  • Page 1 Installation and user manual POOL DEHUMIDIFIER Model: DRY 800 METAL DRY 1200 METAL Version: 01/2022...

  • Page 2: Table Of Contents

    D R Y 8 0 0 / 1 2 0 0 M e t a l V01/2022 Thank you, for purchasing a Microwell swimming pool dehumidifier. You have probably chosen the best and most energy efficient dehumidifier for your pool. Before you use this device, it is necessary to carefully read the entire Installation and user manual.

  • Page 3: Waste Disposal Information

    Installation and user manual D R Y 8 0 0 / 1 2 0 0 M e t a l V01/2022 1. WASTE DISPOSAL INFORMATION If you are using the heat pump in Europian countries, you must follow these instructions: DISPOSAL: Do not dispose this product as unsorted municipal waste.

  • Page 4: Usage Precautions

    Installation and user manual D R Y 8 0 0 / 1 2 0 0 M e t a l V01/2022 • Do not clean device with water. • Before cleaning the device, unplug the power cord and switch off the circuit breaker of the unit’s power supply.

  • Page 5: Handling Precautions

    Installation and user manual D R Y 8 0 0 / 1 2 0 0 M e t a l V01/2022 Handling precautions Leave the unit in a vertical upright position for at least Keep in vertical 2 hours before mounting. It is necessary to stabilize position for 2 hours the refrigerant charge and especially to return the oil to the compressor tray.

  • Page 6: Product Description

    Installation and user manual D R Y 8 0 0 / 1 2 0 0 M e t a l V01/2022 • Please notify your reseller or distributor if the delivered unit had been damaged. The unit may appear to work fine at first, but minor damage may cause the unit to stop working properly in a short time.
  • Page 7 Installation and user manual D R Y 8 0 0 / 1 2 0 0 M e t a l V01/2022 5 – Adjusting "L" 6- Built-in digital piece humidistat and thermostat + screw M6 – 2x + nut MC – 1x + washer D7 –...
  • Page 8 Installation and user manual D R Y 8 0 0 / 1 2 0 0 M e t a l V01/2022 7 – air filter 8 – fresh air supply adapter Installed inside the device List of necessary tools (is not part of packaging): Názov/ kód Obrázok Názov/ kód...

  • Page 9: Description Of Basic Parts

    15 - position of the nut for screwing the locking L-pieces to the wall Fresh air supply (on demand as accessory) Each MICROWELL DRY dehumidifier has the option of fresh air supply. The air supply is located below the condenser, which effectively heats the incoming fresh air due to heat recovery.

  • Page 10: Handling Instructions

    Installation and user manual D R Y 8 0 0 / 1 2 0 0 M e t a l V01/2022 | 1 0 HANDLING INSTRUCTIONS Main humidistat The dehumidifier is switched on and off using a digital humidistat with a display. The built-in humidistat is located in the housing of the device.
  • Page 11 Installation and user manual D R Y 8 0 0 / 1 2 0 0 M e t a l V01/2022 | 1 1 User setting HUMIDITY / TEMPERATURE changing ( /* Manufacturer settings) Press SET key for 10secs Temperature manufacturer setting User setting TEMPERATURE without LPHW with LPHW...
  • Page 12 Installation and user manual D R Y 8 0 0 / 1 2 0 0 M e t a l V01/2022 | 1 2 Deviation, correction and other service settings Press SET key for 10secs Displayed immediately Displayed after 10 secs Press SET button shortly TEMPERATURE output type select...
  • Page 13 Installation and user manual D R Y 8 0 0 / 1 2 0 0 M e t a l V01/2022 | 1 3 Program setting ( /* Manufacturer settings) TEMPERATURE output type Cooling Heating /* TEMP. output delay time setting Change TEMP.
  • Page 14 Installation and user manual D R Y 8 0 0 / 1 2 0 0 M e t a l | 1 4 V01/2022 HUMIDITY output type select Humidifying Dehumidifying /* HUMI. output delay time setting Change Single.(+) hysteresis HUMI. output Double(+/-) hysteresis setting setting /* hysteresis type select...

