Door Lock Harness, 3-Pin Connector; Remote Start Ribbon Harness, Wiring Diagram - Directed Electronics PYTHON 1090 Installation Manual

door lock harness, 3-pin connector

1 LIGHT BLUE
2 EMPTY
3 GREEN
Note: Refer to TechTip 1041 for wiring information.

remote start ribbon harness, wiring diagram

1 PINK/WHITE
2
YELLOW
3 PINK
4 ORANGE
5 PURPLE
6 ORANGE/BLACK
7 BLUE
This ribbon harness connects to the relay satellite.
© 2006 Directed Electronics—all rights reserved
(+) LOCK (-) UNLOCK OUTPUT
NOT USED
(-) LOCK (+) UNLOCK OUTPUT
200 mA (-) PROGRAMMABLE IGN2/ACC2 relay turn on
(+) ignition input to alarm
(-) 200 mA ignition relay turn-on
(-) 200 mA accessory relay turn-on
(-) 200 mA starter relay turn-on
(-) ANTIGRIND/GROUND WHEN armed OUTPUT
(-) 200 mA STATUS OUTPUT
1
