table of zones

When using the Diagnostic functions, use the Table of Zones to see which input has triggered the system. It
is also helpful in deciding which input to use when connecting optional sensors and switches.
ZONE NO.
1
2
3
4
5
6
NOTE: The Warn Away® response does not report on the LED.

shutdown diagnostics

to perform shutdown diagnostics

1. With the ignition OFF, press and HOLD the Valet/Program switch.
2. Turn the ignition ON and then back OFF while HOLDING the Valet/Program switch.
3. Release the Valet/Program switch.
4. Press and release the Valet/Program switch. The LED will report the last shutdown for one minute or
until the ignition is turned on.
LED FLASHES
One
Two
Three
Four
Six
Seven
Eight
TRIGGER TYPE
Trunk Input
Multiplexed Shock Sensor Input
Door Trigger
Multiplexed Shock Sensor Input
Ignition
Hood Brake Trigger
SHUTDOWN MODE
Timed out
Over-rev shutdown
Low or no RPM
Remote control shutdown (or optional push-button)
(-) Shutdown (H3/4 GRAY) or (+) Shutdown (H3/3 BROWN)
(-) Neutral safety shutdown (H3/1 BLACK/WHITE)
Wait-to-start timed out
INPUT DESCRIPTION
BLUE (H1/7)
Mux BLUE wire.
GREEN (H1/8) and VIOLET (H1/6).
Mux GREEN wire
Yellow ribbon harness wire
GRAY on the 6-pin shutdown harness.