  • Page 15: Backup Humidistat

    Installation and user manual D R Y 8 0 0 / 1 2 0 0 M e t a l | 1 5 V01/2022 Backup humidistat Your dehumidifier is equipped with a built-in mechanical humidistat as standard. On request, it can be equipped with an external wired humidistat, or an external wireless humidistat and thermostat.
  • Page 16 Installation and user manual D R Y 8 0 0 / 1 2 0 0 M e t a l V01/2022 | 1 6 provided that the built-in humidity controller in the dehumidifier is set to a higher desired humidity value than the remote humidistat.
  • Page 17 Installation and user manual D R Y 8 0 0 / 1 2 0 0 M e t a l V01/2022 | 1 7 Location of receiver and antenna A: The receiver is located inside the electrical box and the antenna is located on the outside of the electrical box.

  • Page 18: Humidity Control By External Wired Humidistat Eberle

    Installation and user manual D R Y 8 0 0 / 1 2 0 0 M e t a l V01/2022 | 1 8 Humidity control by external wired humidistat EBERLE If your device is equipped with an EBERLE wired remote humidity controller, pay attention to this section of the installation manual.

  • Page 19: Compressor Regulation

    Installation and user manual D R Y 8 0 0 / 1 2 0 0 M e t a l V01/2022 | 1 9 Compressor regulation The start of the compressor is delayed by 3 minutes due to it‘s protection. Depending on the humidity and ambient temperature, this may take longer.

  • Page 20: Locating The Device

    POOL expected to be present. MICROWELL DRY 800/1200 METAL are designed to be installed directly in the pool hall. All models are protected by electrical protection class IP44.
  • Page 21 Installation and user manual D R Y 8 0 0 / 1 2 0 0 M e t a l V01/2022 | 2 1 1. In order to be as efficient as possible, the appliance must be installed as high as possible but not completely below the ceiling.

  • Page 22: Installation Of Device

    Installation and user manual D R Y 8 0 0 / 1 2 0 0 M e t a l V01/2022 | 2 2 Always install the dehumidifier so that it can dehumidify pool air. In case of a structured pool hall, or a separate part –...
  • Page 23 Installation and user manual D R Y 8 0 0 / 1 2 0 0 M e t a l V01/2022 | 2 3 3. Remove the 4 M8 screws that secure the dehumidifier to the palet. WARNING! Do not unscrew the M6 screws. After removing these screws, there is risk of the device falling. 5.2.1 Floor installation 2.
  • Page 24 Installation and user manual D R Y 8 0 0 / 1 2 0 0 M e t a l V01/2022 | 2 4 Not included in packaging. 5.2.2 Wall installation – on demand If the dehumidifier is being installed on a wall, it is necessary to order a set of brackets for wall mounting.
  • Page 25 Installation and user manual D R Y 8 0 0 / 1 2 0 0 M e t a l V01/2022 | 2 5...
  • Page 26 Installation and user manual D R Y 8 0 0 / 1 2 0 0 M e t a l V01/2022 | 2 6 5.2.3 THROUGH-THE-WALL installation – on demand Dehumidifiers are also easily adapted for installation behind a wall in a side room. Only two grilles are then visible in the pool hall area.
  • Page 27 Installation and user manual D R Y 8 0 0 / 1 2 0 0 M e t a l | 2 7 V01/2022 REAR VIEW - Intake and exhaust positions on the back of the dehumidifier and fresh air supply Heating water supply to hot water inserts on the right side/when viewed from the front Air exhaust...
  • Page 28 Installation and user manual D R Y 8 0 0 / 1 2 0 0 M e t a l V01/2022 | 2 8 FRONT VIEW Heating water supply to hot water inserts on the right side of unit SIDE VIEW Heating water supply to hot Heating water supply to hot water insert from the right side...
  • Page 29 Installation and user manual D R Y 8 0 0 / 1 2 0 0 M e t a l | 2 9 V01/2022 COVER REMOVAL Lower the side cover caps, unscrew and remove the side cover screws. Lift the cover as shown in the illustration. Disconnect the connectors on the display on the left side under the cover.
  • Page 30 Installation and user manual D R Y 8 0 0 / 1 2 0 0 M e t a l V01/2022 | 3 0 Place the cover sideways on a foam pad or cardboard so that you do not scratch the cover on the floor.
  • Page 31 Installation and user manual D R Y 8 0 0 / 1 2 0 0 M e t a l V01/2022 | 3 1 Lower the inner cover on the left. Electric box Terminal box Slide the dehumidifier against the wall to the pipe fittings, connect the electrical cable and the condensation hose.
  • Page 32 Installation and user manual D R Y 8 0 0 / 1 2 0 0 M e t a l V01/2022 | 3 2 Slide the dehumidifier onto the pipe fittings and screw the pipe fittings onto the rear wall of the dehumidifier.

