Chapter 8 BIOS ROM
8.2

ROM FLASHING

The system BIOS firmware is contained in a flash ROM device that can be re-written with BIOS
code (using the ROMPAQ utility or a remote flash program) allowing easy upgrading, including
changing the splash screen displayed during the POST routine.

8.2.1 UPGRADING

Upgrading the BIOS is not normally required but may be necessary if changes are made to the
unit's operating system, hard drive, or processor. All BIOS ROM upgrades are available directly
from Compaq. Flashing is done either locally with the CPQFLASH Windows program, a
ROMPaq diskette or remotely using the network boot function (described in the section 7.3.2).
This system includes 64 KB of write-protected boot block ROM that provides a way to recover
from a failed flashing of the system BIOS ROM. If the BIOS ROM fails the flash check, the boot
block code provides the minimum amount of support necessary to allow booting the system from
the diskette drive and re-flashing the system ROM with a ROMPAQ diskette. Note that if an
administrator password has been set in the system the boot block will prompt for this password by
illuminating the caps lock keyboard LED and displaying a message if video support is available.
A PS/2 keyboard must be used during bootblock operation.
Since video may not be available during the initial boot sequence the boot block routine uses the
Num Lock, Caps Lock, and Scroll Lock LEDs of the PS/2 keyboard to communicate the status of
the ROM flash as follows:
Table 8-1. Boot Block Codes
Num Lock
LED
Off
On
Off
On
8-2 hp compaq d330 and d530 Series of Personal Computers
Featuring the Intel Pentium 4 Processor
Table 8-1.
Boot Block Codes
Cap Lock Scroll Lock
LED LED
On Off
Off Off
Off On
On On
First Edition - June 2003
Meaning
Administrator password required.
Boot failed. Reset required for retry.
Flash failed.
Flash complete.
