MICROWELL DRY SIREN ECO mono User And Installation Manual

Swimming pool dehumidifier

Advertisement

Quick Links

User´s and installation manual
SWIMMING POOL
DEHUMIDIFIER
Model:
DRY SIREN ECO mono
DRY SIREN ECO due
Version: 01/2024
ODU cond.pump contact

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DRY SIREN ECO mono and is the answer not in the manual?

Questions and answers

Summary of Contents for MICROWELL DRY SIREN ECO mono

  • Page 1 User´s and installation manual SWIMMING POOL DEHUMIDIFIER Model: DRY SIREN ECO mono DRY SIREN ECO due Version: 01/2024 ODU cond.pump contact...
  • Page 2: Table Of Contents

    P a g e 2 o f 6 8 V e r s i o n : 0 1 / 2 0 2 4 Thank you for purchasing Microwell swimming pool dehumidifier DRY SIREN. You hold in your hands probably the most advanced and most futuristic device for your pool.
  • Page 3 D R Y S I R E N E C O U s e r ´ s a n d i n s t a l l a t i o n m a n u a l P a g e 3 o f 6 8 V e r s i o n : 0 1 / 2 0 2 4 14.1 .............................
  • Page 4: Waste Disposal Information

    Model Microwell DRY SIREN is designed for halls with swimming pool surface of up to 60m For proper and optimal operations of the device is it necessary to maintain the air temperature in the swimming pool room / hall 2-3°C higher than actual water temperature...
  • Page 5: Usage Precautions

    D R Y S I R E N E C O U s e r ´ s a n d i n s t a l l a t i o n m a n u a l P a g e 5 o f 6 8 V e r s i o n : 0 1 / 2 0 2 4 •...
  • Page 6: Handling Precautions

    U s e r ´ s a n d i n s t a l l a t i o n m a n u a l D R Y S I R E N E C O P a g e 6 o f 6 8 V e r s i o n : 0 1 / 2 0 2 4 HANDLING PRECAUTIONS •...
  • Page 7: Parts List

    D R Y S I R E N E C O U s e r ´ s a n d i n s t a l l a t i o n m a n u a l P a g e 7 o f 6 8 V e r s i o n : 0 1 / 2 0 2 4 4.
  • Page 8 U s e r ´ s a n d i n s t a l l a t i o n m a n u a l D R Y S I R E N E C O P a g e 8 o f 6 8 V e r s i o n : 0 1 / 2 0 2 4 11 - Four core 12 - Three core cable...
  • Page 9 D R Y S I R E N E C O U s e r ´ s a n d i n s t a l l a t i o n m a n u a l P a g e 9 o f 6 8 V e r s i o n : 0 1 / 2 0 2 4 CEILING UNIT 1.
  • Page 10 10 | U s e r ´ s a n d i n s t a l l a t i o n m a n u a l D R Y S I R E N E C O P a g e 1 0 o f 6 8 V e r s i o n : 0 1 / 2 0 2 4 COMPRESSOR UNIT (MONO)
  • Page 11 | 11 D R Y S I R E N E C O U s e r ´ s a n d i n s t a l l a t i o n m a n u a l P a g e 1 1 o f 6 8 V e r s i o n : 0 1 / 2 0 2 4 COMPRESSOR UNIT (DUE)
  • Page 12: Tool List

    12 | U s e r ´ s a n d i n s t a l l a t i o n m a n u a l D R Y S I R E N E C O P a g e 1 2 o f 6 8 V e r s i o n : 0 1 / 2 0 2 4 5.
  • Page 13: Installation - Ceiling Unit

    | 13 D R Y S I R E N E C O U s e r ´ s a n d i n s t a l l a t i o n m a n u a l P a g e 1 3 o f 6 8 V e r s i o n : 0 1 / 2 0 2 4 29 - Charging scales...
  • Page 14: Basic Manipulation

    V e r s i o n : 0 1 / 2 0 2 4 BASIC MANIPULATION The unit is designed to be located on the ceiling. We, at Microwell, had to ensure a perfect balance between weight and long-term durability with focus on reliability of the product. It is thus necessary to mind below manipulation information and comply with them.
  • Page 15 | 15 D R Y S I R E N E C O U s e r ´ s a n d i n s t a l l a t i o n m a n u a l P a g e 1 5 o f 6 8 V e r s i o n : 0 1 / 2 0 2 4 Do not hold ceiling in areas where forbidden (bluetooth speaker, LED lamp, air outlet).
  • Page 16: Appropriate Position Of Ceiling Unit

