Satel CSP DMP-100 Manual

Satel CSP DMP-100 Manual

Multisensor smoke and heat detector optical smoke detector fixed temperature / rate-of-rise heat detector
Hide thumbs
1
2
3
4
5
6
7
8
Table of Contents

Advertisement

Quick Links

Download this manual
Multisensor smoke and heat detector
Fixed temperature / rate-of-rise heat detector
SATEL sp. z o.o. • ul. Budowlanych 66 • 80-298 Gdańsk • POLAND
tel. +48 58 320 94 00
www.satel.pl
DMP-100
Firmware version 2.00
Optical smoke detector
DRP-100
Firmware version 2.00
DCP-100
Firmware version 2.00
EN
dmp-100_en 11/22

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CSP DMP-100 and is the answer not in the manual?

Questions and answers

Related Manuals for Satel CSP DMP-100

Summary of Contents for Satel CSP DMP-100

  • Page 1 Firmware version 2.00 Optical smoke detector DRP-100 Firmware version 2.00 Fixed temperature / rate-of-rise heat detector DCP-100 Firmware version 2.00 dmp-100_en 11/22 SATEL sp. z o.o. • ul. Budowlanych 66 • 80-298 Gdańsk • POLAND tel. +48 58 320 94 00 www.satel.pl...
  • Page 2 IMPORTANT The device should be installed by qualified personnel. Prior to installation, please read carefully this manual in order to avoid mistakes that can lead to malfunction or even damage to the equipment. Disconnect power before making any electrical connections. Changes, modifications or repairs not authorized by the manufacturer shall void your rights under the warranty.
  • Page 3 1. Introduction This manual covers the following detectors: DMP-100 - conventional multisensor smoke and heat detector (Fig. 1); DRP-100 - conventional optical smoke detector (Fig. 2); DCP-100 - conventional fixed temperature / rate-of-rise heat detector (Fig. 1 – a red ring is painted on the enclosure of detector to differentiate it from the DMP-100).
  • Page 4 DMP-100 ● DRP-100 ● DCP-100 SATEL Rate of rise of air Lower limit of response Upper limit of response temperature time time 1 °C/min 29 min 40 min 20 s 3 °C/min 7 min 13 s 13 min 40 s 5 °C/min...
  • Page 5 DMP-100 ● DRP-100 ● DCP-100 SATEL 3. Remove the electronics module with the optical chamber (Fig. 7). 4. Remove the plastic element with the thermistor from the optical chamber cover (Fig. 8). 5. Release the mounting catch (Fig. 9) and remove the optical chamber cover (Fig. 10).
  • Page 6 DMP-100 ● DRP-100 ● DCP-100 SATEL 6. Specifications Supply voltage ....................10.5...26 V DC Quiescent current DMP-100 ............0.04 mA DRP-100 ............0.03 mA DCP-100 ............0.022 mA Alarm current DMP-100 ............23 mA DRP-100 ............23 mA DCP-100 ............23 mA Class according to EN 54-5 (heat sensor) ................A1R Minimum static response temperature ................
  • Page 7 1438-CPR-0316 for the construction product DCP-100 detector, confirming its compliance with the requirements of EN 54-5:2017+A1:2018. The Certificate and the Declaration of Constancy of Performance can be downloaded from the www.satel.pl website. SATEL Sp. z o.o. • ul. Budowlanych 66 • 80-298 Gdańsk • POLAND 1438 1438-CPR-0316 Declaration of Performance DOP/CPR/0316 EN 54-5:2017+A1:2018 Fire safety in construction works.
  • Page 8 DMP-100 ● DRP-100 ● DCP-100 SATEL SATEL Sp. z o.o. • ul. Budowlanych 66 • 80-298 Gdańsk • POLAND 1438 1438-CPR-0340 Declaration of Performance DOP/CPR/0340 EN 54-7:2018 1438 – CNBOP-PIB Fire safety in construction works. DRP-100 conventional spot type optical smoke detector, operating on light scattering principle,...

This manual is also suitable for:

Csp drp-100Csp dcp-100
