Figure 2. Sounder and strobe operating
independently:
Caution: Break off P.C.B. Tabs
To Next
Device
or EOL
(–) (–) (+)
IN OUT IN OUT IN OUT
STROBE STROBE
ONLY ONLY
Figure 4. Sounder/strobe surface mount:
Standard
Backbox
1. Screw Sounder/Strobe to Box with A
2. Fill Remaining Screw Holes with Screw B
Screw Types Used In Figures 4 Through 7
A = 8-32 x 1-7/16 Slot.
B = #8 Sht. Mtl. Phil.
C = 8-32 x 1 Phil.
D = #8 Sq. Nut.
E = 8-32 x 5/8 Slot.
F = 8-32 x 2-3/4 Slot.
G = 6-32 x 5/8 Slot.
D900-04-00
– VDC
Non-
Coded
STROBE
+ VDC Supply
– VDC
Can Be
Coded
SOUNDER
Supply
+ VDC
From
panel or
previous
(+)
IN OUT
device
A78-1137-01
MA-12/24D
Signal Strobe
A
B
B
A
A78-2515-00
Figure 3. Sounder and strobe operating in tandem:
To Next
Device
or EOL
(–)
IN OUT
STROBE
ONLY
Note: Use uncoded supply only.
Figure 5. Sounder or sounder/strobe semiflush
mount:
STANDARD
BACKBOX
E
1. Screw Plate to Box with E
2. Complete Wiring (See Fig. 2 and 3)
3. Screw Sounder or Sounder/Strobe
to Plate with A
4. Fill Remaining Holes with Screw B
3
– VDC
+ VDC
From
panel or
previous
(–) (+) (+)
IN OUT IN OUT IN OUT
device
STROBE
ONLY
MP-SF
MA-12/24D
B
A
I56-712-03
A78-1137-29
A
B
A78-1137-26