    16 | U s e r ´ s a n d i n s t a l l a t i o n m a n u a l D R Y S I R E N E C O P a g e 1 6 o f 6 8 V e r s i o n : 0 1 / 2 0 2 4 APPROPRIATE POSITION OF CEILING UNIT...
  • Page 17: Swimming Pool

    | 17 D R Y S I R E N E C O U s e r ´ s a n d i n s t a l l a t i o n m a n u a l P a g e 1 7 o f 6 8 V e r s i o n : 0 1 / 2 0 2 4 Please mind electrical safety requirement below to locate an electrical device close to pool water.
  • Page 18: Fixation On A Ceiling - Concrete / Wood

    18 | U s e r ´ s a n d i n s t a l l a t i o n m a n u a l D R Y S I R E N E C O P a g e 1 8 o f 6 8 V e r s i o n : 0 1 / 2 0 2 4 FIXATION ON A CEILING –...
  • Page 19 | 19 D R Y S I R E N E C O U s e r ´ s a n d i n s t a l l a t i o n m a n u a l P a g e 1 9 o f 6 8 V e r s i o n : 0 1 / 2 0 2 4 Drill 6 holes (4 for TR8, 2 for Lifting mechanism).
  • Page 20 20 | U s e r ´ s a n d i n s t a l l a t i o n m a n u a l D R Y S I R E N E C O P a g e 2 0 o f 6 8 V e r s i o n : 0 1 / 2 0 2 4 Drill 4 holes (TR8) using 10mm bit by...
  • Page 21 | 21 D R Y S I R E N E C O U s e r ´ s a n d i n s t a l l a t i o n m a n u a l P a g e 2 1 o f 6 8 V e r s i o n : 0 1 / 2 0 2 4 WOOD...
  • Page 22 22 | U s e r ´ s a n d i n s t a l l a t i o n m a n u a l D R Y S I R E N E C O P a g e 2 2 o f 6 8 V e r s i o n : 0 1 / 2 0 2 4 Please refer to picture below in order to fix the final length of...
  • Page 23 | 23 D R Y S I R E N E C O U s e r ´ s a n d i n s t a l l a t i o n m a n u a l P a g e 2 3 o f 6 8 V e r s i o n : 0 1 / 2 0 2 4 Example:...
  • Page 24 24 | U s e r ´ s a n d i n s t a l l a t i o n m a n u a l D R Y S I R E N E C O P a g e 2 4 o f 6 8 V e r s i o n : 0 1 / 2 0 2 4 = depth in concrete of TR8 –...
  • Page 25 | 25 D R Y S I R E N E C O U s e r ´ s a n d i n s t a l l a t i o n m a n u a l P a g e 2 5 o f 6 8 V e r s i o n : 0 1 / 2 0 2 4 .
  • Page 26 26 | U s e r ´ s a n d i n s t a l l a t i o n m a n u a l D R Y S I R E N E C O P a g e 2 6 o f 6 8 V e r s i o n : 0 1 / 2 0 2 4 13 (1)
  • Page 27 | 27 D R Y S I R E N E C O U s e r ´ s a n d i n s t a l l a t i o n m a n u a l P a g e 2 7 o f 6 8 V e r s i o n : 0 1 / 2 0 2 4 Max.
  • Page 28 28 | U s e r ´ s a n d i n s t a l l a t i o n m a n u a l D R Y S I R E N E C O P a g e 2 8 o f 6 8 V e r s i o n : 0 1 / 2 0 2 4 Check the final distance of threaded bars and locking hooks on the...
  • Page 29 | 29 D R Y S I R E N E C O U s e r ´ s a n d i n s t a l l a t i o n m a n u a l P a g e 2 9 o f 6 8 V e r s i o n : 0 1 / 2 0 2 4 Next step will be actual fixation of the ceiling unit to its final position.
  • Page 30 30 | U s e r ´ s a n d i n s t a l l a t i o n m a n u a l D R Y S I R E N E C O P a g e 3 0 o f 6 8 V e r s i o n : 0 1 / 2 0 2 4 WOOD...
  • Page 31 | 31 D R Y S I R E N E C O U s e r ´ s a n d i n s t a l l a t i o n m a n u a l P a g e 3 1 o f 6 8 V e r s i o n : 0 1 / 2 0 2 4...
  • Page 32 32 | U s e r ´ s a n d i n s t a l l a t i o n m a n u a l D R Y S I R E N E C O P a g e 3 2 o f 6 8 V e r s i o n : 0 1 / 2 0 2 4...
  • Page 33 | 33 D R Y S I R E N E C O U s e r ´ s a n d i n s t a l l a t i o n m a n u a l P a g e 3 3 o f 6 8 V e r s i o n : 0 1 / 2 0 2 4 When installing you may use help of scaffold base or ladder.
  • Page 34: Installation - Compressor Unit

