No. Name
4 Status Bar
5 Time
6 Arm/disarm
7

Setting

8 SOS
9 Monitor
Setting
6.2

6.2.1 Ring Settings

Set VTO ring, VTH ring, alarm ring and other rings.
6.2.1.1 VTO Ring
Set a ring for the connected VTO, and support to set maximum 20 VTOs.
Press [Setting].
Description
: Wired network connection icon, meaning that the device
isn't connected with network.
: Wired network connection icon, meaning that the device
has connected with network in a wired way.
: Wi-Fi network connection icon, meaning that the device
has connected with network in a wireless way.
: Main VTO connection icon, meaning that the device failed
to connect main VTO; without this icon, the device has
connected with main VTO successfully.
: SD card icon, meaning that SD card has been inserted into
the device; without this icon, the SD card has not been inserted
or the device doesn't support SD card.
: DND (Do Not Disturb) icon, meaning that the device has
enabled DND function. It is not enabled by default.
Display date, day of the week and time.
Display the last unread alarm info.
: press this icon to enter arm mode selection.
Press [Setting], input login password and enter system setting
interface.
Press [Setting] for over 6 seconds, input the password set
during initialization, and enter project setting interface.
Press this icon to call Management Center.
Monitor the VTO, fence station, IPC, NVT, HCVR and XVR.
Table 6-1
Interface Operation 41