  • Page 33: Condensate Drain

    Installation and user manual D R Y 8 0 0 / 1 2 0 0 M e t a l V01/2022 | 3 3 5.2.4 Compressor protection during transport The compressor is protected during transport by plastic straps. This requires the size and weight of the compressor so that the equipment delivered to you is safe and fully functional.
  • Page 34 Installation and user manual D R Y 8 0 0 / 1 2 0 0 M e t a l V01/2022 | 3 4 may lead to unit failure, damage, or failure. It can also cause the floor to get wet, creating the risk of injury and damage to health from unwanted slipperiness.

  • Page 35: Main Power Supply Connection

    Installation and user manual D R Y 8 0 0 / 1 2 0 0 M e t a l V01/2022 | 3 5 CONDENSATE DRAIN Condensate drain Condensate drain Bathtub Sink Sewerage Condensate drain Condensat Overflow e drain Main power supply connection 5.4.1 Main electrical connection for fixed cable in wall As standard, the dehumidifiers are connected to a fixed cable in the wall.
  • Page 36 Installation and user manual D R Y 8 0 0 / 1 2 0 0 M e t a l V01/2022 | 3 6 Standard terminal block - L, N, ground Main power supply Dehumidifier type El. cable El. insulation DRY 800 CYSY 3x 2,5 mm 16 A type C...
  • Page 37 Installation and user manual D R Y 8 0 0 / 1 2 0 0 M e t a l V01/2022 | 3 7 EBERLE HYG6001 connection for DRY 800/1200 MAIN EL. CONNECTION OF DEHUMIDIFIER 230V/50Hz/1f 3x 2.5mm CYSY Black box from the SIDE of the breaker 16A (DRY800) / 20A electrobox (DRY1200) type C...
  • Page 38 Installation and user manual D R Y 8 0 0 / 1 2 0 0 M e t a l V01/2022 | 3 8 Electric heating element connection for DRY 800/1200 EL. HEATING POWER SUPPLY 230V/50Hz/1f Kábel: 3x2.5mm CYSY Príkon: 2.5kW Istič: 16A MAIN ELECTRICAL CONNECTION OF THE DEHUMIDIFIER...

  • Page 39: Lphw Hot Water Insert For Additional Heating - On Demand

    If your dehumidifier is equipped with a hot water insert and/or a solenoid valve, you must use a MICROWELL DRY EASY300 wireless humidistat and a thermostat with an EBERLE HYG7001 thermostat to activate the air heating function with a dehumidifier, or you must have an external thermostat connected.
  • Page 40 Installation and user manual D R Y 8 0 0 / 1 2 0 0 M e t a l V01/2022 | 4 0 dimension DN 12, Parameters of the solenoid valve: operating pressure PN 10, threaded connection, control: coil 230V (D-233), material: brass, controlled directly,...

  • Page 41: Electric Heating

    Installation and user manual D R Y 8 0 0 / 1 2 0 0 M e t a l | 4 1 V01/2022 LPHW (W) Heat output of heating element It is recommended to insert DRY800/1200 a shut-off valve between the LPHW hot water insert and 90/70/30°C 7000...

  • Page 42: Air Filter - On Demand

    Installation and user manual D R Y 8 0 0 / 1 2 0 0 M e t a l V01/2022 | 4 2 Air filter – on demand Your dehumidifier can be equipped with an air filter on request. The air filter traps dust and other mechanical particles and prevents them from entering the fins of aluminum heat exchangers.
  • Page 43 Installation and user manual D R Y 8 0 0 / 1 2 0 0 M e t a l | 4 3 V01/2022 A. Electrical installation FRESH AIR INTAKE WITH AUTOMATIC CONTROL OF BLINDS WASTE AIR EXHAUST FRESH AIR INTAKE (automatic fins) (automatic fins) MAIN POWER SUPPLY...
  • Page 44 Installation and user manual D R Y 8 0 0 / 1 2 0 0 M e t a l V01/2022 | 4 4 Wall Dehumidifier Electric fins + SERVO Fresh air adapter (turn outwards from the unit) d100 piping...

