Figure 8. Strobe surface mount:
Standard
Backbox
1. Complete field wiring.
2. Screw strobe to box with screw A.
3. Fill remaining holes with screw B.
Figure 10. Sounder or sounder/strobe semi-flush
mount:
STANDARD
BACKBOX
1. Screw plate to box with screw E.
2. Complete field wiring. (See Fig. 3, 4, 5, and 6)
3. Screw sounder or sounder/strobe
to plate with screw A.
4. Fill remaining holes with screw B.
Figure 12. Sounder flush mount (deep box required):
BB-D
D
1. Screw sounder to plate.
2. Complete field wiring.
3. Screw plate sounder to box
with screw F.
D900-01-00
A
P
T O
Signal Strobe
B
B
A
A78-2514-00
MP-SF
MA-12/24D
E
E
A
B
B
A
A78-2517-01
D
MA 12/24D
MP-F
C
F
F
C
A78-1137-08
Figure 9. Sounder/strobe sur face mount:
Standard
Backbox
1. Complete field wiring.
2. Screw sounder/strobe to box with screw A.
3. Fill remaining screw holes with screw B
Figure 11. Strobe semi-flush mount:
1. Screw strobe to plate with
screw C.
2. Complete field wiring.
3. Screw strobe plate to box with
screw A.
Figure 13. Sounder or sounder/strobe semi-flush
mount with plaster ring:
1. Plaster ring should be properly mounted to electrical box with
screws supplied with box.
2. Screw plate to plaster ring with screw G.
3. Complete field wiring.
4. Screw sounder/strobe to plate with screw A.
5. Fill remaining holes with screw B.
G
Standard
Backbox
Plaster
Ring
MP-SF
4
MA-12/24D
Signal Strobe
B
A
STANDARD
BACKBOX
MP-SF
Signal Strobe
P
T O
C
A
MA 12/24
B
G
A
A
I56-650-16
© System Sensor 1996
A
B
A78-2515-00
A
C
A78-2516-00
A78-1137-11
