How to Connect VTO and VTH

Equipment Model

Firmware

Course Version

Date

General_VTOXXX_Eng_P_16M_V3.120.0000.0.R

VTO2000A

.20170803

General_VTH151X_Eng_P_V4.000.0000.0.R.201

VTH1550CH

70803

V1.0

2017/10/30

Software Version: 2.420.0000.14.R, build :

IPC-HDW1220SN

2016-04-18

iOS Version 3.49.001

DMSS

iDMSS Lite

Need help?

Do you have a question about the VTO2000A and is the answer not in the manual?

Questions and answers

Summary of Contents for Dahua VTO2000A

Page 1 How to Connect VTO and VTH Equipment Model Firmware Course Version Date General_VTOXXX_Eng_P_16M_V3.120.0000.0.R VTO2000A .20170803 General_VTH151X_Eng_P_V4.000.0000.0.R.201 VTH1550CH 70803 V1.0 2017/10/30 Software Version: 2.420.0000.14.R, build : IPC-HDW1220SN 2016-04-18 iOS Version 3.49.001 DMSS iDMSS Lite...
Page 2 1 VTO n VTO 1 VTH m VTH m VTH You should set up VTO and then set up VTH to successfully connect those two  types of devices. Page1 Copyright © 2017 Dahua Technologies Co., Ltd. All rights reserved.
Page 3 ② Then input username and password ③ Click on login Note: VTO default IP address is 10.22.5.189 or 192.168.1.110. Default username and password are both ‘admin’. Please change user password after first time login. Page2 Copyright © 2017 Dahua Technologies Co., Ltd. All rights reserved.
Page 4 MGT; if not necessary, just keep default. For Note: the setting range of VTO number is 6901~6999, and the number detailed configuration instructions, please refer to How to format is 69XX. Configure: SmartPSS). Page3 Copyright © 2017 Dahua Technologies Co., Ltd. All rights reserved.
Page 5 VTO Web Config Main VTH Setup ⑦ Select System Config>Indoor Management， ⑧ Add the indoor monitor’s room NO, and click Click “add” button to add VTH “OK”, save the setting. Page4 Copyright © 2017 Dahua Technologies Co., Ltd. All rights reserved.
Page 7 ① On the VTH’s screen, please long press ‘Setting’ for 6 seconds until the “Password Verification” is appeared. ② Input VTH Project password 888888. ③ Click “OK” to go to the new set page. Page6 Copyright © 2017 Dahua Technologies Co., Ltd. All rights reserved.
Page 8 ⑤ According to VTO config, input room No. It need be same with the VTH short No. ⑥ The default Config is “Master”, it means the VTH is the main VTH. ⑦ Click “OK”, save the setting. Page7 Copyright © 2017 Dahua Technologies Co., Ltd. All rights reserved.
Page 9 Choose “ON” to open the enable status. After the above operation steps, if the icon of right top of the screen change from , it means you can make a call between VTO and VTH. Page8 Copyright © 2017 Dahua Technologies Co., Ltd. All rights reserved.
Page 10 No’, such as 101. Refer to page 8. ③ Reboot the device. Note: If there are more than 2 VTHs, you can set group call function of VDP. Maximum support for 5 VTH. Page9 Copyright © 2017 Dahua Technologies Co., Ltd. All rights reserved.
Page 11 Extension VTH Setup ① Master VTH add VTO. Set room number as 101. Add VTO2000A in ‘VTO Config’ and enable it. （ Refer to page10-12 ） ② Extension VTH add VTO. Setup extension VTH’s room number in ‘VTH Config’, press ‘Master’ and switch to ‘Extension’. Set the room number as 101-1 ③...
Page 12 VTH, and then enable it. After the above operation steps, if the icon of right top of the screen change from , it means you can make a call between VTO and VTH. Page11 Copyright © 2017 Dahua Technologies Co., Ltd. All rights reserved.
Page 13 VTH in the ‘VTH Short No’ box, such as 101. ③ Reboot the device. In IP villa system, it maximum supports 20 VTO and 5 VTH. Page12 Copyright © 2017 Dahua Technologies Co., Ltd. All rights reserved.
Page 14 VTH in the ‘VTH Short No’ box, such as 101. In IP villa system, it maximum supports 20 VTO and 5 VTH. ③ Reboot the device. Page13 Copyright © 2017 Dahua Technologies Co., Ltd. All rights reserved.
Page 15 Note: maximum support 5 VTH (1 main VTH and 4 extension VTH). The master VTH’s room number is set as 101, and extension VTH’s room number should set as 101-1,101-2,101-3,101-4. Page14 Copyright © 2017 Dahua Technologies Co., Ltd. All rights reserved.
Page 16 VTH. You need to enable it.. After the above operation steps, if the icon of right top of the screen change from , it means you can make a call between VTO and VTH. Page15 Copyright © 2017 Dahua Technologies Co., Ltd. All rights reserved.