  • Page 45: Technical Data

    Installation and user manual D R Y 8 0 0 / 1 2 0 0 M e t a l V01/2022 | 4 5 TECHNICAL DATA Technical data chart* DRY 800 DRY 1200 Data Unit METAL METAL For swimming pool with a max. water 60-90 90-120 surface of:...
  • Page 46 Installation and user manual D R Y 8 0 0 / 1 2 0 0 M e t a l V01/2022 | 4 6 EL. CONNECTION SCHEME DRY 800 – BASIC CONNECTION DRY 800.1...
  • Page 47 Installation and user manual D R Y 8 0 0 / 1 2 0 0 M e t a l V01/2022 | 4 7...
  • Page 48 Installation and user manual D R Y 8 0 0 / 1 2 0 0 M e t a l V01/2022 | 4 8...
  • Page 49 Installation and user manual D R Y 8 0 0 / 1 2 0 0 M e t a l V01/2022 | 4 9 6.1.1 EL. CONNECTION SCHEME DRY 800 – ADVANCED CONNECTION DRY 800.1 - Connection of terminal block X8.1 and humidity / thermostats 1401F, EASY 300, EBERLE...
  • Page 50 Installation and user manual D R Y 8 0 0 / 1 2 0 0 M e t a l V01/2022 | 5 0 DRY 800.2 - Connection of terminal block X8.2 and humidistat with thermostat, voltage- free heating contact and solenoid solenoid valve...
  • Page 51 Installation and user manual D R Y 8 0 0 / 1 2 0 0 M e t a l V01/2022 | 5 1 6.1.2 EL. CONNECTION SCHEME DRY 1200 – BASIC CONNECTION DRY 1200.1...
  • Page 52 Installation and user manual D R Y 8 0 0 / 1 2 0 0 M e t a l V01/2022 | 5 2...
  • Page 53 Installation and user manual D R Y 8 0 0 / 1 2 0 0 M e t a l V01/2022 | 5 3...
  • Page 54 Installation and user manual D R Y 8 0 0 / 1 2 0 0 M e t a l V01/2022 | 5 4 DRY 1200.1 - Connection of terminal block X12.1 and humidity / thermostats 1401F, EASY 300, EBERLE...
  • Page 55 Installation and user manual D R Y 8 0 0 / 1 2 0 0 M e t a l V01/2022 | 5 5 DRY 1200.2 - Connection of terminal block X12.2 and humidistat with thermostat, voltage-free heating contact and solenoid solenoid valve...

  • Page 56: Summer Shutdown

    Installation and user manual D R Y 8 0 0 / 1 2 0 0 M e t a l V01/2022 | 5 6 7 SUMMER SHUTDOWN Users of indoor pools take the opportunity to shut down the dehumidifier for the summer. This is mainly due to favorable weather conditions during the summer - dry and warm weather.

  • Page 57: Maintanance Instructions

    The DRY300 / 400/500 can be equipped with the unique Microwell microLIGHT + system. It is a built- in LED strip that is located inside the unit. microLIGHT + will signal the current color humidity level.
  • Page 58 Installation and user manual D R Y 8 0 0 / 1 2 0 0 M e t a l V01/2022 | 5 8 microLIGHT+ will also signal if your humidity is rising. For example, if you have a covered pool and the humidity is fine, you will see a green light.

  • Page 59: Warranty Conditions

    Please contact your reseller or distributor if the warranty should be applied to the dehumidifier. Use the following Microwell disclaimer under warranty. No claim will be accepted if: 1. The dehumidifier was used incorrectly, other than as described in this manual or in violation of this user manual, resp.
  • Page 60 Installation and user manual D R Y 8 0 0 / 1 2 0 0 M e t a l V01/2022 | 6 0 TRANSPORTATION The dehumidifier must only be transported in the original packaging in an upright position. When transporting, secure the dehumidifier against tipping over and falling. Never place the dehumidifier on its side! There is a risk of serious damage to the compressor! Damage during transport is never covered by the warranty! If you receive the shipment, check the integrity of the packaging and document any...
  • Page 61 Installation and user manual D R Y 8 0 0 / 1 2 0 0 M e t a l V01/2022 | 6 1...
  • Page 62 Installation and user manual D R Y 8 0 0 / 1 2 0 0 M e t a l V01/2022 | 6 2 Notes:...
  • Page 63 Installation and user manual D R Y 8 0 0 / 1 2 0 0 M e t a l V01/2022 | 6 3 Notes:...
  • Page 64 D R Y 8 0 0 / 1 2 0 0 M e t a l V01/2022 | 6 4 Distributor: Manufacturer: MICROWELL, spol. s r.o. SNP 2018/42, 927 01 Šaľa, Slovakia tel.: +421/31/770 7082 e-mail: microwell@microwell.sk w w w . m i c r o w e l l . e u...
