
AWR609CL x 2
AFR609CL x 2
ASR609CL x 2
AWR609CL
AFR609CL
AWR609CL
ASR609CL
AFR609CL
ASR609CL
AWR612CL x 2
FCR612CL x 2
ASR612CL x 2
AWR612CL
FCR612CL
AWR612CL
ASR612CL
FCR612CL
ASR612CL
HEAT PUMP MODELS R22
Indoor Units
AWR509DHL x 2
AFR509DHL x 2
AWR509DHL
AFR509DHL
COOLING ONLY MODELS R407C
Indoor Units
AWR609CL x 2
AFR609CL x 2
ASR609CL x 2
AWR609CL
AFR609CL
AWR609CL
ASR609CL
AFR609CL
ASR609CL
AWR612CL x 2
FCR612CL x 2
ASR612CL x 2
AWR612CL
FCR612CL
AWR612CL
ASR612CL
FCR612CL
ASR612CL
HEAT PUMP MODELS R407C
Indoor Units
AWR509DHL x 2
AFR509DHL x 2
AWR509DHL
AFR509DHL
Power Supply:
02/2002
EG
I
Outdoor Units
AE518DC
F
AE518DC
AE518DC
D
AE518DC
AE518DC
E
AE518DC
P
AE524DC
AE524DC
GR
AE524DC
AE524DC
AE524DC
AE524DC
Outdoor Units
AE518DH
AE518DH
AE518DH
Outdoor Units
AER518DC
AER518DC
AER518DC
AER518DC
AER518DC
AER518DC
AER524DC
AER524DC
AER524DC
AER524DC
AER524DC
AER524DC
Outdoor Units
AER518DH
AER518DH
AER518DH
220 - 240 V ~ 50 Hz
