Figure 1. Vertical and horizontal light distribution:
Figure 2:
COVER SLOT
CLIP
STORAGE
FOR STORING UNUSED CLIPS:
SLIDE COVER BACK TO ALIGN COVER SLOT
WITH CLIP STORAGE POST.
Figure 4. Strobe:
Figure 6. Multi-alert sounder and strobe operating
independently:
Caution: Break off P.C.B. Tabs
To Next
Device
or EOL
(–) (–) (+)
IN OUT IN OUT IN OUT
STROBE STROBE
ONLY ONLY
Screw types used in figure 9 to 15
A = 8-32x1-7/16" Slot
B = #8 Sheet Metal Phillips
C = 8-32x1" Phillips
D = #8 Sq. Nut
E = 8-32x5/8" Slot
F = 8-32x2-3/4" Slot
G = 6-32x5/8" Slot
D900-01-00
TONE
SELECTION TABS
TAB A
TAB B
TAB C
USE A
SMALL-
BLADED
SCREWDRIVER
TO REMOVE
CLIPS REMOVED OR
CLIPS
ADDED TO SELECT
DESIRED TONE.
A78-2167-00
– VDC
Non-
Coded
STROBE
+ VDC Supply
– VDC
Can Be
Coded
SOUNDER
Supply
+ VDC
From
panel or
previous
(+)
IN OUT
device
A78-1137-01
0˚
45˚
LIGHT
90˚
Figure 3. Multi-alert sounder:
To Next
Device
or EOL
(-)
IN OUT
STROBE
ONLY
Figure 5. Multi-alert sounder and strobe operating in
tandem:
To Next
Device
or EOL
(–)
IN OUT
STROBE
ONLY
Note: Use uncoded supply only.
Figure 7. Sounder surface mount:
BB-STD
1. Complete field wiring. (See Fig. 5)
2. Screw sounder to box with screw A.
3. Fill remaining holes with screw B.
3
Degrees % of Rating
0 100
5 - 25 90
30 - 45 75
50 55
–45˚
55 45
60 40
65 35
70 35
75 30
80 30
85 25
–90˚
90 25
- VDC
+ VDC
From
panel or
(-) (+) (+)
IN OUT IN OUT IN OUT
STROBE previous
ONLY
device
A78-1137-00
– VDC
+ VDC
From
panel or
previous
(–) (+) (+)
IN OUT IN OUT IN OUT
device
STROBE
ONLY
A78-1137-29
MA12/24D
A
B
B
A
A78-1137-03
I56-650-16