    34 | U s e r ´ s a n d i n s t a l l a t i o n m a n u a l D R Y S I R E N E C O P a g e 3 4 o f 6 8 V e r s i o n : 0 1 / 2 0 2 4 7.
  • Page 35: Installation - Electrical Connection

    | 35 D R Y S I R E N E C O U s e r ´ s a n d i n s t a l l a t i o n m a n u a l P a g e 3 5 o f 6 8 V e r s i o n : 0 1 / 2 0 2 4 Mount the compressor onto the wall console.
  • Page 36 36 | U s e r ´ s a n d i n s t a l l a t i o n m a n u a l D R Y S I R E N E C O P a g e 3 6 o f 6 8 V e r s i o n : 0 1 / 2 0 2 4 In order to protect the unit from weather anomalies it is recommended to install power surge...
  • Page 37 | 37 D R Y S I R E N E C O U s e r ´ s a n d i n s t a l l a t i o n m a n u a l P a g e 3 7 o f 6 8 V e r s i o n : 0 1 / 2 0 2 4 Mains and signal connection (MONO)
  • Page 38 L1, N1 and Earth. Please connect the communication cable (1, 2, 3, 4). In the case of DUE please connect both 1-2-3-4 always Master-Master and Slave-Slave. DRY SIREN Eco mono – connecting units with electrical cables 9mm/6mm...
  • Page 39 | 39 D R Y S I R E N E C O U s e r ´ s a n d i n s t a l l a t i o n m a n u a l P a g e 3 9 o f 6 8 V e r s i o n : 0 1 / 2 0 2 4 3x0,75mm...
  • Page 40: Drainage Of Condensate Water

    40 | U s e r ´ s a n d i n s t a l l a t i o n m a n u a l D R Y S I R E N E C O P a g e 4 0 o f 6 8 V e r s i o n : 0 1 / 2 0 2 4 DRAINAGE OF CONDENSATE WATER...
  • Page 41: Condensate Discharge

    | 41 D R Y S I R E N E C O U s e r ´ s a n d i n s t a l l a t i o n m a n u a l P a g e 4 1 o f 6 8 V e r s i o n : 0 1 / 2 0 2 4 Compressor unit is supplied with a condensate drain hose.
  • Page 42 42 | U s e r ´ s a n d i n s t a l l a t i o n m a n u a l D R Y S I R E N E C O P a g e 4 2 o f 6 8 V e r s i o n : 0 1 / 2 0 2 4 3.
  • Page 43 | 43 D R Y S I R E N E C O U s e r ´ s a n d i n s t a l l a t i o n m a n u a l P a g e 4 3 o f 6 8 V e r s i o n : 0 1 / 2 0 2 4 5.
  • Page 44 44 | U s e r ´ s a n d i n s t a l l a t i o n m a n u a l D R Y S I R E N E C O P a g e 4 4 o f 6 8 V e r s i o n : 0 1 / 2 0 2 4 Vertical discharge...
  • Page 45: Determining The Pipe Length And Refrigerant Charge

    | 45 D R Y S I R E N E C O U s e r ´ s a n d i n s t a l l a t i o n m a n u a l P a g e 4 5 o f 6 8 V e r s i o n : 0 1 / 2 0 2 4 INSTALLATION –...
  • Page 46 46 | U s e r ´ s a n d i n s t a l l a t i o n m a n u a l D R Y S I R E N E C O P a g e 4 6 o f 6 8 V e r s i o n : 0 1 / 2 0 2 4 Compressor unit...
  • Page 47: Refrigerant Piping

    | 47 D R Y S I R E N E C O U s e r ´ s a n d i n s t a l l a t i o n m a n u a l P a g e 4 7 o f 6 8 V e r s i o n : 0 1 / 2 0 2 4 Refrigerant piping...
  • Page 48: Flaring Work

    48 | U s e r ´ s a n d i n s t a l l a t i o n m a n u a l D R Y S I R E N E C O P a g e 4 8 o f 6 8 V e r s i o n : 0 1 / 2 0 2 4 type sealer or construction foam to seal...
  • Page 49 | 49 D R Y S I R E N E C O U s e r ´ s a n d i n s t a l l a t i o n m a n u a l P a g e 4 9 o f 6 8 V e r s i o n : 0 1 / 2 0 2 4 Smooth, shiny without scratches...
  • Page 50 50 | U s e r ´ s a n d i n s t a l l a t i o n m a n u a l D R Y S I R E N E C O P a g e 5 0 o f 6 8 V e r s i o n : 0 1 / 2 0 2 4 Tube length less than 10m...
  • Page 51: Unit Test - Start Up

    | 51 D R Y S I R E N E C O U s e r ´ s a n d i n s t a l l a t i o n m a n u a l P a g e 5 1 o f 6 8 V e r s i o n : 0 1 / 2 0 2 4 k.
  • Page 52: Remote Control - Instructions For Use

