- Page 1 Wireless smoke and heat detector MSD-300 Firmware version 2.00 msd-300_en 08/24 SATEL sp. z o.o. • ul. Budowlanych 66 • 80-298 Gdańsk • POLAND tel. +48 58 320 94 00 www.satel.pl...
- Page 2 13 August 2005). The device meets the technical regulations of the Eurasian Customs Union. SATEL aims to continually improve the quality of its products, which may result in changes in their technical specifications and software. The current information on the introduced modifications is available on our website.
-
Page 3: Table Of Contents
CONTENTS Features ........................... 2 Description ........................2 Fire alarm ......................... 2 Tamper alarm ........................3 Radio transmissions ......................3 Detector test ........................3 Test mode ......................... 3 Detection of dirt in the optical chamber................3 Battery status control ......................3 LED indication ........................ -
Page 4: Features
MSD-300 SATEL The MSD-300 multisensor detector can detect the early stages of fire development when there is some visible smoke and/or temperature rise. It is designed to work as a stand-alone device or within the MICRA wireless system. This manual applies to the detector with electronics version 1.2 (or newer). -
Page 5: Tamper Alarm
SATEL MSD-300 Fire alarm signaling The fire alarm is indicated by the LED indicator (ON) and the built-in sounder (continuous sound) for 5 minutes. Resetting the fire alarm Press the test / reset button (Fig. 1) to clear the alarm. The fire alarm signaling will be turned off for 5 minutes. -
Page 6: Led Indication
MSD-300 SATEL • each radio transmission contains information about low battery. LED indication The LED indicator (Fig. 1 ) indicates: • fire alarm – ON for 2 minutes, • tamper alarm – ON for 2 seconds, • dirt in the optical chamber – single flash every 40 seconds, •... -
Page 7: Installation
SATEL MSD-300 Explanations for figures A and B: living room. bedroom. hall, lobby, etc. kitchen. basement. primary location for detector installation. additional location for detector installation. 3.2 Installation The detector enclosure cannot be closed without the battery inserted. There is a danger of battery explosion when using a different battery than recommended by the manufacturer, or handling the battery improperly. - Page 8 MSD-300 SATEL 3. Install the battery. 4. Register the detector in the wireless system (see the manual for PERFECTA control panels / VERSA control panels / MTX-300 controller / VERSA-MCU controller / MICRA module). 5. Place the detector where you are planning to install it.
-
Page 9: Maintenance
SATEL MSD-300 9. Replace the detector cover and lock it with a screw. The screw is provided in the bag together with the wall plugs and screws for mounting. 10. Press the test / reset button (Fig. 1). A fire alarm should be generated soon after. -
Page 10: Battery Replacement
MSD-300 SATEL 6. Battery replacement The used batteries must not be discarded, but should be disposed of in accordance with the existing rules for environment protection. When the detector indicates low battery (single beep every 40 seconds), replace the battery. -
Page 11: Specifications
SATEL MSD-300 7. Specifications Operating frequency band ............... 433.05 ÷ 434.79 MHz Radio communication range (in open area) ............up to 200 m Battery ........................CR123A 3 V Battery life expectancy ..................up to 3 years Standby current consumption ................... 50 µA Maximum current consumption ..................
