INSTALLATION AND MAINTENANCE INSTRUCTIONS
RK24ADA Series Retrofit Strobes
for Fire Protective Signaling Systems
Table 1. RK24ADA Series Electrical Ratings:
Model Supply Operating Current from
Voltage
Range
Average
Operating
Current
RK24110ADA 20-30V
RK2475ADA 20-30V
RK2415ADA 20-30V
RK241575ADA 20-30V
NOTE: In-rush current duration is less than 20 microseconds (.00002 seconds).
NOTICE: This manual should be left with the owner/user
of this equipment.
General Description
The National Fire Protection Association has published
standards and recommended practices for the installation
and use of the above appliances. It is recommended that
the installer be familiar with these requirements, with local
codes, and any special requirements of the local fire au-
thority having jurisdiction.
The signaling strobes are intended to be connected to the
alarm indicating circuit of a UL-listed fire alarm control
panel and are compatible with DC line supervision. Models
RK2415ADA, RK2475ADA,
RK241575ADA require 24 volt panels. Panels may have
full-wave rectified, unfiltered power supplies. The strobes
produce one flash per second (nominal) with continuous
Figure 1. Vertical and horizontal light distribution:
Vertical Dispersion
D900-04-00
Regulated Supply
Peak Inrush
Current Current
(mA) (mA in
20/30V access
of Peak)
210 470/500 0
170 385/400 0
75 160/180 0
93 210/220 0
RK24110ADA,
Operating Current from Full-Wave
Rectified Unfiltered Supply
Average Peak
Operating Current
Current (mA)
(mArms) 20Vrms/
30Vrms
245 400/500
200 320/370
90 275/290
120 275/290
nominal voltage applied.
The MA12/24D is suitable for outdoor applications (-35° to
66° C) when it is used with a WBB Weatherproof Back Box.
The signaling strobe is rated for 0° to 49° C and is NOT
suitable for outdoor use.
The rated light
RK241575ADA is 15 cd (see Figure 1).
The rated light output of the RK2475ADA is 75 cd (please
see Figure 1).
and The rated light output of the RK24110ADA is 110 cd (please
see Figure 1).
NOTE: The light output at 0°
RK241575ADA is 75 cd (please see Figure 1).
0˚
45˚
90˚
Horizontal Dispersion
1
A Division of Pittway
3825 Ohio Avenue, St. Charles, Illinois 60174
1-800-SENSOR2, FAX: 630-377-6495
Inrush
Current
(Amps in
excess
of Peak)
0.08
0.04
0.02
1.0
output of the RK2415ADA
viewing angle for
–45˚
LIGHT
–90˚
and
I56-712-03