    52 | U s e r ´ s a n d i n s t a l l a t i o n m a n u a l D R Y S I R E N E C O P a g e 5 2 o f 6 8 V e r s i o n : 0 1 / 2 0 2 4 Compressor unit –...
  • Page 53: Bluetooth Speaker Identification & Pairing

    | 53 D R Y S I R E N E C O U s e r ´ s a n d i n s t a l l a t i o n m a n u a l P a g e 5 3 o f 6 8 V e r s i o n : 0 1 / 2 0 2 4 Bluetooth speaker identification &...
  • Page 54: Led Lamp Controller

    54 | U s e r ´ s a n d i n s t a l l a t i o n m a n u a l D R Y S I R E N E C O P a g e 5 4 o f 6 8 V e r s i o n : 0 1 / 2 0 2 4 LED lamp controller...
  • Page 55: Fan Running Mode

    | 55 D R Y S I R E N E C O U s e r ´ s a n d i n s t a l l a t i o n m a n u a l P a g e 5 5 o f 6 8 V e r s i o n : 0 1 / 2 0 2 4 Fan running mode...
  • Page 56 56 | U s e r ´ s a n d i n s t a l l a t i o n m a n u a l D R Y S I R E N E C O P a g e 5 6 o f 6 8 V e r s i o n : 0 1 / 2 0 2 4 To view operational parameters (diagnosis), please press gently once the diagnosis button...
  • Page 57: Technical Data

    | 57 D R Y S I R E N E C O U s e r ´ s a n d i n s t a l l a t i o n m a n u a l P a g e 5 7 o f 6 8 V e r s i o n : 0 1 / 2 0 2 4 7.
  • Page 58: Extraction Rate Diagram

    58 | U s e r ´ s a n d i n s t a l l a t i o n m a n u a l D R Y S I R E N E C O P a g e 5 8 o f 6 8 V e r s i o n : 0 1 / 2 0 2 4 Extraction rate diagram...
  • Page 59 | 59 D R Y S I R E N E C O U s e r ´ s a n d i n s t a l l a t i o n m a n u a l P a g e 5 9 o f 6 8 V e r s i o n : 0 1 / 2 0 2 4 Alternative...
  • Page 60: Hints & Tips

    60 | U s e r ´ s a n d i n s t a l l a t i o n m a n u a l D R Y S I R E N E C O P a g e 6 0 o f 6 8 V e r s i o n : 0 1 / 2 0 2 4 8.
  • Page 61: Troubleshooting - Save Time And Money

    | 61 D R Y S I R E N E C O U s e r ´ s a n d i n s t a l l a t i o n m a n u a l P a g e 6 1 o f 6 8 V e r s i o n : 0 1 / 2 0 2 4 Red light...
  • Page 62 62 | U s e r ´ s a n d i n s t a l l a t i o n m a n u a l D R Y S I R E N E C O P a g e 6 2 o f 6 8 V e r s i o n : 0 1 / 2 0 2 4 pairing problem,...
  • Page 63: Maintenance

    | 63 D R Y S I R E N E C O U s e r ´ s a n d i n s t a l l a t i o n m a n u a l P a g e 6 3 o f 6 8 V e r s i o n : 0 1 / 2 0 2 4 error code.
  • Page 64: Super-Chlorination Cleaning

    DRY SIREN is equipped with Microwell unique system microLIGHT+. This is built into the LED lamp and if activated (mobile application LIGHT settings) microLIGHT+ will signalize the actual level of humidity through color.
  • Page 65: Transport Instructions

    | 65 D R Y S I R E N E C O U s e r ´ s a n d i n s t a l l a t i o n m a n u a l P a g e 6 5 o f 6 8 V e r s i o n : 0 1 / 2 0 2 4 The dehumidifier was put to operation by an unauthorized person.
  • Page 66: Installation Check-List And Warranty Card

    U s e r ´ s a n d i n s t a l l a t i o n m a n u a l D R Y S I R E N E C O MANUFACTURER: MICROWELL, SPOL. S R.O., SNP 2018/42, 92701 SALA, SLOVAKIA. www.microwell.eu, export@microwell.sk. P a g e 6 6 o f 6 8...
  • Page 67 | 67 D R Y S I R E N E C O U s e r ´ s a n d i n s t a l l a t i o n m a n u a l P a g e 6 7 o f 6 8 V e r s i o n : 0 1 / 2 0 2 4 Notes:...
  • Page 68 Distributed by: Manufacturer: MICROWELL, spol. s r.o. SNP 2018/42, 927 01 Šaľa, Slovakia tel.: +421/31/7707082 e-mail: microwell@microwell.sk w w w . m i c r o w e l l . e u M a d e i n E U...
