Safety Information - Time RX Instinct Assembly Instructions Manual

TIME RX Instinct component composition:
RTM
Frame
VIBRASER technology
Monobloc
Fork
TIME RTM carbon
Seatpost
Quick Set
Headset
Compression cap
Accessories
Stem spacer kit
TransLink joint
TransLink cutting tool
Front and rear brake nuts
Cable sleeve under bottom bracket
Quick Set adjustment pins
Nota: The TIME RX Instinct
It is protected under the following patents:
- Quick Set Headset: EP 1 569 843 and US 7 237 787
- Multi-diameter pivot: FR 2 807 382 and US6 805 372
- Composite pivot: EP 1 015 301
The TIME modules or frames
intended. Please read carefully the following instructions, ensuring a safe use.
Tightening torques:
Carefully follow all tightening torques in order to maintain proper function and security.
Use a high quality torque wrench.
- Saddle clamp = 8 Nm (rear bolt)
- Saddle = 5 Nm
- Rear stem bracket = 5 Nm
- Front stem bracket = 6 Nm
- Brake nuts = 5 Nm
- Front derailleur support = 7 Nm
Replacement parts:
- Only use original parts when replacing worn parts (bearings, derailleur supports, etc.)
Projet de notice de montage
RX Instinct
Composition
Carbon Matrix + TIME
RTM carbon
conforms to the standards EN 14781

SAFETY INFORMATION

are high end products and they contain every safety security when used as
Technical specifications:
- Wheel diameter
- Tire cross section
- Front hub width
- Rear hub width
- Bottom bracket width
- Bottom bracket
- Crankset w/double chainring
- Crankset w/triple chainring
- Seatpost
- Front derailleur type
- Rear derailleur support
- Brake caliper
- Headset
- 3 -
700C
700 x 23
100 mm
130 mm
68 mm
Standard BB30
43,5 mm
46,5 mm
Specific
A braser
M10 x 100
Standard shoes
(Route 39/50)
Integrated
