INSTALLATION AND MAINTENANCE INSTRUCTIONS
SS24ADAS Series Strobes and
MASS24ADAS Series Synchronized
Horn/Strobes for Fire Protective
Signaling Systems
Table 1. SS24ADAS Series Electrical Ratings:
Model Supply Operating Current from
Voltage Regulated Supply
Range
Average
Operating Current
Current
(mA)
SS2415ADAS 20-30V 106
SS241575ADAS 20-30V 195
General Description
The National Fire Protection Association has published
standards and recommended practices for the installation
and use of the listed appliances. It is recommended that the
installer be familiar with these requirements, with local
codes, and any special requirements of the local fire au-
thority having jurisdiction.
The Multi-Alert sounder and signaling strobe are intended
to be connected to the alarm indicating circuit of a UL-
listed fire alarm control panel and is compatible with DC
line supervision. The electronic sounder can be connected
to either 12 or 24 VDC panels. Models SS2415ADAS,
SS241575ADAS, and combination models incorporating
these strobes, require 24 volt panels. Panels may have full-
wave rectified, unfiltered power supplies. The strobes are
synchronized and flash at a rate of one flash per second
with continuous voltage applied. SS24ADAS, SS24ADA,
MASS24ADAS, and MASS24ADA series devices may be
combined in the same zone.
Table 2. Sound output and current ratings for the MA12/24D:
Sound (Hz)
Slow Whoop
800 Continuous
800/1000 Alternating
2400 Interrupted
2400 Continuous
1200 Interrupted
Swept Frequency
Fast Warble
Note 1: See Figure 2 for tab clip removal & storage.
Note 2: All models can be powered using full wave rectified unfiltered
supplies. Under no circumstances can
MASS24ADAS series devices input voltage exceed 33 VDC or be
D900-06-00
Operating Current from Full-Wave
Rectified Unfiltered Supply
Peak Inrush Average
Current Operating
(mA) (Amps) Current
20/30 (mArms)
Vrms
200 5.0/7.0 125
350 5.0/7.0 180
Clips on Current (mA)
Tabs DC Regulated/
FWR Unfiltered
(Note 1)
12V 24V
ABC 21/40 38/56
BC 15/24 28/45
AC 17/32 34/46
AB 19/23 35/56
C 21/31 38/59
B 13/19 23/33
A 17/24 34/47
NONE 15/27 30/47
SS24ADAS or
Peak Inrush
Current Current
(mA) (Amps)
20/30
Vrms
250 5.0/7.0
395 5.0/7.0
The MA12/24D sounder is suitable for outdoor applica-
tions (-35° to 66° C) when it is used with a WBB Weather-
proof Back Box. The signaling strobe is rated for 0° to 49°
C and is NOT suitable for outdoor use.
The UL-rated light
SS241575ADAS, MASS2415ADAS, and MASS241575ADAS
is 15 cd (See Figure 1).
NOTE: The light output at 0° viewing angle for
SS241575ADAS and MASS241575ADAS is 75 cd.
Any one of eight sounds can be selected on the electronic
sounder, as indicated in Table 2.
NOTE: SS24ADAS, MASS24ADAS AND MAEH24ADAS
SERIES DEVICES OPERATING IN THE SAME
ZONE WILL NOT BE SYNCHRONIZED IF ENER-
GIZED AT DIFFERENT TIMES (I.E., IF MORE
THAN ONE CONTROLLER IS CONTROLLING THE
SAME ZONE.)
Output (dBA)
(Note 3)
30V 12V 24V
46/72 85 92
35/55 87 93
43/58 85 92
43/64 89 90
46/73 85 94
27/41 85 91
43/60 85 92
38/59 85 92
less than 16 VDC (18-33Vrms for full-wave rectified, unfiltered
supplies).
Note 3: Measured at 10 feet in an anechoic chamber.
Note 4: Measured in a UL reverberant room.
1
A Division of Pittway
3825 Ohio Avenue, St. Charles, Illinois 60174
1-800-SENSOR2, FAX: 630-377-6495
NOTE: In-rush current du-
ration is less than 20
m i c r o s e c o n d s
(.00002 seconds).
output of the SS2415ADAS,
UL (dBA)
Ratings
(Note 4)
12V 24V
79 85
79 85
79 85
79 85
79 85
75 82
79 85
79 85
I56-750-57
